2015 LEXUS LS600H light

3775-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
■To prevent 12-volt battery discharge
If the vanity lights remain on when the power switch is turned off, the lights will go off
automatically after 20 minutes.
NOTICE
■When not in use
Keep the rear vanity mirror closed.
■To prevent the 12-volt battery from being discharged
Do not leave the vanity lights on for extended periods while the hybrid system is off.

3805-6. Other interior features
LS600hL_U(OM50E41U)
Front
Push the back part of the lid to open,
and push the cigarette lighter down.
The cigarette lighter will pop up when
it is ready for use.
Rear (5-seat models)
Push the cigarette lighter.
The cigarette lighter will pop out when
it is ready for use.
Rear (4-seat models)
Open the auxiliary box and push the
cigarette lighter.
The cigarette lighter will pop out when
it is ready for use.
Cigarette lighters
: If equipped

3815-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
■The cigarette lighter can be used when
The power switch is in ACCESSORY or ON mode.
CAUTION
■To avoid burns or fires
●Do not touch the metal parts of the cigarette lighter.
●Do not hold the cigarette lighter down. It could overheat and cause a fire.
●Do not insert anything other than the cigarette lighter into the outlet.
■When not in use
Keep the ashtray closed.
Injuries may result in the event of an accident or sudden braking.

3855-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
Automatic operation
Operates automatically according
to the outside and cabin tempera-
ture when the power switch is
turned to ON mode. Automatic
operation can be turned off using
the switch.
The indicator light comes on when the
heater is operating.
Manual operation
Turns the heated steering wheel on/
off.
The indicator light comes on when the
heater is operating.
■Operating condition
The power switch is in ON mode.
■Timer function
Manual operation: Turns off after approximately 30 minutes.
Automatic operation: Operates for a maximum of 30 minutes. (Turns off according
to outside and cabin temperature.)
■If the indicator light does not come on
If the indicator light does not come on when the switch is pressed, a malfunction may
have occurred in the system. Have the vehicle inspected by your Lexus dealer.
■Customization
The automatic turning on/off of the heated steering wheel can be customized.
(Customizable features P. 5 6 4 )
Heated steering wheel
The left and right grip portions of the steering wheel can be heated.

4035-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
The garage door opener (HomeLink Universal Transceiver) is manufac-
tured under license from HomeLink
.
The HomeLink
 compatible transceiver in your vehicle has 3 buttons
which can be programmed to operate 3 different devices. Refer to the
programming method below appropriate for the device.
Indicator
Buttons
■Programming the HomeLink (for U.S.A. owners)
Point the remote control trans-
mitter for the device 1 to 3 in.
(25 to 75 mm) from the
HomeLink
 control buttons.
Keep the HomeLink indicator
light in view while programming.
Garage door opener
The garage door opener can be programmed to operate garage doors,
gates, entry doors, door locks, home lighting systems, security systems,
and other devices.
Programming the HomeLink®
1
2
1

4045-6. Other interior features
LS600hL_U(OM50E41U)
Press and hold one of the
HomeLink
 buttons and the
transmitter button. When the
HomeLink
 indicator light
changes from a slow to a rapid
flash, you can release both but-
tons.
If the HomeLink indicator light
comes on but does not flash, the
HomeLink
 button is already
programmed. Use the other but-
tons or follow the “Reprogram-
ming a HomeLink
 button”
instructions. ( P. 4 0 7 )
The remote control transmitter is
of the rolling code type if the
HomeLink
indicator light
flashes rapidly for 2 seconds and
then remains lit. If your transmitter
is of the rolling code type, pro-
ceed to the heading “Program-
ming a rolling code system”.
2

4055-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
Test the HomeLink operation
by pressing the newly pro-
grammed button.
If a HomeLink button has been
programmed for a garage door,
check to see if the garage door
opens and closes. If the garage
door does not operate, see if your
remote control transmitter is of
the rolling code type. Press and
hold the programmed
HomeLink
 button. The remote
control transmitter is of the rolling
code type if the HomeLink
indi-
cator light flashes rapidly for 2
seconds and then remains lit. If
your transmitter is of the rolling
code type, proceed to the head-
ing “Programming a rolling code
system”.
Repeat the steps above to progra m another device for each of the
remaining HomeLink
 buttons.
■Programming a Rolling Code system (for U.S.A. owners)
If your device is Rolling Code equi pped, follow the steps under the
heading “Programming the HomeLink
” before proceeding with the
steps listed below.
Locate the learn button on the ce iling mounted garage door opener
motor. The exact location and color of the button may vary by brand
of garage door opener motor.
Refer to the operation manual supplied with the garage door opener for the
location of the learn button.
Press the learn button.
Following this step, you have 30 seconds in which to initiate step 3 below.
3
4
1
2

4065-6. Other interior features
LS600hL_U(OM50E41U)
Press and hold the vehicle’s programmed HomeLink button for 2
seconds and release it. Repeat this step once again. The garage door
may open.
If the garage door opens, the programming process is complete. If the door
does not open, press and release the button a third time. This third press
and release will complete the programming process by opening the
garage door.
The ceiling mounted garage door open er motor should now recognize the
HomeLink
 signal and operate the garage door.
Repeat the steps above to program another rolling code system for
any of the remaining HomeLink
 buttons.
■Programming an entry gate (for U.S.A. owners)/Programming all
devices in the Canadian market
Place your transmitter 1 to 3 in. (2 5 to 75 mm) away from the surface
of the HomeLink
.
Keep the HomeLink indicator light in view while programming.
Press and hold the selected HomeLink button.
Repeatedly press and release (c ycle) the device’s remote control
button for two seconds each until step 4 is completed.
When the indicator light on the HomeLink
 compatible transceiver
starts to flash rapidl y, release the buttons.
Test the operation of the HomeLink
 by pressing the newly pro-
grammed button. Check to see if the gate/device operates correctly.
Repeat the steps above to progra m another device for each of the
remaining HomeLink
 buttons.
■Programming other devices
To program other devices such as home security systems, home door
locks or lighting, contact your Lexus dealer for assistance.
■Reprogramming a button
The individual HomeLink
 buttons cannot be erased but can be repro-
grammed. To reprogram a button, follow the “Reprogramming a
HomeLink
 button” instructions.
3
4
1
2
3
4
5
6
