2015 LEXUS LS600H run flat

483
When trouble arises7
LS600hL_U(OM50E41U)7-1. Essential information
Emergency flas hers.................. 484
If your vehicle has to be stopped in an
emergency ................................ 485 7-2. Steps to take in an
emergency
If your vehicle needs to be towed ...........................................486
If you think something is wrong ........................................... 492
If a warning light turns on or a warning buzzer
sounds.......................................... 493
If a warning message is displayed.....................................503
If you have a flat tire (vehicles with
a spare tire)................................506
If you have a flat tire (vehicles with
run-flat tires)............................... 515
If the hybrid system will not start .........................................517
If the shift lever cannot be shifted from P............................. 519
If the parking brake cannot be released................. 520
If the electronic key does not operate properly ............. 524
If the 12-volt battery is discharged ................................. 527
If your vehicle overheats .........530
If the vehicle becomes stuck ............................................. 535

4927-2. Steps to take in an emergency
LS600hL_U(OM50E41U)●
Fluid leaks under the vehicle.
(Water dripping from the air conditioning after use is normal.)
●Flat-looking tires or uneven tire wear
●Engine coolant temperature gauge
needle continually points higher
than normal.
●Changes in exhaust sound
●Excessive tire squeal when cornering
●Strange noises related to the suspension system
●Pinging or other noises related to the hybrid system
●Engine missing, stumbling or running roughly
●Appreciable loss of power
●Vehicle pulls heavily to one side when braking
●Vehicle pulls heavily to one side when driving on a level road
●Loss of brake effectiveness, spongy feeling, pedal almost touches the
floor
If you think something is wrong
If you notice any of the following symptoms, your vehicle probably
needs adjustment or repair. Contact your Lexus dealer as soon as pos-
sible.
Visible symptoms
Audible symptoms
Operational symptoms

5007-2. Steps to take in an emergency
LS600hL_U(OM50E41U)
CAUTION
■If both the ABS and the brake system warning lights remain on
Stop your vehicle in a safe place immediately and contact your Lexus dealer. The
vehicle will become extremely unstable during braking, and the ABS system may
fail, which could cause an accident resulting in death or serious injury.
■When the electric power steering system warning light comes on
The steering wheel may become extremely heavy.
If the steering wheel becomes heavier than usual when operating, hold firmly and
operate using more force than usual.
■If the tire pressure warning light comes on
Be sure to observe the following precautions. Failure to do so could cause a loss of
vehicle control and result in death or serious injury.
Vehicles with a spare tire
●Stop your vehicle in a safe place as soon as possible. Adjust the tire inflation pres-
sure immediately.
●If the tire pressure warning light comes on even after tire inflation pressure adjust-
ment, it is probable that you have a flat tire. Check the tires. If a tire is flat, change
it with the spare tire and have the flat tire repaired by the nearest Lexus dealer.
●Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could
lose control of the steering wheel or the brakes.
Vehicles with run-flat tires
●Decelerate to the lowest appropriate speed as soon as possible. Do not drive
over 50 mph (80 km/h).
●Check and adjust the tire inflation pressure immediately.
●If the tire pressure warning light comes on even after tire inflation pressure adjust-
ment, it is probable that you have a flat tire. Have the tire replaced by the nearest
Lexus dealer.
●Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could
lose control of the steering wheel or the brakes.
■If a blowout or sudden air leakage should occur
The tire pressure warning system may not activate immediately.

5107-2. Steps to take in an emergency
LS600hL_U(OM50E41U)
Lift up the luggage mat and secure it by using the hook provided.
( P. 3 74 )
Loosen the center fastener that
secures the spare tire.
If the center fastener cannot be turned
by hand, use the wheel nut wrench
that is stored in the trunk. (To secure
the tire, tighten the center fastener by
hand. Do not use the wrench or other
tools.)
Chock the tires.
Taking out the spare tire
1
2
CAUTION
■When storing the spare tire
Be careful not to catch fingers or other body parts between the spare tire and the
body of the vehicle.
Replacing a flat tire
1
Flat tireWheel chock positions
FrontLeft-hand sideBehind the rear right-hand side tire
Right-hand sideBehind the rear left-hand side tire
RearLeft-hand sideIn front of the front right-hand side tire
Right-hand sideIn front of the fron t left-hand side tire

5157-2. Steps to take in an emergency
7
When trouble arises
LS600hL_U(OM50E41U)
■Run-flat tires (A “RFT” or “DSST” mark is molded on the sidewall)
Take your vehicle to the nearest
Lexus dealer or authorized tire
dealer as soon as possible if any
tire goes flat.
The vehicle can be driven for a
maximum of 99 miles (160 km) at a
speed below 50 mph (80 km/h)
after the tire pressure warning light
comes on. (P. 4 9 7 )
■In some conditions (such as at high temperatures)
You cannot continue driving fo r up to 99 miles (160 km).
■For the detailed information on run-flat tires
See the tire warranty booklet.
■When replacing the tires
P. 5 1 0
If you have a flat tire (vehicles with run-flat
tires)
Your vehicle is not equipped with a spare tire, but instead you can con-
tinue driving the vehicle with run-flat tires even if any tire goes flat.
In this case, slow down and drive with extra caution.

5167-2. Steps to take in an emergency
LS600hL_U(OM50E41U)
■Location of the jack and toolsLift up the handle and fold the trunk floor back. ( P. 3 74 )
Remove the tool tray cover.
Jack handle
Towing eyelet
Parking brake release tool
Jack*
Screwdriver
Wheel nut wrench
*: Use of the jack ( P. 5 1 0 )
NOTICE
■When replacing the tires
When removing or fitting the wheels, tire s or the tire pressure warning valve and
transmitter, contact your Lexus dealer as the tire pressure warning valve and trans-
mitter may be damaged if not handled correctly.
■When driving over bumps
If a vehicle has a flat tire, the vehicle height will be lower than usual. Ensure that
nothing strikes the bottom of the vehicle.
■To avoid damage to the tire pressu re warning valves and transmitters
When a tire is repaired with liquid seal ants, the tire pressure warning valve and
transmitter may not operate properly. If a liquid sealant is used, contact your Lexus
dealer or other qualified service shop as soon as possible. Make sure to replace
the tire pressure warning valve and transmitter when replacing the tire. ( P. 455)
1
2
1
2
3
4
5
6

5217-2. Steps to take in an emergency
7
When trouble arises
LS600hL_U(OM50E41U)
Remove the plug.
Insert the tool and press it down
firmly while turning it counter-
clockwise until it stops.
Vehicles with run-flat tires
Take out the parking brake release tool and the screwdriver from the
trunk. ( P. 5 1 6 )
Check that the flathead end of
the screwdriver is exposed.
If the Phillips end is exposed, reinsert
the screwdriver shaft so the flathead
end is exposed.
4
5
1
Phillips end
Flathead end
2

5237-2. Steps to take in an emergency
7
When trouble arises
LS600hL_U(OM50E41U)
Insert the tool and press it down
firmly while turning it counter-
clockwise until it stops.
■When installing the tool tray cl ips (vehicles with run-flat tires)
■Manual operation of the parking brake
The parking brake cannot be set manually.
7
CAUTION
■When releasing the parking brake manually
●Shift the shift lever to P, turn the power switch off and chock the tires.
Failure to do so may cause the vehicle to move, resulting in an accident.
●Turn the power switch off and check that the parking brake indicator is off.
Failure to do so may cause the system to operate and turn the inserted parking
brake release tool, resulting in an injury.
Install the clips as shown in the illustration.
