2014 VOLKSWAGEN JETTA HYBRID Owners Manual

Front passenger side overview

Fig. 8 Overview of the front passenger side.
Key to fig. 8:
(1) Passenger front airbag location in the instrument panel (approximate)
(2) Opening handle for the glove compartment
(3) Air vent  –

Symbols on the roof console

Symbol Meaning
* / s  Interior and reading lights
g c h Power sunroof

/ a 3-button module (if equipped) ⇒ booklet Mobile Phone Package.

Instrument cluster

– While driving, the current hybrid driving power (in %) is displayed.
(3) Displays Displays. The hybrid power is displayed after the ignition is switched on, Starting and stopping the engine.
(4) Reset button for the trip odometer display (trip).
– Push the /./

x Outside temperature
x Hybrid drive information, Hybrid drive
x Open door, engine hood, or luggage compartment lid ⇒ fig. 11
x Selector lever position Shifting
x Multi-Function Indicator (MFI) and menus for different settings, Volkswagen Information System
x Service reminder display, Service reminder display
Warning and information texts
The status of various vehicle functions and components is monitored when the ignition is switched on and while driving. Malfunctions are indicated by red and yellow warning symbols with text messages in the instrument cluster display (Warning and indicator lights). In some cases, they may also be signaled acoustically. The display can vary depending on the instrument cluster model.

Type of notification Symbol color Explanation
Priority 1 warning message Red Symbol flashing or lit – sometimes with acoustic warnings.

x Extended electro-mode drive indicator E-MODE.
x Information and warnings.
x Visual display for the vehicle power sources (electric motor or combustion engine), and energy flow between these power sources, the drive wheels, and high-voltage battery.
Selector lever positions
The selector lever position is shown both on the side of the selector lever and in the instrument cluster display. The respective gear may also be shown in the instrument cluster display in Drive D and Sport Drive S, as well as in Tiptronic® mode.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Park the vehicle at a safe distance from moving traffic and where no part of the hot cata-lytic converter and exhaust system can come into contact with flammable materials under the vehicle, such as dry grass, brush, spilled fuel, etc.
x A broken down vehicle presents a high accident risk for itself and others. Switch on emergency flashers and set up a warning triangle to warn oncoming traffic.
WARNING
Roads and bridges may be dangerously icy even if the outside air temperature is above freez-ing.
x If you use the outside temperature display to tell you about frost conditions, remember that roads can even ice over at temperatures above +39 °F (+4 °C). Always remember: even if the “snowflake symbol” (icy road warning) is not displayed, there could still be black ice on the road.
x Never rely exclusively on the outside temperature display.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
The instrument cluster displays and their arrangement may vary depending on the vehicle model and engine. For displays without warning and information messages, malfunctions are only signaled with indicator lights.
If there are multiple warning messages, the symbols are displayed for several seconds in order of importance. The symbols are displayed until the cause has been corrected.
Service reminder display

For information on maintenance intervals, please see the ⇒ booklet Warranty and Maintenance.
For vehicles with time- or distance driven-dependent service, only fixed service intervals are dis-played.
Service reminder
If service is due in the near future, a service reminder is displayed when the ignition is switched on.
The messages Oil change and Inspection are shown in the instrument cluster display with the number of miles (km) and days remaining until service is due.
Service event
When service is due, the message Oil change now! or Inspection now! is shown in the instrument cluster display.
Viewing service message
The current service message can be accessed when the ignition is switched on, the engine is switched off, and the vehicle is stopped:
x Select the Settings menu.
x In the Service submenu, select the Info menu item.
x OR: If the Vehicle status main menu is active, use the arrow buttons to navigate to the service reminder display.
A message appears in the instrument cluster display when service is overdue.
Resetting the oil change service reminder
If the service was not performed by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility, the oil change service reminder can be reset as follows:

Switch off the ignition.
Press and hold the /./

The service reminder disappears after a few seconds or the OK button on the multi-function steering wheel has been pushed.
