2015 Lexus ES300h Navigation Manual

280
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44
2. MOBILE ASSISTANT OPERATION
1. MOBILE ASSISTANT
1Press and hold this switch until you hear
the beeps.
2The Mobile Assistant can be used only
when the following screen is displayed.
zTo cancel the Mobile Assistant, select
“Cancel” , or press and hold the on the
steering wheel.
z To restart the Mobile Assistant for addi-
tional commands, press the on the
steering wheel.
• Mobile Assistant can only be restarted
after the system responds to a voice com-
mand. • After some phone and music commands,
the Mobile Assistant feature will automat-
ically end to complete the requested
action.
The Mobile Assistant feature will
activate Apple’s Siri® Eyes Free mode
via the steering wheel switches. To
operate the Mobile Assistant, a
compatible cellular phone must be
registered and connected to this system
via Bluetooth
®. ( → P.48)
zThe volume of the Mobile Assistant can
be adjusted using the “PWR
·VO L” knob
or steering wheel volume control
switches. The Mobile Assistant and
phone call volumes are synchronized.
INFORMATION
● The available features and functions may
vary based on the iOS version installed
on the connected device.
● Some Siri features are limited in Eyes
Free mode. If you attempt to use an
unavailable function, Siri will inform you
that the function is not available.
● If Siri is not enable d on the cellular phone
connected via Bluetooth
®, an error mes-
sage will be displayed on the screen.
● While a phone call is active, the Mobile
Assistant cannot be used.
● If using the navigation feature of the cellu-
lar phone, ensure the active audio source
is Bluetooth
® audio or iPod in order to
hear turn by turn direction prompts.

281
2. MOBILE ASSISTANT OPERATION
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44
VOICE COMMAND SYSTEM
5
MICROPHONE
It is not necessary to speak directly into
the microphone when using the Mobile
Assistant. (Microphone location:
→ P.266)
INFORMATION
●Wait for the listening beeps before using
the Mobile Assistant.
● The Mobile Assistant may not recognize
commands in the following situations:
• Spoken too quickly.
• Spoken at a low or high volume.
• The roof or windows are open.
• Passengers are talking while the Mobile
Assistant is being used.
• The air conditioning speed is set high.
• The air conditioning vents are turned toward the microphone.

282
2. MOBILE ASSISTANT OPERATION
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44

6
283
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44
1
2
3 4
5
6
7
8 9
1. RECEIVING DOPPLER WEATHER INFORMATION .................................. 284
DISPLAYING DOPPLER WEATHER
INFORMATION ................................................. 284
2. DATA SERVICES SETTINGS ............. 286
SETTING DOWNLOAD METHODS ........ 286
1INFORMATION DISPLAY
INFORMATION

284
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44
1. INFORMATION DISPLAY
1. RECEIVING DOPPLER WEATHER INFORMATION
1Press the “MENU” button on the
Remote Touch.
2Select “Info”.
3Select “Weather” .
4Check that the “Weather” screen is dis-
played.Doppler weather radar information can
be received via the HD Radio or by the
LEXUS App Suite application on a
Bluetooth
® phone. For details about the
LEXUS App Suite application: →P.359
DISPLAYING DOPPLER
WEATHER INFORMATION
No.Function
Select to display the weather of the
current location. ( →P.285)
Select to display the weather of a de-
sired location in the recently
checked locations list.
Select to display the weather of a de-
sired location in the national cities
list.
Select to display the weather of a de-
sired location in the other local cities
list.
Select to display Doppler weather
radar information over the map.

285
1. INFORMATION DISPLAY
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44
INFORMATION
6
1Display the “Weather” screen.
(→ P.284)
2Select “Current Weather” .
3Select the desired tab to be displayed.
X When the “Current” tab is selected
X When the “3 Day” tab is selected
zWhen a specific day is selected, weather
information for that day will be displayed.
X When the “6/12 Hour” tab is selectedDISPLAYING THE WEATHER
OF THE CURRENT LOCATION
INFORMATION
●
If weather is set to the home screen, the
weather screen of the current location
will be displayed.

286
1. INFORMATION DISPLAY
ES350/300h_Navi_OM33B43U_(U)14.06.23 09:44
2. DATA SERVICES SETTINGS
1Press the “MENU” button on the
Remote Touch.
2Select “Setup” .
3Select “Data Services Settings” .
4Select the desired item to be set.
zSelect a checkbox on the right to set.
SETTING DOWNLOAD
METHODS
Data service information, which is com-
prised of traffic information and weather
information, can be received via the HD
Radio and by the LEXUS App Suite ap-
plication on a Bluetooth
® phone. The
receiving method can be set to both or
only via the HD Radio. For details about
the LEXUS App Suite application:
→ P.359
No.Function
Select to receive data service infor-
mation via both the HD Radio and
the LEXUS App Suite application on
a Bluetooth
® phone. When both
methods are available, the HD Radio
will be selected.
Select to receive data only via the
HD Radio.

7
287
ES350/300h_Navi_OM33B43U_(U)14.06.20 10:12
1
2
3 4
5
6
7
8 9
1. LEXUS PARKING ASSIST MONITOR ............................................. 288
LEXUS PARKING ASSIST MONITOR...... 288
DRIVING PRECAUTIONS .............................. 288
SCREEN DISPLAY ............................................... 290
USING THE SYSTEM ............................................ 291
2. ESTIMATED COURSE LINE DISPLAY MODE ................................. 293
SCREEN DESCRIPTION .................................. 293
PARKING .................................................................. 294
3. PARKING ASSIST GUIDE LINE DISPLAY MODE ................................. 295
SCREEN DESCRIPTION .................................. 295
PARKING .................................................................. 296
4. LEXUS PARKING ASSIST MONITOR PRECAUTIONS .......... 297
AREA DISPLAYED ON SCREEN ................. 297
THE CAMERA ........................................................ 298
DIFFERENCES BETWEEN THE SCREEN
AND THE ACTUAL ROAD ......................... 299
WHEN APPROACHING THREE-DIMENSIONAL OBJECTS......... 300
5. THINGS YOU SHOULD KNOW .... 302
IF YOU NOTICE ANY SYMPTOMS.......... 302
1LEXUS PARKING ASSIST
MONITOR
PERIPHERAL MONITORING SYSTEM
