01
In ACC mode or when starting the vehicle, the system comes on.
u
se the button at bottom right of the screen for access to the main menus\
.
A second press returns the system to the last source activated, then pres\
s the virtual buttons
in the screen.
GENERAL OPERATION
In the event of prolonged exposure to sunlight and very hot conditions, \
the system may go into stand-by (screen and sound completely off)
for at least 5 minutes.
Return to normal operation takes place when the temperature in the passe\
nger compartment drops.
183
B3_en_Chap12a_Autoradio-toyota-tactile-1_ed01-2014

02
184Press to mute the sound.
A long press reinitialises the system. Volume (each source is
independent).
Select audio source (depending on version):
-
"FM" / "AM" / "DAB"* radio.
-

"
u SB" player.
- t
elephone connected by Bluetooth and with Bluetooth streaming.
-

Media player connected to the auxiliary socket (jack, cable not supplie\
d).
Pressing with more than one finger is not recognised.
t
he screen can be used when wearing gloves.
FIRST STEPS
* Depending on equipment.
to clean the screen, use a soft non-abrasive cloth (spectacles cloth) w\
ithout any additional product or a damp cloth.
Do not use pointed objects on the screen.
Do not touch the screen with wet hands.
Short-cuts: using virtual buttons in the
top bar of the screen, it is possible to go
directly to the choice of audio source,
telephone functions or "Mirror Screen
®"
mode.

03
185
STEERING MOUNTED CONTROLS
Short press: change multimedia
source.
Long press: mute / restore sound from
the radio or pause media sources.
Increase volume.
Decrease volume.
Radio: change to preset radio stations
in ascending order.
Media: next track.
Radio: change to preset radio stations
in descending order.
Media: previous track.Accept an incoming call.
Other than on a call: press to open the
list of contacts; a second press opens
the calls history.
Reject the incoming call.
e

nd the call in progress.
Other than on a call: press to return
to the radio screen or the clock if the
radio is not active.
B3_en_Chap12a_Autoradio-t oyota-tactile-1_ed01-2014

04
186
MEDIA
Level 1Level 2 Level 3
"Audio source"

187
Level 1
Level 2 Level 3 Comment
Audio source FM FM radio configuration
u

pdate the list of stations
update the list to take account of reception.
List of stationsChoose to list by "Broadcaster" or "Alphabetic".
FM traffic announcements
Activate or deactivate options.FM alternative frequencies
Change regional code
FM radiotext
Presets
List of preset stations.
StationsList of radio stations received.
ManualSearch for stations step by step or automatically.
Audio source
AM PresetsList of preset stations.
ManualSearch for stations step by step or automatically.
Audio source
DAB DAB radio configuration
u
pdate the list of stations
update the list to take account of reception.
L-Band
Activate or deactivate options.DAB traffic announcements
DAB alternative frequencies
DAB radiotext
Presets
List of preset stations.
StationsList of radio stations received.
ManualSearch for stations step by step or automatically.
B3_en_Chap12a_Autoradio-t oyota-tactile-1_ed01-2014

04MEDIA
Level 1Level 2 Level 3
188
"Audio source"

189
Level 1
Level 2 Level 3 Comment
Audio source USB Scan
Choose the play setting.
Random play
Repeat play
Previous track
Play
Next track
Audio source
Bluetooth audio Telephone
First connection, refer to the telephone section.
Audio play
System configuration
Activate or deactivate options.
Random play
Choose the play setting.
Repeat play
Previous track
Play
Next track
Audio source A / V Screen format
Normal
Choose the most suitable screen format.Stretched
Zoom
Full screen
Display in full screen mode.
B3_en_Chap12a_Autoradio-t oyota-tactile-1_ed01-2014

04
Selecting a station
the exterior environment (hills, buildings, tunnel, car park,
below ground...) may prevent reception, even in RDS alternative
frequencies mode.
t

his phenomenon is normal in the propagation
of radio waves and is in no way indicative of a fault with the audio
system.
Select "FM". Press on "Audio source" to display the
carousel of sound sources.
Select the "Station" tab then select a radio
station from the stations received. If necessary, select change of source by
pressing on the "
Audio source" shortcut in the
upper bar of the carousel.
Select "AM" or "DAB"*.
Select "FM radio configuration " then "Update
the list of stations " to refresh the list.
RADIO
190 * Depending on equipment.
