2014 VOLKSWAGEN BEETLE CONVERTIBLE Owners Manual

Front passenger side overview

Fig. 9 Overview of the front passenger side.
Key to fig. 9:
(1) Passenger front airbag location in the instrument panel (approximate)
(2) Opening handle for the upper glove compartment (if equipped)
(3) Opening handle for the lower glove compartment
(4) Air vents  –

Symbols on the roof console

Fig. 11 In the roof console: Button for opening and closing the convertible top.

Symbol Meaning
*  /  Interior and reading lights
a
/ 3-button module (if equipped) ⇒ booklet Mobile Phone Package.

Instrument cluster

WARNING
Driving on today's roads demands the full attention of the driver at all times. Driver distrac-tion causes accidents, collisions and serious personal injury!
x Never set the stopwatch when the vehicle is moving.
NOTICE
To help prevent engine damage, always avoid high engine speeds, full throttle acceleration and heavy engine loads when the engine is cold.
The digital clock is set using the buttons in the instrument cluster, Instrument overview.
Displays and warning lights (Basic version)

Fig. 14 In the instrument cluster display (examples): A: Open engine hood, B: Open luggage compartment lid, C: Open driver door.

but outside the display itself (Warning and indicator lights). In some cases, they may also be signaled acoustically.

Type of notification Warning light Explanation
Priority 1 warning light Red Light flashing or lit – sometimes with acoustic warnings.

WARNING
Failure to heed warning lights can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Park the vehicle at a safe distance from moving traffic and where no part of the hot cata-lytic converter and exhaust system can come into contact with flammable materials under the vehicle, such as dry grass, brush, spilled fuel, etc.
x A broken down vehicle presents a high accident risk for itself and others. Switch on emergency flashers and set up a warning triangle to warn oncoming traffic.
WARNING
Roads and bridges may be dangerously icy even if the outside air temperature is above freez-ing.
x If you use the outside temperature display to tell you about frost conditions, remember that roads can even ice over at temperatures above +39 °F (+4 °C). Always remember: even if the “snowflake symbol” (icy road warning) is not displayed, there could still be black ice on the road.
x Never rely exclusively on the outside temperature display.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
For displays without warning and information messages, malfunctions are only signaled with warning and indicator lights, Warning and indicator lights, Warning and indicator lights.
Applicable only in the United States
Displays (Premium version)

Fig. 15 In the instrument cluster display: A: Open engine hood, B: Open luggage compartment lid, C: Open driver door.
