Preparing to charge the high-voltage battery

Control module display ⇒ fig. 136:
No. Display Meaning Proper re-
sponse
(5) Flashes
is connected to
the vehicle.
High-voltage
battery is being
charged.
(1) (4)
Flashes
The charging
cable is con-
nected to an
outlet without a
Ground Fault
Circuit (GFI).
The high-voltage
battery is not
being charged.
Connect charg-
ing cable to a
110 Volt outlet
with a Ground
Fault Circuit
(GFI).
Lights up
Charging cable
is connected to a
110 Volt outlet,
but an error was
detected by the
control module.
The high-voltage
battery is not
being charged.
Disconnect the
charging cable
from the 110 Volt
outlet and plug it
back in. If the
error comes
back again, get
expert assis-
tance from a
qualified electri-
cal installation
specialist.

Control module display ⇒ fig. 136:
No. Display Meaning Proper re-
sponse
(1) (2) (4) Lights up
During the
charging pro-
cess: The con-
trol unit detected
a residual cur-
rent, the charg-
ing process is
interrupted.
Dangerous con-
tact voltage
damaged isola-
tion detected at
the voltage
source. High-
voltage battery is
not being
charged.
Or: Damaged
isolation detect-
ed in the vehi-
cle’s high-
voltage system.
Get expert assis-
tance from a
qualified electri-
cal installation
specialist.
During the test-
ing of the
Ground Fault
Circuit (GFI):
The test button
(3) was pressed
for longer than 3
seconds. The
high-voltage
battery is not
being charged.
Press the reset
button (6) for at
least 3 seconds.
(1) (2) Flashes Charging cable Have charging

Control module display ⇒ fig. 136:
No. Display Meaning Proper re-
sponse
(4) Lights up
is connected to a
110 Volt outlet,
but an error was
detected by the
control module.
The high-voltage
battery is not
being charged.
cable checked
by a qualified
electrical special-
ist. Go to an
authorized
Volkswagen
dealer or
Volkswagen
service facility for
assistance.
(2) (4) Lights up
The vehicle’s
system detected
an error in the
connected
charging cable.
The high-voltage
battery is not
being charged.
Disconnect the
charging cable
from the 110 Volt
outlet and the
vehicle and plug
it back in. Should
the error occur
again, get expert
assistance from
a qualified elec-
trical installation
specialist.
(1) (2) Lights up An overheating - Let the charg-

Control module display ⇒ fig. 136:
No. Display Meaning Proper re-
sponse
(4) Flashes
of the charging
cable was de-
tected. The high-
voltage battery is
not being
charged. An
overheating can
be caused by:
- A damaged 110
Volt outlet
- Ambient tem-
perature above
113 °F (45 °C)
- A damaged
charging cable
ing cable cool
down.
- Should the
error occur
again, have
charging cable
checked by a
qualified electri-
cal specialist. Go
to an authorized
Volkswagen
dealer or
Volkswagen
service facility for
assistance.
(1) Lights up
The system de-
tected fluctua-
tions in the volt-
age. The high-
voltage battery is
not being
charged
- The charging
process will con-
tinue automati-
cally once the
voltage is stable
again.
- If necessary try
connecting the
cable to another
110 Volt outlet.
- Should the
error occur
again, get expert
assistance from
a qualified elec-
trical installation
specialist.
(4) Flashes
(2) Flashes Excess voltage - Disconnect the

Control module display ⇒ fig. 136:
No. Display Meaning Proper re-
sponse
(4) Lights up
was detected by
the control unit.
The high-voltage
battery is not
being charged.
charging cable
from the 110 Volt
outlet and the
vehicle and plug
it back in.
- If necessary try
connecting the
cable to another
110 Volt outlet.
- Should the
error occur
again, have
charging cable
checked by a
qualified electri-
cal specialist. Go
to an authorized
Volkswagen
dealer or
Volkswagen
service facility for
assistance.

Enabling the charging process
After a successful self-test, press the button (1) to set the protection unit to ready and enable the charging process. The LED in the protection unit symbol (2) lights up green.
Ending the charging process
If you want to interrupt the high-voltage battery charging process before charging is completed, the charging process must be interrupted or ended on the vehicle
Checking the Ground Fault Circuit (GFI) of the 110 Volt outlet
The GFI should be checked once a month. Carry out this procedure with the charging cable connected to the 110 Volt outlet and the vehicle. The charging process has to be deactivated:
x Press the test button (3) on the control unit of the charging cable for at about 3 seconds.
x If the test was successful, the warning lights (1) and (2) will light up. Should these warning lights not light up or other lights should light up or flash, an error occurred while testing.
x After a successful test and if error occurred, you can start the charging process by pressing the rest button (6) for at least 3 seconds.

Temperature monitoring
During the charging process the charging cable can become slightly warmer. This is normal and no cause for concern
If the control unit or the charging cable becomes too hot, the charging current will automatically be reduced If the control unit or the charging cable continues to get hot even at the lowest charging current, the protection unit will be switched off, and will remain switched off until it has cooled down sufficiently.
If no other sources of heat, such as direct sunlight, can be identified as relevant, have the outlet checked by properly qualified and trained experts.
Charging cable for charging at charging stations (if equipped)
Keep the charging cable for charging at a charging station safely in its bag in the luggage compart-ment. Follow the operating manual for the charging station. Before using the charging cable, read the procedure for charging with alternating current
WARNING
Charging the high-voltage battery improperly, using improper or damaged outlets and charg-ing cables, improper handling of the high-voltage battery or failure to follow safe charging procedures can cause short circuits, electric shock, explosions, fire, burns, injuries and death.
x Always connect the charging cable to a properly functioning 110 Volt Ground Fault Circuit (GFI) wall outlet. The outlet must be properly protected from water, moisture and other fluids.
x Always check the fuse protection of the GFI outlet before connecting the charging cable.
x Never connect the charging cable to a conventional power outlet, regardless of whether the outlet is protected or not.
x Never use the charging cable with an extension cord of any kind.
x Never let plugs or connectors come into contact with water, moisture, or any other fluids.
x Never use any charging cable if it is damaged and never use the charging cable with a damaged GFI outlet.
x Never attempt to alter or repair cables or other electrical components.
x Never let anybody stay in the vehicle while the high-voltage battery is charging.
x Never do any kind of work on the outside or inside of the vehicle while the high-voltage battery is charging.
x Always disconnect the charging cable completely from the vehicle before starting the motor.
WARNING
If you are not familiar with the outlet or the electrical installation or it has not been checked by qualified experts, never use it for charging. Even very low charging currents can cause serious damage and in particular fires if the socket or electrical installation is in bad condi-tion. If necessary, get expert assistance from a qualified electrical installation specialist.
WARNING
If a 110 Volt outlet is being used for charging, never charge 2 or more vehicles on outlets of the same fuse at the same time. Use a different fuse circuit for charging another vehicle. Al-ways comply with the maximum load for the fuse circuit used. If necessary, get expert assis-tance.
