5
POWER FRONT SEAT ADJUSTMENTS
To slide the seat forward or bac kward, push the
control switch
01 forward or backward.
To adjust
the angle of the seatbac k, push the switch
02 forward or backward.
SEAT LIFTER (driver’s seat only)
To adjust the angle and height of the seat cushion,
push the front or rear end of the switch
01 up
or down.
MANUAL LUMBAR SUPPORT (driver’s seat only)
To adjust the lumbar area, move the lever 03 up or down.
For more information, refer to the “Safety –– Seats, seat belts and supplemental restraint system (section 1)”\
of your
Owner’s Manual.
0102
03
2ND ROW SEAT ADJUSTMENTS (if so equipped)
To recline the seatback, pull up on the recline handle
01 and lean back. To bring the seatback forward, pull
the handle up and lean your body forward. Release
the handle to lock the seatback in position.
TIP UP FOR EASY ENTRY/EXIT OF THE 3RD ROW
1.
Raise the armrest (capt
ain’s chairs – if so equipped)
so it is parallel to the seatback and in the stowed position.
2.
T
hen lift up on the seatback latch
02 located on the
upper corner of the seatback and fold the seatback
forward onto the seatbase.
3.
Finally
, lift up on the lower corner of the seat base
and fold the seat forward.
For more information, refer to the “Safety –– Seats, seat belts and
supplemental restraint system (section 1)” of your Owner’s Manual.
01
02
