Page 105 of 114
MOTORCYCLE CARE AND STORAGE7-5
7
e. Remove the spark plug caps
from the spark plugs, and then
install the spark plugs and the
spark plug caps.
4. Lubricate all control cables and the pivoting points of all levers and
pedals as well as of the side-
stand/centerstand.
5. Check and, if necessary, correct the tire air pressure, and then lift
the motorcycle so that both of its
wheels are off the ground. Alterna-
tively, turn the wheels a little every
month in order to prevent the tires
from becoming degraded in one
spot.
6. Cover the muffler outlets with plastic bags to prevent moisture
from entering them.
7. Remove the battery and fully charge it. Store it in a cool, dry
place and charge it once a month.
Do not store the battery in an ex-
cessively cold or warm place [less
than 0 °C (30 °F) or more than 30
°C (90 °F)]. For more information
on storing the battery, see page
6-32.
TIPMake any necessary repairs before
storing the motorcycle.
U2SGE0E0.book Page 5 Wednesday, June 12, 2013 1:15 PM
Page 106 of 114
SPECIFICATIONS
8-1
8
Dimensions:Overall length:2070 mm (81.5 in)
Overall width:
715 mm (28.1 in)
Overall height: 1130 mm (44.5 in)
Seat height: 835 mm (32.9 in)
Wheelbase:
1415 mm (55.7 in)
Ground clearance: 135 mm (5.31 in)
Minimum turning radius: 3500 mm (137.8 in)Wei ght:Curb weight:
206 kg (454 lb)Engine:Engine type:
Liquid cooled 4-stroke, DOHC
Cylinder arrangement: Inline 4-cylinder
Displacement: 998 cm³
Bore × stroke:
78.0 × 52.2 mm (3.07 × 2.06 in)
Compression ratio: 12.70 : 1
Starting system: Electric starter
Lubrication system:
Wet sump
Engine oil:Recommended brand:
YAMALUBE
Type:
SAE 10W-40, 10W-50, 15W-40, 20W-40 or
20W-50
Recommended engine oil grade: API service SG type or higher, JASO
standard MA
Engine oil quantity:
Without oil filter cartridge replacement: 3.73 L (3.94 US qt, 3.28 Imp.qt)
With oil filter cartridge replacement:
3.93 L (4.15 US qt, 3.46 Imp.qt)Coolin g system:Coolant reservoir capacity (up to the
maximum level mark):
0.25 L (0.26 US qt, 0.22 Imp.qt)
Radiator capacity (including all routes): 2.73 L (2.89 US qt, 2.40 Imp.qt)Air filter:Air filter element:Oil-coated paper element
Fuel:Recommended fuel:Premium unleaded gasoline (Gasohol (E10)
acceptable)
Fuel tank capacity: 18.0 L (4.76 US gal, 3.96 Imp.gal)
Fuel reserve amount:
3.1 L (0.82 US gal, 0.68 Imp.gal)Fuel injection:Throttle body:ID mark: 1KB8 00Spark plu g(s):Manufacturer/model:
NGK/LMAR9E-J
Spark plug gap: 0.6–0.7 mm (0.024–0.028 in)Clutch:Clutch type:
Wet, multiple-discTransmission:Primary reduction ratio:1.512 (65/43)
Final drive:
Chain
Secondary reduction ratio: 2.765 (47/17)
Transmission type: Constant mesh 6-speed
Operation:
Left foot operation
Gear ratio: 1st:
2.533 (38/15)
–20 –10 0 1020 30 40 50 C
10 30 50 70 90 110
0 130 F
SAE 20W-50SAE 20W-40SAE 15W-40SAE 10W-40SAE 10W-50
U2SGE0E0.book Page 1 Wednesday, June 12, 2013 1:15 PM
Page 107 of 114
SPECIFICATIONS
8-2
8
2nd:2.063 (33/16)
3rd: 1.762 (37/21)
4th:
1.522 (35/23)
5th: 1.364 (30/22)
6th: 1.269 (33/26)
Chassis:Frame type:Diamond
Caster angle: 24.00 °
Trail:
102 mm (4.0 in)Front tire:Type:Tubeless
Size:
120/70 ZR17M/C (58W)
Manufacturer/model: MICHELIN/POWER PURE A
Manufacturer/model: DUNLOP/Qualifier IIRear tire:Type: Tubeless
Size: 190/55 ZR17M/C (75W)
Manufacturer/model:
MICHELIN/POWER PURE Manufacturer/model:
DUNLOP/Qualifier II
Loa din g:Maximum load:
189 kg (417 lb)
(Total weight of rider, passenger, cargo
and accessories)Tire air pressure (measure d on col d
tires):Loading condition:
0–90 kg (0–198 lb)
Front:250 kPa (2.50 kgf/cm², 36 psi)
Rear:
290 kPa (2.90 kgf/cm², 42 psi)
Loading condition: 90–189 kg (198–417 lb)
Front:250 kPa (2.50 kgf/cm², 36 psi)
Rear:
290 kPa (2.90 kgf/cm², 42 psi)
High-speed riding: Front:
250 kPa (2.50 kgf/cm², 36 psi)
Rear: 290 kPa (2.90 kgf/cm², 42 psi)Front wheel:Wheel type:
Cast wheel
Rim size: 17M/C x MT3.50Rear wheel:Wheel type:
Cast wheel Rim size:
17M/C x MT6.00
Front brake:Type:
Dual disc brake
Operation: Right hand operation
Specified brake fluid: DOT 4Rear brake:Type:
Single disc brake
Operation: Right foot operation
Specified brake fluid:
DOT 4Front suspension:Type:Telescopic fork
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel: 120.0 mm (4.72 in)Rear suspension:Type:
Swingarm (link suspension)
Spring/shock absorber type: Coil spring/gas-oil damper
Wheel travel: 120.0 mm (4.72 in)Electrical system:Ignition system:TCI
U2SGE0E0.book Page 2 Wednesday, June 12, 2013 1:15 PM
Page 108 of 114
SPECIFICATIONS
8-3
8
Charging system:AC magnetoBattery:Model:
YTZ10S
Voltage, capacity: 12 V, 8.6 AhHea dlig ht:Bulb type:
Halogen bulbBul b volta ge, watta ge × quantity:Headlight:
12 V, 55.0 W × 2
Tail/brake light:
LED
Front turn signal light: 12 V, 10.0 W × 2
Rear turn signal light: 12 V, 10.0 W × 2
Auxiliary light:
LED
License plate light: 12 V, 5.0 W × 1
Meter lighting: LED
Neutral indicator light:
LED
High beam indicator light: LED
Oil level warning light: LED
Turn signal indicator light:
LED Fuel level warning light:
LED
Coolant temperature warning light: LED
Engine trouble warning light:
LED
Immobilizer system indicator light: LED
Shift timing indicator light: LED
Traction control system indicator/warning
light: LED
Fuses:Main fuse:50.0 A
Headlight fuse: 20.0 A
Signaling system fuse:
7.5 A
Ignition fuse: 15.0 A
Radiator fan fuse: 10.0 A × 2
Turn signal light fuse:
7.5 A
Fuel injection system fuse: 15.0 A
Steering damper fuse: 7.5 A
Backup fuse:
7.5 A
Electronic throttle valve fuse: 7.5 A
U2SGE0E0.book Page 3 Wednesday, June 12, 2013 1:15 PM
Page 109 of 114
CONSUMER INFORMATION
9-1
9
EAU48613
Id entification num bersRecord the vehicle identification num-
ber and model label information in the
spaces provided below for assistance
when ordering spare parts from a
Yamaha dealer or for reference in case the vehicle is stolen.
VEHICLE IDENTIFICATION NUMBER:
MODEL LABEL INFORMATION:
EAU26401
Vehicle i dentification num ber
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.TIPThe vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area.
EAU26521
Mo del la bel
The model label is affixed to the frame
under the passenger seat. (See page
3-27.) Record the information on this
label in the space provided. This infor-
mation will be needed when ordering
spare parts from a Yamaha dealer.
1. Vehicle identification number
1
1. Model label
1
U2SGE0E0.book Page 1 Wednesday, June 12, 2013 1:15 PM
Page 110 of 114
INDEXAAir filter element .................................... 6-17
Auxiliary light......................................... 6-38BBattery .................................................. 6-32
Brake and clutch levers, checking and lubricating ........................................... 6-29
Brake and shift pedals, checking and lubricating ........................................... 6-28
Brake fluid, changing ............................ 6-25
Brake fluid level, checking .................... 6-24
Brake lever ............................................ 3-21
Brake lever free play, checking............. 6-22
Brake light switches.............................. 6-23
Brake pedal........................................... 3-22CCables, checking and lubricating ......... 6-27
Care ........................................................ 7-1
Catalytic converter ................................ 3-27
Clutch lever ........................................... 3-20
Clutch lever free play, adjusting ........... 6-21
Coolant ................................................. 6-14
Coolant temperature warning light ......... 3-5
Cowlings, removing and installing .......... 6-8DDimmer switch ...................................... 3-19
D-mode (drive mode) ............................ 3-18
Drive chain, cleaning and lubricating .... 6-27
Drive chain slack................................... 6-25EEngine break-in....................................... 5-3
Engine idling speed, checking .............. 6-17
Engine oil and oil filter cartridge ........... 6-11
Engine stop switch ............................... 3-19 Engine trouble warning light ................... 3-7
FFront and rear brake pads, checking ... 6-23
Front fork, adjusting ............................. 3-31
Front fork, checking ............................. 6-30
Fuel ....................................................... 3-25
Fuel consumption, tips for reducing ...... 5-3
Fuel level warning light ........................... 3-4
Fuel tank breather hose and overflow
hose ................................................... 3-26
Fuel tank cap ........................................ 3-24
Fuses, replacing ................................... 6-33HHandlebar switches .............................. 3-18
Hazard switch....................................... 3-19
Headlight bulb, replacing ..................... 6-35
Helmet holder ....................................... 3-29
High beam indicator light ....................... 3-4
Horn switch .......................................... 3-19IIdentification numbers ............................ 9-1
Ignition circuit cut-off system ............... 3-36
Immobilizer system ................................ 3-1
Immobilizer system indicator light .......... 3-8
Indicator lights and warning lights ......... 3-4LLicense plate light bulb, replacing........ 6-37
Luggage strap holders ......................... 3-35MMain switch/steering lock....................... 3-2
Maintenance and lubrication, periodic ... 6-4
Maintenance, emission control system.................................................. 6-3
Matte color, caution ............................... 7-1 Model label .............................................9-1
Multi-function meter unit .........................3-8
NNeutral indicator light ..............................3-4OOil level warning light ..............................3-4PParking ....................................................5-4
Part locations ..........................................2-1
Pass switch ...........................................3-19RRear view mirrors ..................................3-30
Rider footrest position, adjusting ..........3-30SSafety information ...................................1-1
Seats .....................................................3-27
Shifting ....................................................5-2
Shift pedal .............................................3-21
Shift timing indicator light .......................3-7
Shock absorber assembly, adjusting ....3-33
Sidestand ..............................................3-35
Sidestand, checking and lubricating.....6-29
Spark plugs, checking ..........................6-10
Specifications .........................................8-1
Starting the engine ..................................5-1
Start switch ...........................................3-19
Steering, checking ................................6-31
Storage ...................................................7-4
Storage compartment ...........................3-29
Supporting the motorcycle ...................6-38
Swingarm pivots, lubricating ................6-30TTail/brake light ......................................6-36
U2SGE0E0.book Page 1 Wednesday, June 12, 2013 1:15 PM
Page 111 of 114
INDEX
Throttle grip and cable, checking and lubricating........................................... 6-28
Throttle grip free play, checking ........... 6-18
Tires ...................................................... 6-18
Tool kit .................................................... 6-2
Traction control system ........................ 3-22
Traction control system indicator/ warning light ......................................... 3-7
Traction control system switch ............ 3-19
Troubleshooting.................................... 6-39
Troubleshooting charts......................... 6-40
Turn signal indicator lights ..................... 3-4
Turn signal light bulb, replacing ........... 6-36
Turn signal switch................................. 3-19VValve clearance .................................... 6-18
Vehicle identification number ................. 9-1WWheel bearings, checking .................... 6-31
Wheels .................................................. 6-21
U2SGE0E0.book Page 2 Wednesday, June 12, 2013 1:15 PM
Page 112 of 114
A5-yoko_Blank.fm Page 1 Thursday, December 8, 2011 2:18 PM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
