2015 MAZDA MODEL 3 4-DOOR Owners Manual

*Some models.7–33
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Message Indicated on Display *
If a message is displayed in the center display (Type B audio), take appropriate action (in a
calm manner) according to the displayed message.
(Display example)
Stop Vehicle in Safe Place Immediately
If the following messages are displayed in the center display (Type B audio), a vehicle
system may be malfunctioning. Stop the vehicle in a safe place and conta\
ct an Authorized
Mazda Dealer.
Display Indicated Condition
Displays if the engine coolant temperature has
increased excessively.
Displays if the charging system has a malfunction.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










7–34
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Make Sure the Message is No Longer Displayed
Displays in the following cases:
Display Indicated Condition/Action to be taken
Displays if i-ELOOP requires charging. Leave the
engine idling and wait until the message disappears.
NOTE
yIf the vehicle is driven while the message is displayed,
the buzzer will sound.
yIf you turn the steering wheel while the message is displayed, it will feel heavier than normal, but
this does not indicate an abnormality. The steering
operation will return to normal after the message has
disappeared.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










7–35
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Warning Sound is
Activated
Lights-On Reminder
The lights-on reminder is operable when
the time setting *1 of the auto headlight off
function is off.
If lights are on and the ignition is switched
to ACC or the ignition is switched off, a
continuous beep sound will be heard when
the driver's door is opened.
*1 If the light switch is left on, the auto headlight off function automatically
turns off the lights about 30 seconds
after switching the ignition off. The
time setting can be changed.
Refer to Personalization Features on page 9-12 .
NOTE
 y When the ignition is switched to ACC,
the “Ignition Not Switched Off (STOP)
Warning Beep” (page 7-36 ) overrides
the lights-on reminder.
 y A personalized function is available to
change the sound volume for the lights-
on reminder.
 Refer to Personalization Features on page 9-12 .
Air Bag/Front Seat Belt Pretensioner System Warning
Beep
If there is a problem with the air bag/seat
belt pretensioner systems and the warning
light illumination, a warning beep sound
will be heard for about 5 seconds every
minute.
The air bag and seat belt pretensioner
system warning beep sound will continue
to be heard for approximately 35
minutes. Have your vehicle inspected at
an Authorized Mazda Dealer as soon as
possible.
WARNING
Do not drive the vehicle with the air
bag/seat belt pretensioner system
warning beep sounding:
Driving the vehicle with the air bag/
seat belt pretensioner system warning
beep sounding is dangerous. In a
collision, the air bags and the seat belt
pretensioner system will not deploy
and this could result in death or serious
injury. Contact an Authorized Mazda
Dealer to have the vehicle inspected as
soon as possible.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










7–36
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Seat Belt Warning Beep
If the driver's seat belt is not fastened
when the ignition is switched ON, a beep
sound will be heard for about 6 seconds. If
the driver or the front passenger's seat belt
is not fastened and the vehicle is driven
at a speed faster than about 20 km/h (12
mph), a beep sound will be heard again for
a specifi ed period of time.
NOTE
 y Placing heavy items on the front
passenger seat may cause the front
passenger seat belt warning function to
operate depending on the weight of the
item.
 y To allow the front passenger seat weight
sensor to function properly, do not place
and sit on an additional seat cushion
on the front passenger seat. The sensor
may not function properly because the
additional seat cushion could cause
sensor interference.
 y When a small child sits on the front
passenger seat, it is possible that the
warning beep will not operate.
Ignition Not Switched Off (STOP) Warning Beep
If the driver's door is opened while
the ignition is switched to ACC, a
continuous beep sound will be heard to
notify the driver that the ignition has not
been switched off (STOP). Left in this
condition, the keyless entry system will
not operate, the car cannot be locked, and
the battery power will be depleted.
Key Removed from Vehicle Warning Beep
A beep sound will be heard 6 times and
the KEY warning light (red) will fl ash
continuously if the ignition has not been
switched off, all the doors are closed, and
the key is removed from the vehicle. This
is to notify the driver that the key has been
removed from the vehicle and the ignition
has not been switched off.
NOTE
Because the key utilizes low-intensity
radio waves, the Key Removed From
Vehicle Warning may activate if the key is
carried together with a metal object or it
is placed in a poor signal reception area.
Request Switch Inoperable Warning Beep (With the advanced
keyless function)
If the request switch is pressed with a door
open or ajar or the ignition has not been
switched off while the key is being carried,
a beep will be heard for about 2 seconds
to indicate that the doors and the liftgate/
trunk lid cannot be locked.
Key Left-in-luggage Compartment Warning Beep (With the advanced
keyless function)
If the key is left in the trunk with all doors
locked and the trunk lid closed, a beep
sound is heard for about 10 seconds to
remind the driver the key has been left in
the trunk. If this happens, open the trunk
lid by pressing the electric trunk lid opener
and remove the key. A key removed from
the trunk may not function because its
functions may have been temporarily
suspended. To restore the key function,
perform the applicable procedure (page
3-8 ).
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










*Some models.7–37
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Key Left-in-vehicle Warning Beep (With the advanced keyless
function)
If a key is left in the vehicle cabin and all
the doors and the trunk are locked using
a separate key, a beep sound is heard for
about 10 seconds to remind the driver
that the key has been left in the vehicle
cabin. If this happens, open the door and
remove the key. A key removed from the
vehicle this way may not function because
its functions may have been temporarily
suspended. Perform the applicable
procedure to restore the functions of the
key (page 3-8 ).
i-ELOOP Warning Beep *
The beep will activate if you attempt to
drive the vehicle under the following
conditions.
 y  The i-ELOOP indicator light is fl ashing
green.
 y  “i-ELOOP Charging” is indicated in the
center display (Type B audio).
The beep will stop when the vehicle is
stopped. Make sure the indicator light is
no longer illuminated and the message
is no longer displayed before driving the
vehicle.
Tire Infl ation Pressure Warning
Beep*
The warning beep sound will be heard
for about 3 seconds when there is any
abnormality in tire infl ation pressures
(page 4-103 ).
Lane Departure Warning System (LDWS) Warning Sound *
While the system is operating, if the
system determines that the vehicle may
depart from the lane, it sounds a warning
sound.
NOTE
 y  The volume of the LDWS warning sound
can be changed.
 Refer to Personalization Features on page 9-12 .
 y The type of the LDWS warning sound
can be changed.
 Refer to Personalization Features on page 9-12 .
Blind Spot Monitoring (BSM) System Warning Beep *
Driving forward
The warning beep operates when the turn
signal lever is operated to the side where
the Blind Spot Monitoring (BSM) warning
light is illuminated.
NOTE
A personalized function is available to
change the Blind Spot Monitoring (BSM)
warning beep sound volume.
Refer to Personalization Features on page
9-12 .
Reversing
If a moving object such as a vehicle or
two-wheeled vehicle approaches on the
left or right from behind your vehicle, the
Blind Spot Monitoring (BSM) warning
sound is activated.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










*Some models.7–38
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Mazda Radar Cruise Control (MRCC) System Warnings *
The Mazda Radar Cruise Control (MRCC)
system warnings notify the driver of
system malfunctions and cautions on use
when required.
Check based on the beep sound.
Cautions What to check
The beep sounds 1 time
while the Mazda Radar
Cruise Control (MRCC)
is operating The vehicle speed is
slower than 25 km/h (16
mph) and the Mazda
Radar Cruise Control
(MRCC) system has
been canceled.
The beep sounds
continuously while
driving The distance between
your vehicle and the
vehicle ahead is too
close. Verify the safety
of the surrounding area
and reduce vehicle
speed.
When the Mazda
Radar Cruise Control
(MRCC) is operating,
the beep sounds and the
Mazda Radar Cruise
Control (MRCC)
warning light (amber)
in the instrument cluster
fl ashes. A malfunction in
the system may be
indicated. Have your
vehicle inspected at
an Authorized Mazda
Dealer.
Collision warning *
If there is the possibility of a collision
with a vehicle ahead, the beep sounds
continuously and a warning is indicated in
the display.
Power Steering Warning Buzzer
If the power steering system has
a malfunction, the power steering
malfunction light turns on or fl
ashes and
the buzzer operates at the same time.
Refer to Warning/Indicator Lights on page
4-20 .
Over Rev. Buzzer *
The buzzer sounds to notify the driver if
the engine speed is about to exceed the
permissible engine speed.
CAUTION
Operate the accelerator and shift gears
according to the driving conditions so
that the buzzer does not sound. If the
engine speed exceeds the permissible
engine speed, the engine could be
damaged.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










7–39
If Trouble Arises
When Liftgate/Trunk Lid Cannot be Opened
When Liftgate/Trunk Lid
Cannot be Opened
If the vehicle battery is dead or there is a
malfunction in the electrical system and
the liftgate/trunk lid can not be opened,
perform the following procedure as an
emergency measure to Open it:
(5–door)
1. Remove the cap on the interior surface of the liftgate with a fl athead
screwdriver.
Cap
2. Turn the lever to the right to unlock the liftgate.
Lever
Cap
(4–door)
1. Open the cover.
2. Open the cap.
Cover
Cap
3. Turn the screw counterclockwise and remove it, and then remove the inner
cover.
Screw
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC










7–40
If Trouble Arises
When Liftgate/Trunk Lid Cannot be Opened
4. Move the lever to the left to fold the seatback.
Cover
Lever
5. Move the lever to the left to open the trunk lid.
(Type A)
(Type B)
After performing this emergency
measure, have the vehicle inspected at
an Authorized Mazda Dealer as soon as
possible.
.B[EB@%9&"'@&EJUJPOJOEC


.B[EB@%9&"'@&EJUJPOJOEC
