2015 LEXUS LS600H light

5047-2. Steps to take in an emergency
LS600hL_U(OM50E41U)
The warning lights and warning buzzers operate as follows depending on
the content of the message. If a message indicates the need for inspection
by a dealer, have the vehicle inspected by your Lexus dealer immediately.
*: A buzzer sounds the first time a message is shown on the multi-information display.
■Warning message in radar cruise mode (if equipped)
In the following cases, the warning message may not be displayed even if vehicle-to-
vehicle distance decreases:
●When your vehicle and the vehicle ahead are traveling at the same speed or the
vehicle ahead is traveling more quickly than your vehicle
●When the vehicle ahead is traveling at a very low speed
●Immediately after cruise control speed is set
●At the instant the accelerator pedal is depressed
Messages and warnings
System warn- ing lightWa r n i n g buzzer
*Wa r n i n g
Remains onSounds
Indicates an important situation
such as the malfunction of the
system related to driving that
may result in danger
Remains on or flashesSounds
Indicates an important situation
such as the malfunction of the
system shown on the multi-infor-
mation display
FlashesSounds
Indicates a situation such as
damage to the vehicle that may
result in danger
Remains onDoes not sound
Indicates a condition such as a
malfunction of electrical compo-
nents and the need for mainte-
nance
FlashesDoes not sound
Indicates a situation such as the
incorrect performance of an
operation and how to perform
the operation correctly

5057-2. Steps to take in an emergency
7
When trouble arises
LS600hL_U(OM50E41U)
■The LKA (Lane-Keeping Assist) lane departure warning function (if equipped)
In the following cases, the warning message will not be displayed even if a lane line is
crossed.
●When the vehicle speed deviates from the operating range of the LKA system
functions
●When the lane lines cannot be recognized
●When the steering wheel is turned as far as necessary to cause the vehicle to
change lanes
■System warning lights
The master warning light does not come on or flash in the following cases. Instead, a
separate system warning light will come on or flash along with the message shown
on the multi-information display.
●Malfunction of the brake system
The brake system warning light (red indicator) comes on. ( P. 4 9 3 )
●Malfunction of the regenerative brake syst em, electronically controlled brake sys-
tem or electric parking brake
The brake system warning light (yellow indicator) comes on. ( P. 495)
●Malfunction of the ABS
The ABS warning light comes on. ( P. 4 9 4 )
●Malfunction of the charging system
The charging system warning light comes on. ( P. 4 9 4 )
●Indicates that a door or the trunk is not fully closed
The open door warnin g light comes on. (P. 4 9 6 )
●High engine coolant temperature
The needle of the engine coolant temperature gauge enters the red zone.
( P. 5 3 0 )
■If “Maintenance required ” is shown (U.S.A. only)
Perform the necessary maintenance.
Please reset the message after the maintenance is performed. ( P. 4 2 6 )
■If “Hybrid System Overheat” is shown
Coping method: P. 5 3 0
This message may be displayed when driv ing under severe operating conditions.
(For example, when driving up a long steep hill.)
■Warning buzzer
In some cases, the buzzer may not be hear d due to ambient noise or sounds from the
audio system.

5117-2. Steps to take in an emergency
7
When trouble arises
LS600hL_U(OM50E41U)
Slightly loosen the wheel nuts
(one turn).
Turn the tire jack portion “A” by
hand until the notch of the jack is
in contact with the jack point.
The jack point guides are located
under the rocker panel. They indicate
the jack point positions.
Raise the vehicle until the tire is
slightly raised off the ground.
Remove all the wheel nuts and
the tire.
When resting the tire on the ground,
place the tire so that the wheel design
faces up to avoid scratching the wheel
surface.
2
3
4
5

5157-2. Steps to take in an emergency
7
When trouble arises
LS600hL_U(OM50E41U)
■Run-flat tires (A “RFT” or “DSST” mark is molded on the sidewall)
Take your vehicle to the nearest
Lexus dealer or authorized tire
dealer as soon as possible if any
tire goes flat.
The vehicle can be driven for a
maximum of 99 miles (160 km) at a
speed below 50 mph (80 km/h)
after the tire pressure warning light
comes on. (P. 4 9 7 )
■In some conditions (such as at high temperatures)
You cannot continue driving fo r up to 99 miles (160 km).
■For the detailed information on run-flat tires
See the tire warranty booklet.
■When replacing the tires
P. 5 1 0
If you have a flat tire (vehicles with run-flat
tires)
Your vehicle is not equipped with a spare tire, but instead you can con-
tinue driving the vehicle with run-flat tires even if any tire goes flat.
In this case, slow down and drive with extra caution.

5177-2. Steps to take in an emergency
7
When trouble arises
LS600hL_U(OM50E41U)
One of the following may be the cause of the problem:
●The electronic key may not be functioning properly. (P. 5 2 6 )
●There may not be sufficient fuel in the vehicle’s tank.
Refuel the vehicle.
●There may be a malfunction in the immobilizer system. ( P. 8 8 )
●There may be a malfunction in the steering lock system.
●The hybrid system may be malfunctio ning due to an electrical problem
such as electronic key battery de pletion or a blown fuse. However,
depending on the type of malfuncti on, an interim measure is available
to start the hybrid system. ( P. 5 1 8 )
One of the following may be the cause of the problem:
●The 12-volt battery may be discharged. ( P. 5 2 7 )
●The 12-volt battery terminal connecti ons may be loose or corroded.
If the hybrid system will not start
Reasons for the hybrid system not st arting vary depending on the situa-
tion. Check the following and perf orm the appropriate procedure:
The hybrid system will not start even though the correct starting
procedure is being followed. ( P. 2 1 6 )
The interior lights and headlights are dim, or the horn does not
sound or sounds at a low volume.

5187-2. Steps to take in an emergency
LS600hL_U(OM50E41U)
One of the following may be the cause of the problem:
●One or both of the 12-volt battery terminals may be disconnected.
●The 12-volt battery may be discharged. ( P. 5 2 7 )
Contact your Lexus dealer if the problem cannot be repaired, or if repair proce-
dures are unknown.
When the hybrid system does not start, the following steps can be used as
an interim measure to star t the hybrid system if the power switch is func-
tioning normally:
Turn the power switch to ON mode ( P. 217) and check that the park-
ing brake is set.
Shift the shift lever to P.
Turn the power switch to ACCESSORY mode.
Press and hold the power switch fo r about 15 seconds while depressing
the brake pedal firmly.
Even if the hybrid system can be star ted using the above steps, the system
may be malfunctioning. Have the vehicle inspected by your Lexus dealer.
The interior lights and headlights do not turn on, or the horn does
not sound.
Emergency start function
1
2
3
4

5277-2. Steps to take in an emergency
7
When trouble arises
LS600hL_U(OM50E41U)
If you have a set of jumper (or booster) cables and a second vehicle with a
12-volt battery, you can jump start your vehicle by following the steps
below.
Open the trunk lid and remove the 12-volt battery cover. ( P. 450)
In the event that the trunk opener cannot be used, use the mechanical key to open
the trunk. ( P. 5 2 4 )
Connect the jumper cables according to the following procedure:
Positive (+) battery terminal on your vehicle
Positive (+) battery terminal on the second vehicle
Negative (-) battery terminal on the second vehicle
Negative (-) battery terminal on your vehicle
Start the engine of the second ve hicle. Increase the engine speed
slightly and maintain at that le vel for approximately 5 minutes to
recharge the 12-volt battery of your vehicle.
Open and close any of th e doors of your vehicle with the power switch
off.
If the 12-volt battery is discharged
The following procedures may be used to start the hybrid system if the
12-volt battery is discharged.
You can also call your Lexus dealer or a qualified repair shop.
1
2
1
2
3
4
3
4

5287-2. Steps to take in an emergency
LS600hL_U(OM50E41U)
Maintain the engine speed of the second vehicle and start the hybrid
system of your vehicle by turning the power switch to ON mode.
Make sure the “READY” indicator co mes on. If the indicator does not
come on, contact your Lexus dealer.
Once the hybrid system has started, remove the jumper cables in the
exact reverse order from wh ich they were connected.
Once the hybrid system starts, have the vehicle inspected at your Lexus
dealer as soon as possible.
■Starting the hybrid system when the 12-volt battery is discharged
The hybrid system cannot be started by push-starting.
■To prevent 12-volt battery discharge
●Turn off the headlights and the audio system while the hybrid system is off.
●Turn off any unnecessary electrical compon ents when the vehicle is running at a
low speed for an extended period, such as in heavy traffic.
■When the 12-volt battery is removed or discharged
The hybrid system may not start.
(  P. 4 5 1 )
■Charging the 12-volt battery
The electricity stored in the 12-volt battery will discharge gradually even when the
vehicle is not in use, due to natural discharge and the draining effects of certain elec-
trical appliances. If the vehicle is left for a long time, the 12-volt battery may dis-
charge, and the hybrid system may be unable to start. (The 12-volt battery recharges
automatically while the hybrid system is operating.)
■When recharging or replacing the 12-volt battery
●Make sure that the key is not inside the vehicle when recharging or replacing the
12-volt battery. The key may be locked in the vehicle if the alarm is activated.
(  P. 9 1 )
●In some cases, it may not be possible to unlock the doors using the smart access
system with push-button start when the 12-volt battery is discharged. Use the wire-
less remote control or the mechanical key to lock or unlock the doors.
■If the 12-volt battery is discharged
The information stored in the computer will be deleted.
If the 12-volt battery is discharged, have the vehicle inspected by your Lexus dealer.
5
6
7
