When trouble arises
481
5-2. Steps to take in an emergency
If the vehicle 12-volt batter y is discharged
The following procedures may be used to start the hybrid system if
the vehicle’s 12-volt battery is discharged.
You can also call your Toyota deal er or a qualified repair shop.
If you have a set of jumper (or booster) cables and a second vehi-
cle with a 12-volt battery, you can jump start your vehicle by follow-
ing the steps below.
Open the hood and remove
the fuse box cover.
Push the tab in and lift the
cover off.
Open the exclusive jump start-
ing terminal cover.
Push the tab in and open the
cover.
STEP1
STEP2

5
When trouble arises
483
5-2. Steps to take in an emergency
Start the engine of the second vehicle. Increase the engine
speed slightly and maintain that level for approximately 5
minutes to recharge the 12-v
olt battery of your vehicle.
Vehicles with a smart key system only: Open and close any
of the doors of your vehicle with the “POWER” switch off.
Vehicles without a smart key system
Maintain the engine speed of the second vehicle and start
the hybrid system of your vehicle by turning the engine
switch to the “ON” position.
Vehicles with a smart key system
Maintain the engine speed of the second vehicle and start
the hybrid system of your ve hicle by turning the “POWER”
switch to ON mode.
Make sure the “READY” indicator comes on. If the indicator
does not come on, contact your Toyota dealer.
Once the hybrid system has started, remove the jumper
cables in the exact reverse or der from which they were con-
nected.
Close the exclusive jump starting terminal cover, and rein-
stall the fuse box cover to its original position.
When installing, first hook the fuse box cover onto the two rear
tabs.
Once the hybrid system starts, ha ve the vehicle inspected at your
Toyota dealer as soon as possible.
STEP4
STEP5
STEP6
STEP7
STEP8
STEP9

550 Alphabetical index
Engine oilCapacity ................................ 499
Checking ............................... 369
Preparing and checking before winter ....................... 231
Engine/power control unit coolantCapacity ................................ 500
Checking ............................... 373
Preparing and checking before winter ....................... 231
Engine switch ................... 160, 164
EPS ............................................ 221
EV drive mode .......................... 172
Event data recorder ...................18
Exclusive jump starting terminal .................... 481
Floor mat................................... 341
Fluid Brake ..................................... 503
Washer .................................. 378
Fog lights Replacing light bulbs ............. 415
Switch.................................... 208
Wattage ................................. 505
Front fog lights Replacing light bulbs ............. 415
Switch.................................... 208
Wattage ................................. 505
Front passenger occupant
classification system ............ 130 Front passenger’s seat
belt reminder light ................. 439
Front seats Adjustment .............................. 76
Front side marker lights
Replacing light bulbs ............. 415
Switch ................................... 204
Wattage................................. 505
Front turn signal lights Replacing light bulbs ............. 415
Switch ................................... 178
Wattage................................. 505
Fuel Capacity ................................ 498
Fuel gauge ............................ 181
Gas station information ......... 560
Information ............................ 506
Refueling ............................... 105
Type ...................................... 498
Fuel door .................................. 105
Fuel filler door .......................... 105
Fuses ........................................ 404
Gas station information .......... 560
Gauges...................................... 181
Glove box ................................. 325
Hazard lights
Switch ................................... 428
Head restraints
Adjusting ................................ 81
Headlights Replacing light bulbs ............. 415
Switch ................................... 204
Wattage................................. 505
F
G
H
