2014 Ram 2500 Owner's Manual

Rear Tail/Stop, Turn Signal And Backup Lamps
1. Remove the two screws that pass through the bedsheetmetal. 2. Pull the outboard side of the lamp rearward far
enough to unsnap the two receptacles on the outboard
side of the lamp housing from the two plastic snap
post retainers in the outer box side panel.
3. Disconnect the wiring harness connectors from the bulb socket.
Tail Lamp Screw LocationsPulling Out The Tail Lamp
7
MAINTAINING YOUR VEHICLE 735

4. Rotate the bulb socket counterclockwise 1/4 turn tounlock it from the housing.
5. Pull the bulb straight out of the socket.
CAUTION!
Do not contaminate the bulb glass by touching it
with your fingers or by allowing it to contact other
oily surfaces. Shortened bulb life will result.
6. Reverse the procedure to install the bulb and housing.
Center High-Mounted Stoplamp (CHMSL) With
Cargo Lamp
1. Remove the two screws holding the housing/lens to the body as shown. 2. Separate the connector holding the housing and wir-
ing harness to the body.
CHMSL Mounting Screw Locations
736 MAINTAINING YOUR VEHICLE

3. Turn the desired bulb socket ¼ turn and remove thesocket and bulb from housing. 4. Pull the desired bulb straight from the socket.
CHMSL Connector Location
CHMSL Bulb And Socket7
MAINTAINING YOUR VEHICLE 737

CAUTION!
Do not contaminate the bulb glass by touching it
with your fingers or by allowing it to contact other
oily surfaces. Shortened bulb life will result.• Outside Bulbs: Cargo Lamps
• Inside Bulb: Center High-Mounted Stop Lamp
5. Reverse the procedure for installation of bulbs and housing.
Cab Top Clearance Lamps — If Equipped
1. Remove the two screws from the top of the lamp.
Removing Rear Screw From Clearance Lamp
738 MAINTAINING YOUR VEHICLE

2. Rotate the bulb socket ¼ turn and pull it from the lampassembly. 3. Pull the bulb straight from it’s socket and replace.
Removing Bulb Socket From Clearance Lamp
Removing The Bulb From The Bulb Socket7
MAINTAINING YOUR VEHICLE 739

Rear Lamp Bar ID Marker (Dual Rear Wheels) — If
Equipped
1. Loosen the two screws and the housing to gain accessto the bulb sockets. 2. Turn the socket ¼ turn counterclockwise to access the
bulb.
3. Pull the bulb straight out from the socket.
4. Reverse the procedure for installation of the bulbs and housing.
Screw Locations
740 MAINTAINING YOUR VEHICLE

Side Marker Lamps (Dual Rear Wheels) — If
Equipped
1. Push rearward on the side marker lamp assembly.2. Pull the entire assembly from the fender.
3. Turn the socket ¼ turn counterclockwise and remove
from assembly to access the bulb.
4. Pull the bulb straight out from socket.
5. Reverse the procedure for installation of the bulbs and housing.
Side Marker Lamp Locations
7
MAINTAINING YOUR VEHICLE 741

FLUID CAPACITIES
U.S. Metric
Fuel (Approximate)
1500 Regular Cab Shortbed/Crew Quad Cab Models 26 Gallons 98 Liters
1500 Regular Cab Longbed/Crew Quad Cab Models (Optional) 32 Gallons 121 Liters
2500/3500 Shortbed Models 31 Gallons 117 Liters
2500/3500 Longbed Models 32 Gallons 121 Liters
Engine Oil With Filter
3.6L Engine (We recommend you use SAE 5W-20, API Certified) 6 Quarts 5.6 Liters
5.7L Engines (We recommend you use SAE 5W-20, API Certified) 7 Quarts 6.6 Liters
5.7L Engine (We recommend you use SAE 5W-30, API Certified), for 2500/3500 trucks
operating under a gross combined weight rating greater than 14,000 lbs (6 350 kg).7 Quarts 6.6 Liters
6.4L Engines (We recommend you use SAE 0W-40 engine oil meeting the requirements
of Chrysler Material Standard MS-12633 for use in all operating temperatures.)7 Quarts 6.6 Liters
742 MAINTAINING YOUR VEHICLE
