Folding the rear seat backrest forward and back into place

Fig. 97 Folding the backrest forward and back.

WARNING
Improper folding and improper latching of the rear seat backrest can cause serious personal injury.
x Always make sure there are no people or animals in the area around the rear seat backrest when folding it forward.
x Never fold the rear seat backrest up or down while the vehicle is moving.
x When folding the rear seat backrest back up, make sure that the safety belt does not get caught or damaged.
x Keep hands, fingers, feet and other body parts out of the away when folding the rear seat backrest up and down.
x Each rear seat backrest must be securely latched into place in the upright position so that the safety belts on the rear seats can provide protection. This is particularly the case for the middle seat on the rear bench.
x If a seat is used with an unsecured backrest, the passenger will move forward together with the rear seat backrest during sudden braking, driving maneuvers, or a collision.
x No one, including children, may ride on the rear seats if the rear seat backrest is folded down or not correctly latched.
NOTICE
Before folding the rear seat backrest forward, adjust the front seats so that the rear seat's head restraint or backrest cushion will not touch the front seats.
NOTICE
Items in the luggage compartment could be damaged or cause damage when the rear seat is adjusted in the fore and aft direction.
Removing and reinstalling the rear seat

Fig. 98 Front attachment of the rear seat.

Fig. 99 Rear attachment of the rear seat.

4. Secure both seat rails of the rear seat in front and back with 2 hexagonal nuts each, tightening the nuts by hand - do not tighten them with the lug wrench yet.
5. Lift the right rear seat into the vehicle through the right rear door.
6. Set the seat rails of the rear seat first on the front anchoring studs and then on the rear studs.
7. Secure both seat rails of the rear seat in front and back with 2 hexagonal nuts each, tightening the nuts by hand - do not tighten them with the lug wrench yet.
8. To align the seat rails, press the left rear seat all the way to the left in the vehicle.
9. To align the seat rails, press the right rear seat all the way to the right in the vehicle.
10. Tighten the hexagonal nuts in the luggage compartment (arrows) to 44 ft-lbs (60 Nm) using a torque wrench. If no torque wrench is available, tighten the hexagonal nuts using the lug wrench and have the torque checked at a qualified workshop as soon as possible.
11. Push the rear seats as far back as possible ⇒ Adjusting the rear seat.
12. Remove the hexagonal nuts in the rear of the footwell again, set the 3 plastic covers ⇒ fig. 98 on the studs and screw on with the hexagonal nuts.
13. Tighten the hexagonal nuts (arrows) to 44 ft-lbs (60 Nm) using a torque wrench. If no torque wrench is available, tighten the hexagonal nuts using the lug wrench and have the torque checked at a qualified workshop as soon as possible.
14. Clip on the small covers (not pictured) on the hexagonal nuts (arrows).
15. Install the foam insert and spare wheel in the vehicle ⇒ Compact spare wheel.
16. Install the luggage compartment floor ⇒ Variable luggage compartment floor.
17. Install the luggage compartment cover ⇒ Luggage compartment cover.
18. Install all rear head restraints ⇒ Adjusting the seating position.
WARNING
No one may ride in the back of the vehicle when the rear seat has been removed.
WARNING
An improperly installed rear seat can separate from its mountings during an accident.
x All securing bolts must be tightened to the specified torque after the rear seat has been installed.
CAUTION
Sharp-edged parts are located on the underside of the rear seat.
x Protect your hands when you lift the rear seat in or out.
NOTICE
x Have at least one person help to lift the rear seat in or out. One person should be in the vehicle and one outside.

x The lever ⇒ fig. 44 for the fore and aft adjustment of the rear seat must not be operated while the seat is removed. If the position of the fore and aft adjustment is changed, the rear seat can only be installed by a qualified workshop.
Luggage compartment cover

Fig. 100 Installing and removing the luggage compartment cover.

x Things on the luggage compartment cover can damage it.
x The defroster heating wires or antenna in the rear window can be damaged by objects that rub against them.
Do not cover the ventilation slots in the side consoles. Otherwise, stale air cannot escape from the vehicle.
Luggage compartment pass-through

Fig. 101 In the rear backrest: Opening the luggage compartment pass-through.

The pass-through can also be opened from the luggage compartment. Push down the release button (arrow) and push the center section of the rear seat backrest (pass-through) all the way forward.
Tie-downs

Fig. 102 In the luggage compartment: Tie-downs.

WARNING
Elastic straps have to be stretched when being attached to the tie-downs in the luggage compartment Hooks on elastic straps can cause serious personal injury if not handled properly and attached securely.
x Always protect eyes and face from injury from the hooks when attaching them to the vehicle and do not let them snap back and hit you.
x Always hold the hooks on elastic straps firmly when attaching to the vehicle and do not let them snap back and hit you.
x First attach hooks on the straps to the tie-downs at the rear seat backrest in the luggage compartment and then to the tie-downs near the loading edge of the luggage compartment. This way, if one of the hooks on the elastic straps snaps back, it will move away from you, decreasing the risk of personal injury.
The maximum load for the tie-downs is about 785 lbs. (356 kg).
For suitable ratchet straps and luggage stowage systems, please see an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
Shopping bag hooks

Fig. 103 In the luggage compartment: Shopping bag hooks.
