2014 TOYOTA CAMRY HYBRID display

297
3-2. Using the audio system
3
Interior features
Registering and connecting from
the “Bluetooth* Setup” screen
To display the screen shown below, press the “SETUP” button and
select “Bluetooth*” on the “Setup” screen.
Select to connect the device to
be used with audio system.
( P. 303)
Select to register a Bluetooth
®
device to be used with audio
system. ( P. 300)
Select to set detailed
Bluetooth
® system settings.
(  P. 308)
Select to delete registered
devices. ( P. 302)
*: Bluetooth is a registered trade-
mark of Bluetooth SIG, Inc.

300
3-2. Using the audio system
Registering a Bluetooth® device
How to register a Bluetooth® device
Display the “Bluetooth* Setup” screen. ( P. 297)
*:Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Select “Add”.
When this screen is displayed,
search for the device name dis-
played on this screen on the
screen of your Bluetooth
®
device.
For details about operating the
Bluetooth® device, see the man-
ual that comes with it.
To cancel the registration, select
“Cancel”.
Register the Bluetooth® device using your Bluetooth® device.
A PIN-code is not required for SSP (Secure Simple Pairing) compat-
ible Bluetooth® devices. Depending on the type of Bluetooth® device
being connected, a message confirming registration may be dis-
played on the Bluetooth
® device’s screen. Respond and operate the
Bluetooth® device according to the confirmation message.
Bluetooth® compatible phones (HFP) and portable audio players
(AVP) can be registered simultane ously. You can register up to 5
Bluetooth
® devices.
STEP1
STEP2
STEP3
STEP1STEP4

301
3-2. Using the audio system
3
Interior features
Check that this screen is dis-
played when registration is com-
plete.
Select “OK” when the connection status changes from “Con-
necting...” to “Connected”.
If an error message is displayed, follow the guidance on the screen to try
again.
Registration can be performed from screens other than the
“Bluetooth* Setup” screen.
■ When registering from the “Bluetooth* Audio” screen
Display the “Bluetooth* Audio” screen. ( P. 268)
Select “Select Device”.
Follow the steps in “How to register a Bluetooth
® device” from
“STEP 2”. ( P. 300)
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
STEP5
STEP1STEP6
STEP1
STEP2
STEP3

302 3-2. Using the audio system
Deleting a Bluetooth® device
Display the “Bluetooth* Setup” screen. ( P. 297)
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Select “Remove”.
Select the desired device.
A confirmation message will be displayed, select “Yes” to
delete the device.
Check that a confirmation screen is displayed when the oper-
ation is complete.
STEP1
STEP2
STEP3
STEP4
STEP5

303
3-2. Using the audio system
3
Interior features
Connecting a Bluetooth® device
Press the “SETUP” button.
Select “Bluetooth*”.
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Select the device to be con-
nected.
Supported profile icons will be
displayed.Phone
Audio player
Supported profile icons for cur-
rently connected devices will illu-
minate.
Dimmed icons can be selected to
connect to the function directly.
Up to 5 Bluetooth® devices (Phones (HFP) and audio players (AVP))
can be registered.
If more than 1 Bluetooth
® device has been registered, select which
device to connect to.
STEP1
STEP2
STEP3

304 3-2. Using the audio system
Auto connectionTo turn auto connection mode on, set “Bluetooth* Power” to on.
(  P. 308)
When you register a phone, auto connection will be activated. Always
set it to this mode and leave the Bluetooth
® phone in a place where a
connection can be established.
When the “POWER” switch is turned to ACCESSORY or ON mode, the
system will search for a nearby cellular phone you have registered.
Next, the system automatically connects with the most recent of the
phones connected to in the past. Then, the connection result is displayed.
Manual connection
When auto connection has failed or “Bluetooth* Power” is turned off,
you must connect the Bluetooth
® device manually.
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Follow the steps in “Connecting a Bluetooth® device” from
“STEP 1”. ( P. 303)
Connecting a Bluetooth® audio player
Registering an additional device Select “Select Devi ce” on the Bluetooth
® audio control
screen.
For more information: P. 3 0 0
Selecting a registered device Select “Select Devi ce” on the Bluetooth
® audio control
screen.
For more information: P. 3 0 3
STEP1
STEP1
STEP2
STEP1
STEP2

306
3-2. Using the audio system
Displaying a Bluetooth® device details
Bluetooth® device registration status
Display the “Bluetooth* Setup” screen. ( P. 297)
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Select the device.
Select “Device Info”.
Following screen is displayed:
Change device name
Change connection method
Bluetooth
® Address
Display your telephone num-
ber
The number may not be dis-
played depending on the
model of phone.
Compatibility profile of the
device
Restore default settings
You can confirm and change th e registered device details.
STEP1
STEP2
STEP3
STEP4

308
3-2. Using the audio system
Detailed Bluetooth® system settings
How to check and change detailed Bluetooth® settings
Display the “Bluetooth* Setup” screen. ( P. 297)
Select “System Settings”.
The following screen is displayed:
Bluetooth
® Power on/off
You can change Bluetooth® func-
tion on/off
Change Bluetooth® name
Change PIN-code ( P. 309)
Bluetooth
® address
Display phone status
Select to set the phone connec-
tion status display on/off.
Display audio player status
Select to set the connection sta-
tus display of the audio player on/
off.
Compatibility profile of the sys-
tem
Restore default settings
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
You can confirm and change the detailed Bluetooth® settings.
STEP1
STEP2
STEP3
