2014 VAUXHALL ZAFIRA Owner's Manual

Seats, restraints55
Belt tensioners
In the event of a head-on or rear-end
collision of a certain severity, the front
seat belts are tightened.
9 Warning
Incorrect handling (e.g. removal or
fitting of belts) can trigger the belt
tensioners.
Deployment of the belt tensioners is
indicated by illumination of control
indicator v 3 87.
Triggered belt tensioners must be
replaced by a workshop. Belt
tensioners can only be triggered once.
Notice
Do not affix or install accessories or
other objects that may interfere with
the operation of the belt tensioners.
Do not make any modifications to
belt tensioner components as this
will invalidate the vehicle type
approval.
Three-point seat belt
FittingWithdraw belt from retractor, guide it
untwisted across the body and insert the latch plate in the buckle. Tension
the lap belt regularly whilst driving by
tugging the shoulder belt.
Loose or bulky clothing prevents the
belt from fitting snugly. Do not place
objects such as handbags or mobile
phones between the belt and your body.
9 Warning
The belt must not rest against hard
or fragile objects in the pockets of
your clothing.

56Seats, restraints
Height adjustment
1. Pull belt out slightly.
2. Press button.
3. Adjust height and engage.
Adjust the height so that the belt lies across the shoulder. It must not lie
across the throat or upper arm.
Do not adjust while driving.
Removing
To release belt, press red button on
belt buckle.
Seat belts in the second row
The seat belt for the middle seat can
only be withdrawn from the retractor if
the backrest is latched in the rearmost
position
Seat belts in the third row
Open the cover in the floor between
the seats and pull up the belt buckles.
Remove latch plate and belt from
fixture.
9 Warning
The belt must not be routed
through the belt holder when the seat belt is being applied.

Seats, restraints57
When not in use, guide the seat belt
through the belt holder and insert the
latch plate in the holder.
Unhookable seat belts in the third row
Detachable seat belts are identified
by a label on the belt.
To use the side rails, the seat belts
can be removed from the seat belt
eyes in the vehicle floor.Press the spring catch and release
the hook from the belt eye in the
vehicle floor.
Reel the belt in and fasten the hook to
the magnetic holder.
To hinge the seat belt, remove hook
from magnetic holder, push spring-
loaded tab of hook and attach to seat
belt eye in floor of vehicle. The seat
belt must not be twisted. The hook must be properly engaged in the seat belt eye with the spring-loaded tab
closed again.
Notice
The hook must only be attached to the eyes placed on the vehicle floor.
The eyes and the seat belts may notbe used for lashing loads.

58Seats, restraints
Using the seat belt whilepregnant9 Warning
The lap belt must be positioned as
low as possible across the pelvis
to prevent pressure on the
abdomen.
Airbag system
The airbag system consists of a
number of individual systems
depending on the scope of
equipment.
When triggered, the airbag inflates
within milliseconds. They also deflate
so quickly that it is often unnoticeable
during the collision.9 Warning
If handled improperly the airbag
systems can be triggered in an
explosive manner.
Notice
The airbag systems and belt
pretensioner control electronics are
located in the centre console area.
Do not put any magnetic objects in
this area.
Do not affix any objects onto the
airbag covers and do not cover them with other materials.
Each airbag is triggered only once.
Have deployed airbags replaced by
a workshop. Furthermore, it may be
necessary to have the steering
wheel, the instrument panel, parts of
the panelling, the door seals,
handles and the seats replaced.
Do not make any modifications to
the airbag system as this will
invalidate the vehicle type approval.
When the airbags inflate, escaping
hot gases may cause burns.
Control indicator v for airbag systems
3 87.
Child restraint systems on front passenger seat with airbag
systems Warning according to ECE R94.02:

Seats, restraints59
NEVER use a rearward-facing child
restraint on a seat protected by an
ACTIVE AIRBAG in front of it; DEATH or SERIOUS INJURY to the CHILDcan occur.
Beyond the warning required by
ECE R94.02, for safety reasons
never use a forward-facing child
restraint system on the passenger
seat with active front airbag.
9 Danger
Do not use a child restraint system
on the passenger seat with active
front airbag.
Front airbag system
The front airbag system consists of
one airbag in the steering wheel and
one in the instrument panel. These
can be identified by the word
AIRBAG .
Additionally there is a warning label
on the side of the instrument panel,
visible when the front passenger door
is open, or on the passenger's sun
visor.
The front airbag system is triggered in
the event of an accident of a certain
severity. The ignition must be on.

60Seats, restraints
The forward movement of the front
seat occupants is decelerated,
thereby considerably reducing the risk of injury to the upper body and
head.
9 Warning
Optimum protection is only
provided when the seat is in the
proper position 3 46.
Keep the area in which the airbag
inflates clear of obstructions.
Fit the seat belt correctly and
engage securely. Only then the
airbag is able to protect.
Side airbag system
The side airbag system consists of an
airbag in each front seat backrest.
This can be identified by the word
AIRBAG .
The side airbag system is triggered in the event of an accident of a certain
severity. The ignition must be on.
The risk of injury to the upper body
and pelvis in the event of a side-on
collision is considerably reduced.
9 Warning
Keep the area in which the airbag
inflates clear of obstructions.
Notice
Only use protective seat covers that have been approved for the vehicle.Be careful not to cover the airbags.

Seats, restraints61Curtain airbag system
The curtain airbag system consists ofan airbag in the roof frame on each
side. This can be identified by the
word AIRBAG on the roof pillar.
The curtain airbag system is triggered
in the event of an accident of a certain severity. The ignition must be on.
The risk of injury to the head in the
event of a side impact is considerably reduced.
The curtain airbag system does not
protect the third row of seats.
9 Warning
Keep the area in which the airbag
inflates clear of obstructions.
The hooks on the handles in the
roof frame are only suitable for
hanging up light articles of
clothing, without coat hangers. Do not keep any items in these
clothes.
Child restraints
Child restraint systems We recommend the Vauxhall childrestraint system which is tailored
specifically to the vehicle.
When a child restraint system is being
used, pay attention to the following
usage and installation instructions
and also those supplied with the child restraint system.
Always comply with local or national
regulations. In some countries, the
use of child restraint systems is
forbidden on certain seats.
Selecting the right system The rear seats are the most
convenient location to fasten a child
restraint system.
Children should travel facing
rearwards in the vehicle as long as
possible. This ensures that the child's
backbone, which is still very weak, is
under less strain in the event of an
accident.

62Seats, restraints
Suitable are restraint systems that
comply with ECE 44-03 or
ECE 44-04. Check local laws and
regulations for mandatory use of child restraint systems.
Never hold a child whilst travelling in
the vehicle. The child will become too
heavy to be held in the event of a
collision.
When transporting children, use the
child restraint systems suitable for the
child's weight.
Ensure that the child restraint system to be installed is compatible with the
vehicle type.
Ensure that the mounting location of
the child restraint system within the
vehicle is correct.
Allow children to enter and exit the vehicle only on the side facing away
from the traffic.
When the child restraint system is not in use, secure the seat with a seat beltor remove it from the vehicle.Notice
Do not affix anything on the child
restraint systems and do not cover
them with any other materials.
A child restraint system which has
been subjected to stress in an
accident must be replaced.
