2014 VOLKSWAGEN BEETLE CONVERTIBLE Owners Manual

Opening the luggage compartment lid from inside the luggage
compartment

Fig. 154 Inside the luggage compartment: Opening the luggage compartment lid.

Fig. 156 Convertible top emergency closing (2).

x Pull the convertible top down using the emergency handle and turn the handle clockwise until the convertible top latches completely and securely. The X indicator light goes out.
x Turn the screw in the center of the emergency handle counterclockwise to loosen using the Phillips head end of the screwdriver and remove the handle.
x Reinstall the front cover over the emergency lock opening.
x Put the hexagonal socket wrench, emergency handle, and screwdriver back into the vehicle tool kit
⇒ page 389, Vehicle tool kit.
x Drive to an authorized Volkswagen dealer or an authorized Volkswagen Service Facility to have the convertible top serviced. The bolts that were removed cannot be reused and must be replaced with
new bolts before the top can be opened again ⇒ .
WARNING
The wind generated by driving can open the convertible top if it is not latched. This can cause accidents and serious injuries.
x Never drive if the convertible top is not latched.
CAUTION
To help reduce the risk of personal injury, never touch moving parts when the convertible top is closing.
x Always be careful not to pinch your hands when closing the convertible top manually.
x Always be careful not to pinch yourself or others when pressing the convertible top onto the windshield frame.
NOTICE
To help prevent significant vehicle damage, do not operate the convertible top after performing the emergency closing procedure until the bolts are replaced with correct, new bolts by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Emergency release for the fuel filler flap

Emergency release for the selector lever lock

Fig. 157 Removing the selector gate cover.

Fig. 158 Releasing the selector lever lock.

x Carefully press the selector gate cover back in place, making sure that the electrical wiring stays in the correct position and is not pinched or damaged.
WARNING
Never shift the transmission out of Park (P) without first firmly applying the parking brake. Otherwise, the vehicle can start to roll unexpectedly, especially on hills or inclines, and cause an accident and serious injuries.
NOTICE
Even with the selector lever is in Neutral (N), the automatic transmission will be damaged if the vehicle is towed (or you let it coast) for an extended period or at high speed with the engine shut off.

Vehicle tool kit

Storage

Fig. 159 In the luggage compartment: Floor covering 1 folded back.

Contents of the vehicle tool kit ⇒ fig. 160
(1) Screwdriver with a hexagonal socket in the handle for removing or inserting previously loosened wheel bolts. The screwdriver blade is reversible. The screwdriver may be stored under the lug wrench. For vehicles with a subwoofer in the luggage compartment, the tool kit contains a Torx bit for the screwdriver. Use the screwdriver with the Torx bit to remove or install the subwoofer screws.
(2) Screw-in towing eye.
(3) Hubcap puller clip for removing hubcaps, wheel covers, or wheel bolt caps.
(4) Jack. Before putting the jack back in the foam insert, be sure to completely crank the jack down to its original position.
(5) Lug wrench.
(6) Crank.
(7) Hexagonal socket wrench for the convertible top emergency release.
(8) Emergency handle for latching the front of the convertible top.
