2014 VOLKSWAGEN BEETLE CONVERTIBLE Owners Manual

When the vehicle is not moving or when you are driving at very low speeds, the temperature displayed may be slightly higher than the actual outside temperature.
The measurement range is from -40 °F (-40 °C) to +122 °F (+50 °C).
Compass display (if applicable)
On vehicles equipped with compass display, the current compass direction is indicated in the instru-ment cluster display when the ignition and navigation system are switched on.
Selector lever positions
The selector lever position is shown both on the side of the selector lever and in the instrument cluster display. The respective gear may also be shown in the instrument cluster display in Drive D and Sport Drive S, as well as in Tiptronic® mode.
Gear recommendation
When the vehicle is moving, a fuel economy gear recommendation may appear in the instrument cluster display, Shifting.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Park the vehicle at a safe distance from moving traffic and where no part of the hot cata-lytic converter and exhaust system can come into contact with flammable materials under the vehicle, such as dry grass, brush, spilled fuel, etc.
x A broken down vehicle presents a high accident risk for itself and others. Switch on emergency flashers and set up a warning triangle to warn oncoming traffic.
WARNING
Roads and bridges may be dangerously icy even if the outside air temperature is above freez-ing.
x If you use the outside temperature display to tell you about frost conditions, remember that roads can even ice over at temperatures above +39 °F (+4 °C). Always remember: even if the “snowflake symbol” (icy road warning) is not displayed, there could still be black ice on the road.
x Never rely exclusively on the outside temperature display.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
The instrument cluster displays and their arrangement may vary depending on the vehicle model and engine. For displays without warning and information messages, malfunctions are only signaled with indicator lights.
If there are multiple warning messages, the symbols are displayed for several seconds in order of importance. The symbols are displayed until the cause has been corrected.

Service reminder display

Vehicles with Basic display:
Switch off the ignition.
Push the E

Volkswagen Information System

Menu structure – overview (Basic version)

– Oil temp.
– Coolant temp.
– Speed warning
– Back
▪ Time
– Hours
– Minutes
– 24 hr. mode
– Daylight save
– Back
▪ Units
– Temperature
– Consump./distance
– Back
▪ Service
– Info
– Back
▪ Factory setting
Using the instrument cluster menus

Fig. 17 In vehicles without a multi-function steering wheel: Use button 1 in the windshield wiper lever to confirm menu items and rocker switch 2 to switch menus.

Fig. 18 Right side of the multi-function steering wheel (if equipped): Controls for the menus in the instrument cluster.

If your vehicle does not have a multi-function steering wheel with menu controls, the instrument cluster
menus are controlled with buttons on the end of the windshield wiper lever (⇒ fig. 17). On vehicles with menu control multi-function steering wheels, the instrument cluster menus are controlled with buttons
on the right side of the steering wheel ⇒ fig. 18.
Accessing the instrument cluster menus
x Switch on the ignition.
x If a message or the vehicle icon is displayed, push the rocker switch (1) (⇒ fig. 17) on the end of
the windshield wiper lever or the OK button (⇒ fig. 18) on the right side of the multi-function steering wheel to display the main menus (on some vehicles, a list of main menus) in the instrument cluster display.
x For operation with windshield wiper lever: To show the main menu ,Main menus (Premium version)
or to go back to the main menu from another menu, press and hold the rocker switch ⇒ fig. 17 (2).
x For operation with multi-function steering wheel: To scroll through the various main menu items,
push the button # or ∃ several times ⇒ fig. 18.
Displaying a submenu
x Windshield wiper lever: Move up and down in a menu by pushing the top or bottom of rocker
switch (2) (⇒ fig. 17) until the menu item / selection you want is highlighted.
x Multi-function steering wheel: Press arrow buttons * or + until the menu item / selection you want is highlighted. Press and hold an arrow button to increase or decrease values faster.
Selecting a setting
x Windshield wiper lever: Press the /+
