2015 VOLKSWAGEN E GOLF Owners Manual

The procedure can be repeated a second time, but the possible driving distance and the power will be reduced considerably. Please contact an authorized Volkswagen dealer , Volkswagen service facility or roadside assistance if the vehicle cannot be moved any further.
Charge the high-voltage battery as soon as possible
WARNING
Driving when the high-voltage battery charge is too low can lead to stalling in traffic, colli-sions and serious personal injury.
x Always make sure that the high-voltage battery has a sufficient charge level to get where you are going and that the high-voltage battery can be charged when you get there.
WARNING
If the maximum power reserve is not available or the charge level of the high-voltage battery has reached the “reserve range”, the driving characteristics can change, for example, the acceleration performance of the vehicle.
x Always adapt your speed and driving style to suit visibility, weather, road and traffic con-ditions as well as the charge level of the high-voltage battery.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x A broken down vehicle presents a high accident risk for itself and others. Switch on emergency flashers and set up a warning triangle or other device to warn oncoming traffic.
NOTICE
If the vehicle is parked for a long period with a drained high-voltage battery, irreversible dam-age can be caused to the high-voltage battery.
x Always charge the high-voltage battery as soon as possible .
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Stopping the electric motor

Step Vehicles without Keyless Ac-
cess Vehicles with Keyless Access
1. Bring the vehicle to a complete stop ⇒ .
2. Depress and hold down the brake pedal until step 4 is completed.
3. Shift the transmission into Park (P).
4. Apply the parking brake to help prevent the vehicle from moving
5. Turn the vehicle key to position
⇒ fig. 120 (0) in the ignition
switch.
Briefly press the starter button
⇒ fig. 121. If the electric motor
will not switch off, carry out the
emergency shut-off procedure
7.
Removing the vehicle key from
the ignition switches off electrical
equipment and activates the
steering column lock.
Opening the doors switches off
electrical equipment and acti-
vates the steering column lock.

WARNING
Never stop the electric motor before the vehicle has come to a complete stop. You can lose control of the vehicle, crash, and be seriously injured.
x The airbags and safety belt pretensioners will not work when the ignition is switched off.
x The brake booster does not work when the electric motor is not activated. More brake pedal pressure will be needed to stop the vehicle.
x The power steering system does not work when the electric motor is not activated, and you will need more force to steer the vehicle.
x When the key is removed from the ignition switch, the steering will lock and you will not be able to steer the vehicle.
If the ignition is switched on or the electric motor is activated and the driver door is opened, a chime sounds. The chime is also a reminder to switch off the electric motor and turn off the ignition before leaving and locking the vehicle from the outside.
The vehicle key can only be removed from the ignition when the transmission is in Park (P).
After the electric motor has been switched off, the radiator fan in the electric motor compartment may keep activated for several minutes, or may start activated after the vehicle has been parked for a while, even if the ignition is switched off and the vehicle key has been removed. The radiator fan shuts off automatically when the electric motor has cooled down enough.

Driving profiles

Fig. 125 In the lower part of the center console: Button for selecting driving profile.

Displaying the driving mode
x Make sure that the ignition is switched on.
x Press the

The electric motor can therefore only be activated with an authorized and correctly coded genuine Volkswagen vehicle key. Coded vehicle keys are available from authorized Volkswagen dealers, authorized Volkswagen Service Facilities, and from certain independent repair facilities and locksmiths
who are qualified to make these vehicle keys ⇒  Vehicle key set.
If an unauthorized vehicle key is used, a message may appear in the instrument cluster display. The vehicle cannot be operated with this key.
A Declaration of Compliance with the United States FCC and Industry Canada regulations is on ⇒  Declaration of Compliance, Telecommunications and Electronic Systems.
Using genuine Volkswagen keys helps minimize the risk of malfunctions.

Shifting

x Before driving downhill, especially on hills that are long or steep, always reduce speed and shift into an adequate recuperation level. This will let the vehicle use the electric motor braking and reduce the load on the brakes. Otherwise, the brake system could overheat and even fail. Only use the brakes when you need them to slow the vehicle down more or to stop.
Warning and indicator lights

NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Pedals

Fig. 126 Pedals in the vehicle: 1 Accelerator pedal, 2 Brake pedal.
