2014 MITSUBISHI LANCER SPORTBACK display

Indicator light, warning light, an
d information screen display list
5-130 Features and controls
5
N00557900040
When there is information to be announced, such as light reminders, the tone sounds andthe screen switches to the displays shown below. Refer to the appropriate page and take the necessary measures.When the cause of the warning display is eliminated, the warning display goes out automatically.Refer to “Warning display list (With ignitionswitch in the “OFF” position)” on page 5-131. Refer to “Warning display list (With ignitionswitch in the “ON” position)” on page 5-134. Refer to “Other interrupt displays (With igni- tion switch in the “ON” position)” on page5-140.Information screen display list
NOTE
 In the following cases, a warning may be dis- played on the information screen and the buzzer may sound for a few seconds, at times. This is caused by the system picking up interference such as strong electromagneticwaves or noise, and is not a functional prob- lem. • An extremely strong electromagnetic wave is received from a source such as an illegal radio set, a spark from a wire, or a radar sta-tion.
• Abnormal voltage or a static electricity dis- charge is generated by the operation of installed electronics (including after-market parts). If the warning display has occurred a number of times, take your vehicle to an authorized Mitsubishi Motors dealer or a repair facilityof your choice and have the system checked.NOTE
BK0200700US.book
130 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Indicator light, warning light, an
d information screen display list Features and controls 5-131
5
N00558001247
Warning display list (With ignition switch in the “OFF” position)
Screen type 1
Screen type 2
Cause
Do this (Reference)
 You have forgotten to remove the key from the ignition switch.
 Remove the key. Refer to “Key reminder system” on page 5-37.
 You have forgotten to turn off the lights.
Refer to “Light auto-cutout function (head- lights and other lights)” on page 5-147.
 The theft-alarm is operating.
Refer to “Theft-alarm system” on page 5-41.
 Immobilizer is registered.
Refer to “Electronic immobilizer (Anti- theft starting system)” on page 5-4, 5-28.
BK0200700US.book
131 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Indicator light, warning light, an
d information screen display list
5-132 Features and controls
5
 After turning off the engine, an attempt was made to open the driver’s door with the ignition switch in any position other than “LOCK” (PUSH OFF).
 Turn the ignition switch to the “LOCK” (PUSH OFF) position. Refer to “Ignition switch return reminder system” on page 5-38.
 An attempt was made to lock all the doors and the rear hatch with the ignition switch in any position other than “LOCK” (PUSH OFF).
 Turn the ignition switch to the “LOCK” (PUSH OFF) position. Refer to “Ignition switch turn-off reminder system” on page 5-19.
Screen type 1
Screen type 2
Cause
Do this (Reference)
BK0200700US.book
132 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Indicator light, warning light, an
d information screen display list Features and controls 5-133
5
 There is a fault in the F.A.S.T.-key.
Refer to “F.A.S.T.-key” on page 5-11.
Screen type 1
Screen type 2
Cause
Do this (Reference)
BK0200700US.book
133 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Indicator light, warning light, an
d information screen display list
5-134 Features and controls
5
N00558101307
Warning display list (With ignition switch in the “ON” position)
Screen type 1
Screen type 2
Cause
Do this (Reference)
 There is a fault in the EPS.
Have the vehicle inspected by an autho- rized Mitsubishi Motors dealer or a repair facility of your choice as soon as possible. Refer to “Electric power steering system (EPS)” on page 5-91.
BK0200700US.book
134 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Indicator light, warning light, an
d information screen display list Features and controls 5-135
5
 There is a fault in the F.A.S.T.-key.
Refer to “F.A.S.T.-key” on page 5-11.
 Immobilizer is registered.
Refer to “Electronic immobilizer (Anti- theft starting system)” on page 5-4, 5-28.
Screen type 1
Screen type 2
Cause
Do this (Reference)
BK0200700US.book
135 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Indicator light, warning light, an
d information screen display list
5-136 Features and controls
5
 The brake fluid level is low.  There is a fault in the brake system.
 Park the vehicle in a safe place and contact an authorized Mitsubishi Motors dealer or a repair facility of your choice for assis-tance. Refer to “Brake warning display” on page 5-143.
 There is a fault in the Anti-lock braking system.
 Avoid sudden braking and high-speed driv- ing, park the vehicle in a safe place, and take corrective measures. Refer to “Anti- lock braking system warning light/display” on page 5-89.
 The tire pressure in one of the tires (except spare tire) is low.
 Refer to “Tire Pressure Monitoring Sys- tem” on page 5-100.
 There is a fault in the Tire Pressure Moni- toring System.
 Refer to “Tire Pressure Monitoring Sys- tem” on page 5-100.
 One of the doors or the rear hatch is not completely closed. The open door or rear hatch is displayed.
 Close the door or rear hatch. Refer to “Door ajar warning display (With ignition switch in the “OFF” position)” on page 5-112.
Screen type 1
Screen type 2
Cause
Do this (Reference)
BK0200700US.book
136 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Indicator light, warning light, an
d information screen display list Features and controls 5-137
5
 The engine hood is open.
Close the engine hood. Refer to “Engine hood” on page 9-3.
 The engine is overheated.
Park the vehicle in a safe place and take corrective measures.Refer to “Engine overheating” on page 8-4.
 The continuously variable transmission (CVT) fluid or Twin Clutch SST fluid tem-perature is increased.
 Park the vehicle in a safe place and take corrective measures.Refer to “Continuously variable transmis- sion (CVT)” on page 5-61. Refer to “Twin Clutch SST” on page 5-70.
 The seat belt is not fastened when the igni- tion switch is in
the “ON” position.
 Fasten your seat belt properly. Refer to “Driver’s seat belt reminder/warn- ing light and display” on page 4-12.
 There is a fault in the fuel system.
Contact an authorized Mitsubishi Motors dealer or a repair facility of your choice to have the system checked.
 The vehicle is being driven with the park- ing brake still applied.
 Release the parking brake. Refer to “Brake warning display” on page 5-143.
Screen type 1
Screen type 2
Cause
Do this (Reference)
