2014 TOYOTA LAND CRUISER Navigation Manual

257
1. AUDIO/VIDEO SYSTEM OPERATION
5
AUDIO/VIDEO SYSTEM
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
■REPEATING AN ALBUM
1Touch “RPT” repeatedly until
“ALB.RPT” appears on the screen.
When the album is finished, the player will
automatically go back to the beginning of
the album and play it again. To cancel this
function, touch “RPT” again.
■PLAYING THE TRACKS ON THE
ALBUM IN RANDOM ORDER
1Touch “RAND” while the track is play-
ing.
Each time “RAND” is touched, the mode
changes as follows:
• Album Random  All Track Random 
Off
Once “RAND” appears on the screen, the
system selects a track randomly from the
album currently being listened to. To can-
cel this function, touch “RAND” repeat-
edly until the random mode turns off.
■PLAYING TRACKS FROM ALL THE
ALBUMS IN RANDOM ORDER
1Touch “RAND” repeatedly until
“ALB.RAND” appears on the screen.
Once “ALB.RAND” appears on the
screen, the system selects a track
randomly from all of the existing albums
on the Bluetooth
® device. To cancel this
function, touch “RAND” again.
RANDOM ORDER
Tracks or albums can be automatically
and randomly selected.
INFORMATION
●Depending on the portable player that is
connected to the system, certain func-
tions may not be available.

258
1. AUDIO/VIDEO SYSTEM OPERATION
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
11. VTR OPERATION*
1Open the cover and connect audio/vid-
eo device.
The A/V input port is composed of 3 input
ports.
Turn on the power of the audio/video
device if it is not turned on.
Users can enjoy watching videos by
connecting an audio/video device to
the A/V input port.
For safety reasons, the videos can only
be viewed when the following condi-
tions are met:
(a)The vehicle is completely stopped.
(b)The “ENGINE START STOP”
switch is in ACCESSORY or IGNI-
TION ON mode.
(c)The parking brake is applied.
While driving in VTR mode, only the
VTR’s audio can be heard.
NOTICE
●When the A/V input port is not in use,
keep the A/V input port cover closed.
Inserting anything other than an appro-
priate plug may cause electrical failure
or a short circuit.
CONNECTING AUDIO/VIDEO
DEVICE
ColorFunction
YellowVideo input port
WhiteLeft channel audio input port
RedRight channel audio input port
*: Vehicles with A/V input port

259
1. AUDIO/VIDEO SYSTEM OPERATION
5
AUDIO/VIDEO SYSTEM
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
1Press the “AUDIO” button.
2Touch the “A/V” tab or press the
“AUDIO” button repeatedly until the
“A/V” tab is selected.
Touch “Options” on the screen, then
touch
“Wide” on the “A/V Options”
screen. The screen mode can be
changed.
If “Full Screen” is touched when the vehi-
cle is completely stopped and the parking
brake is applied, the VTR video screen will
be displayed.
If any part of the VTR screen is touched,
the system will return to the VTR top
screen.
1Press the “AUDIO” button.
2Touch the “A/V” tab or press the
“AUDIO” button repeatedly until the
“A/V” tab is selected.
3Touch “Options”.
4This screen is displayed.
PLAYING VTRVTR OPTIONS
No.FunctionPage
Touch to display the
screen mode screen. 198
Touch to display the im-
age quality adjustment
screen.
226

260
1. AUDIO/VIDEO SYSTEM OPERATION
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
12. REAR SEAT ENTERTAINMENT SYSTEM FEATURES*
The rear seat entertainment system is designed for the rear passengers to enjoy
audio and DVD video separately from the front audio/video system. The rear seat
entertainment system can be used when the “ENGINE START STOP” switch is in
ACCESSORY or IGNITION ON mode.
No.NameNo.Name
Front audio/video systemHeadphone volume control dials and
headphone jacks
DisplayA/V input port
Rear seat entertainment system con-
troller
*: If equipped

261
1. AUDIO/VIDEO SYSTEM OPERATION
5
AUDIO/VIDEO SYSTEM
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
1Remove the insulating sheet before
using the remote control.
1Remove the cover.
2Remove the depleted batteries and in-
stall the new ones.
DISPLAY
The display is installed in the ceiling.
When audio-video equipment is con-
nected to the A/V input port, rear pas-
sengers can enjoy different audio
sources on each display. See “USING
THE VIDEO MODE” on page 277.
REAR SEAT
ENTERTAINMENT SYSTEM
CONTROLLER
BEFORE USING THE
CONTROLLER (FOR NEW
VEHICLE OWNERS)
INFORMATION
●An insulating sheet is set to prevent the
batteries from being discharged.
REPLACING THE
CONTROLLER BATTERIES
Necessary item for replacing two AA
batteries.
INFORMATION
●If the batteries are discharged, the
following symptoms may occur.
• The rear seat entertainment system
controller will not function properly.
• The operational range is reduced.
●When using AA batteries
• Batteries can be purchased at your
Toyota dealer, electric appliance shop,
or camera stores.
• Replace only with the same or equiva-
lent type recommended by your Toyota
dealer.
• Dispose of used batteries according to
the local laws.

262
1. AUDIO/VIDEO SYSTEM OPERATION
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
1Press the knob.
2Turn the knob clockwise to increase
the volume. Turn the knob counter-
clockwise to decrease the volume.
3Press the knob again.
With some headphones generally avail-
able in the market, it may be difficult to
catch signals properly. Toyota recom-
mends the use of Toyota genuine wireless
headphones.
Please contact your Toyota dealer for fur-
ther details.
HEADPHONE JACKS
No.Function
To use the headphones, connect
them to the jack.
To adjust the volume
HEADPHONES
To listen to the rear audio, use head-
phones.
VOLUME
Adjust the volume when you connect
the headphones to the jack. Loud
sounds may have a significant impact
on the human body.

263
1. AUDIO/VIDEO SYSTEM OPERATION
5
AUDIO/VIDEO SYSTEM
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
1To open the display, press the
“OPEN”, “SOURCE” or “DISC” but-
ton. To close the display, press the
“OPEN” or button.
If the display is closed with an image
shown, the image will automatically turn
off. (When you press the “OPEN” button,
the sound will not be turned off.)
1Press the “SETTING” button on the
controller.
2Select “TILT” tab.
3Select or .
This screen appears for a few seconds
when the rear display is opened. During
this time, only “OPEN/CLOSE” can be
operated.
OPENING AND CLOSING THE
DISPLAY
Opening and closing operations can be
performed from the front audio system.
(See page 266.)
JAM PROTECTION
The display will stop closing and return
to its previous position if something
gets in the way of it closing.
TILTING THE DISPLAY
INFORMATION
●The display angle is memorized and will
be recalled when the “ENGINE START
STOP” switch is turned to ACCESSORY
or IGNITION ON mode again.
CAUTION SCREEN

264
1. AUDIO/VIDEO SYSTEM OPERATION
L/C200_Navi_OM60L27U_(U)
13.06.03 19:41
1Press the “SOURCE” button to display
the audio source selection screen.
2Select an audio source.
1To play the rear audio over the speak-
ers in the vehicle, turn “Speaker Out-
put” on.
CHANGING THE SOURCE
No.Function
Turning on the audio source selec-
tion screen
Selecting an icon
Inputting the selected icon
CHANGING THE SPEAKER
OUTPUT
