2014 VOLKSWAGEN TIGUAN Owners Manual

“Leaving home” Operation
Switch off:
– Automatically after preset delay period is over. – Lock the vehicle. – Turn the light switch to the / position. – Switch the ignition on.

Background lighting in the outside mirrors
The background lighting in the outside mirrors lights up the area close to the doors while you are getting into or out of the vehicle. It is switched on when the vehicle is unlocked, a vehicle door is opened, or the “Coming home” or “Leaving home” feature is activated. If the vehicle is equipped with a light sensor, the background lighting in the outside mirrors is only switched on in darkness.
The delay period can be adjusted and the feature can be switched on and off in the Lights &
Vision menu ⇒ Volkswagen Information System.
If the “Coming home” feature is switched on and the driver door is opened, no acoustic chime will sound to alert you that the lights are still on.
Instrument panel lighting and headlight range adjustment

Fig. 85 Next to the headlight switch: Control for instrument cluster lighting.

WARNING
Headlights that are aimed too high because of the way the vehicle is loaded can blind and distract other drivers. This can lead to a crash and serious personal injuries.
x Always adjust headlights to loading conditions so that they do not blind others.
Interior and reading lights

Sun protection

Windshield made of heat-insulating glass

Fig. 87 Heat-reflective windshield with communications window (blue shaded area).

Windshield wipers and washer

Lights up Possible cause Proper response
Y Not enough windshield washer fluid. Refill windshield washer reservoir at the next opportunity

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Windshield wiper lever

Fig. 88 Operating the front windshield wiper.

Fig. 89 Operating the rear wiper.

Move the lever to the desired position ⇒ :
(B) z
Intermittent wiping for the windshield.
Adjust the interval settings with switch ⇒ fig. 88 (1) (vehicles without rain sensors) or the sensitivity of the rain sensor (vehicles with rain sensors).
(C) ,/7 Slow wiper speed.
(D) ()'( Fast wiper speed.
(E) x One-tap wiping – brief wiping. Hold the lever pressed down longer to wipe more often.
(F) W Pull the lever toward the steering wheel to activate the windshield washers, then release.
(G) Z Intermittent wiping for the rear window. The wiper wipes about every 6 seconds.
(H) \ Press the lever forward as far as it will go to activate the rear window washers, then release.

NOTICE
x To help prevent damage to the wiper blades and the wiper motor when it is cold outside, always make sure that blades are not frozen to the windshield before operating the wipers. Using the service position can be helpful in cold weather so the wipers do not freeze to the
windshield ⇒ Windshield wiper service position.
x If the ignition is switched off while the wipers are running, the wipers will continue at the same wiping speed when the ignition is switched on again. Frost, ice, snow, leaves, and other objects on the windshield can damage the wipers and the wiper motor.
x Remove snow and ice from the wipers before you begin driving.
x If the wiper blades freeze to the windshield, loosen them carefully. Volkswagen recommends using a deicing spray.
NOTICE
Never switch on the windshield wipers when the windshield is dry because the windshield can be scratched.
The windshield wipers work only if the ignition is switched on and the engine hood is closed. The windshield wipers turn off automatically when the engine hood is opened. The rear windshield wipers turn off automatically when the rear hatch is opened.
If the front wipers are on, the rear wiper is switched on automatically when backing up.
If the windshield wiper lever is in the rear window intermittent wiping position ⇒ fig. 89 (G) when the ignition is switched off and back on or the engine is started, rear window wiper action does not resume until the windshield wipers are activated. This is to keep the wiper from working when the

window is dry. By switching rear window intermittent wiping off and then back on, you can override this feature and activate the rear window wiper immediately.
The intermittent wiping for the front windshield depends on the driving speed. The higher the speed, the faster the wipers move.
If the wiper blades freeze to the windshield, loosen them carefully. Volkswagen recommends using a deicing spray.
Windshield wiper functions
