2014 VOLKSWAGEN TIGUAN Owners Manual

For your own safety and to reduce injuries in the event of sudden braking maneuvers or accidents, Volkswagen recommends the following seating positions:
Applies to all vehicle occupants:
x Adjust head restraints so that the upper edge of the head restraint is at least at eye level or higher.
Position the back of your head as close as possible to the head restraint ⇒ fig. 39 and ⇒ fig. 40.
x Push the head restraint completely down for short people, even if the top of the head is then below the upper edge of the head restraint.
x Tall people should pull the head restraint all the way up.
x Adjust the seat backrest angle to an upright position so that your back is in full contact with it when the vehicle is moving.
x Always keep both feet on the floor and in the footwell whenever the vehicle is moving.
x Always adjust and fasten safety belts properly ⇒ Safety belts.
Driver - Seat and steering wheel adjustment:
x Adjust the steering wheel so that there are at least 10 inches (25 cm) between the steering wheel
and your breast bone ⇒ fig. 39. When adjusting the proper distance to the steering wheel, grasp the top of the steering wheel with your elbows slightly bent.
x Always hold the steering wheel on the outside of the steering wheel rim with your hands at the 9 o'clock and 3 o'clock positions to help reduce the risk of personal injury if the driver's airbag inflates.
x Never hold the steering wheel at the 12 o'clock position or with your hands at other places inside the steering wheel rim or on the steering wheel hub. Holding the steering wheel the wrong way can cause serious injuries to the hands, arms, and head if the driver's airbag inflates.
x Adjust the steering wheel so that the steering wheel cover points at your chest and not at your face. Pointing the steering wheel toward your face decreases the ability of the driver's airbag to help protect you in a collision.
x Adjust the driver's seat so that you can easily push the pedals all the way to the floor while keeping your knee(s) slightly bent.
x Adjust the seat height so that the top point of the steering wheel can be reached.
x Always keep both feet in the footwell so that you are in control of the vehicle at all times.
Passenger - front seat adjustment:
x Push the passenger seat as far back as possible in order to ensure optimum protection if the airbag is deployed.

Manual controls on the driver and front passenger seats

Fig. 41 Controls on the left front seat.

Fig. 43 Lumbar support control.

NOTICE
To help prevent damage to electrical parts in the seat, do not kneel on the front seats or apply concentrated pressure to a small area of the seat or backrest.
If the vehicle battery is too weak, the electrical seat adjustment controls may not work.
Starting the engine stops seat adjustment.
When entering and exiting the vehicle, be careful not to come into contact with any switches that could change the seat adjustment.
Adjusting the rear seat

Fig. 44 Adjusting the rear seat.

Fig. 45 Adjusting the rear backrest.

Pull right or left lever upwards ⇒ fig. 44 and push the respective rear seat section forward or backward. Release the lever and lock the rear seat section by gently sliding it forward or backward.
Place one hand on the right or left rear backrest and pull the respective pull strap with the other hand
⇒ fig. 45. Move the rear backrest to the desired position by hand against the force of the spring. Release the pull strap and lock the rear backrest by gently tilting it forward or backward.
WARNING
Improper adjustment of the rear seat can cause accidents and severe injuries.
x Adjust the rear seat only when the vehicle is stopped, since the seat could otherwise move unexpectedly when the vehicle is moving.
x Adjust the rear seat only if no one is in the way.
x Always guide the backrest down by hand and never let it fall into place on its own.
NOTICE
Items in the luggage compartment could be damaged or cause damage when the rear seat is adjusted in the fore and aft direction.
x If the rear seat is in a forward position, items can get into the area between the seat and the luggage compartment floor. When you slide the rear seat back again, make sure that the area behind the seat is clear of objects.
Adjusting front and rear head restraints

Fig. 46 Adjusting the front head restraints.

Fig. 47 Adjusting or folding the rear head restraints.

WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the risk of neck injury in a crash.
x Every person in the vehicle must have a properly adjusted head restraint to minimize the risk of neck injury in a crash. Each head restraint must be adjusted according to the occupants' size so that the upper edge is even with the top of the person's head, but no lower than eye level. Always sit so that the back of your head is as close as possible to the head restraint.
x Never adjust head restraint while driving.
Removing and reinstalling head restraints

Fig. 48 Removing the front head restraints.

Fig. 49 Removing the rear head restraints.

Removing the front head restraints
x Sit in the back seat behind the head restraint you want to remove. Pull the head restraint all the
way up ⇒ in Adjusting front and rear head restraints. Recline the backrest with the head restraint so that there is enough overhead clearance to remove it.
x Slide a flat object, such as a plastic credit card, underneath the right side of the cap on the right-
hand seat guide rod ⇒ fig. 48 (2) to unlock the head restraint.
x Use one hand to hold the release button in with the flat object. With your other hand, lift the same guide rod slightly to expose a notch in the rod at the bottom (can be seen and felt with fingers). The right-hand guide rod is now released.
x To release the left-hand guide rod, press button (1) in (towards guide rod) and hold.
x Pull the head restraint out completely while holding button (1).
Installing the front head restraints
x Position head restraint properly over the head restraint guides of the respective seat backrest and insert the head restraint into the guides.
x Push the head restraint down while pressing button (1) or ⇒ fig. 49 (1).
x Adjust the head restraint according to the occupant's size ⇒ Adjusting front and rear head restraints.
Removing the rear head restraint
x Unlock the rear bench and fold it forward ⇒ Luggage compartment.
x Pull the head restraint all the way up ⇒ .
x Slide a flat object, such as a plastic credit card, underneath the right side of the cap on the right-hand seat guide rod (2) to unlock the head restraint.
x Use one hand to hold the release button in with the flat object. With your other hand, lift the same guide rod slightly to expose a notch in the rod at the bottom (can be seen and felt with fingers). The right-hand guide rod is now released.
x To release the left-hand guide rod, press button (1) in (towards guide rod) and hold.
x Pull the head restraint out completely while holding button (1).
x Fold the backrest of the rear bench back so that it locks securely.
Reinstalling the rear head restraint
x Unlock the rear bench and fold it forward ⇒ Luggage compartment.
x Position head restraint properly over the head restraint guides of the respective seat backrest and insert the head restraint into the guides.
x Push the head restraint down while pressing button (1).
x Fold the backrest of the rear bench back so that it locks securely.
x Adjust the head restraint according to the occupant's size ⇒ Adjusting front and rear head restraints.
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the risk of neck injury in crash.
x Always reinstall head restraints as soon as possible so that vehicle occupants are properly protected.
