2014 VOLKSWAGEN JETTA HYBRID Owners Manual

Changing the temperature unit on the factory-installed Radio or Radio & Navigation system display
The inside and outside temperatures can be displayed in either Fahrenheit (F) or Celsius (C).
Select Units in the instrument cluster display in the Settings main menu, Volkswagen Information System.
You can also press and hold the !

Air vents
To help ensure sufficient heating, cooling and ventilation in the passenger compartment, never close
the air vents completely ⇒ fig. 137 (1).
x To open and close the air vents, turn the respective thumbwheel (magnified view) in the desired direction. When the thumbwheel is in the ¡ position, the air vent is closed.
x Use the lever on the vent grille to adjust the airflow direction.
Additional, non-adjustable air vents are located in the instrument panel (2), in the footwells, as well as in the rear area of the passenger compartment.
NOTICE
Do not place food, medications, or other heat-sensitive things in front of the air vents. Food, medications, and other things that are sensitive to heat or cold can be damaged or made unusable by the air flow from the vents.
Air recirculation

x The cooling system is switched off, the outside air temperature is cooler than about +59 °F (+15 °C), and the windshield wiper is switched on.
Switching automatic air recirculation on and off
Switching on: Press the

Refueling

WARNING
Even if empty, portable fuel containers can leak and cause a fire and serious personal injuries, especially in a crash.
x For your safety, we strongly recommend that you do not travel with a portable fuel container in your vehicle.
x If, under exceptional circumstances, you must transport a portable fuel container, please observe the following:
– Never fill a portable fuel container while it is anywhere in or on the vehicle (for example, in the luggage compartment or on top of the luggage compartment lid). Static electricity can build up while filling and can ignite fuel vapors, causing a fire.
– Always place a portable fuel container on the ground before filling. Never spill fuel inside the vehicle or luggage compartment. Fuel vapors are highly flammable.
– Always keep the filler nozzle completely inside the portable container before and during filling.
– If filling a portable container made of metal, the filler nozzle must always be in contact with the container. This will help prevent static electricity from discharging and causing a fire.
– Always observe local and state or provincial laws about the use, storage, and transportation of portable fuel containers.
– Make certain that the portable fuel container meets industry standards, such as ANSI/ASTM F852-86.
NOTICE
x Remove fuel spills from the vehicle immediately to help prevent damage to the paint, tires, and wheel housings.
x Refueling with gasoline when your vehicle has a diesel engine or refueling with diesel fuel when your vehicle has a gasoline engine can cause very serious and expensive engine and fuel system damage that is not covered by any Volkswagen Limited Warranty.
x If you put any amount of incorrect fuel in the fuel tank, do not start the engine under any circumstances. Immediately contact the nearest authorized Volkswagen dealer or authorized Volkswagen Service Facility for assistance. These fuels contain substances that can severely damage the fuel system and the engine if the engine is started.
NOTICE
If the fuel tank venting system malfunctions and the fuel tank cannot be properly vented before refueling:
x Gasoline fumes can escape from the fuel filler neck, resulting in temporary odors.
x The fuel nozzle may shut off during refueling and it will take longer to refuel the vehicle. Only in this situation can you continue to carefully refuel your vehicle after the fuel nozzle shuts off.
x See your Authorized Volkswagen dealer or authorized Volkswagen Service Facility to have your vehicle checked.
Fuels can pollute the environment. Spilled fuel must be collected and disposed of properly, following all applicable environmental regulations.

There is no emergency release for the fuel filler flap. Contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Indicator lights and fuel gauge

Fig. 138 In the instrument cluster: Fuel gauge.

Fuel filler cap not properly closed

Refueling

Fig. 139 In the driver door: Release switch for the fuel filler flap.

Fig. 140 Fuel cap placed on the open fuel filler flap.
