Specifications
qEngine
Item Specification
Type DOHC-16V in-line, 4-cylinder
Bore × Stroke 78.0 × 78.4 mm (3.07 × 3.09 in)
Displacement 1,498.0 ml (1,498.0 cc)
Compression ratio 10.0
qElectrical System
Item Classification
Battery 12V-50Ah/20HR or 12V-65Ah/20HR
Spark-plug number Mazda Genuine spark plug ZJY6-18-110 or Z6B7-18-110
CAUTION
When cleaning the iridium plugs, do not use a wire brush. The fine particulate
coating on the iridium alloy and platinum tips could be damaged.
qLubricant Quality
Lubricant type and classification
Engine oil Refer to Recommended Oil on page 8-13.
Manual transaxle oil API Service GL-4
SAE 75W-80
Automatic transaxle fluid Mazda Genuine ATF M-V
Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3
NOTE
Refer to Introduction on (page 8-2) for owner's responsibility in protecting your investment.
10-4
Specifications
Mazda2_8DB2-EA-13G_Edition4 Page346
Thursday, May 15 2014 1:38 PM
Form No.8DB2-EA-13G

Black plate (347,1)
qCapacities
(Approximate Quantities)
Item Capacity
Engine oil With oil filter replacement
3.9 L (4.1 US qt, 3.4 Imp qt)
Without oil filter replacement 3.7 L (3.9 US qt, 3.3 Imp qt)
Coolant Manual transaxle
5.1 L (5.4 US qt, 4.5 Imp qt)
Automatic transaxle 5.4 L (5.7 US qt, 4.8 Imp qt)
Manual transaxle oil 2.91 L (3.07 US qt, 2.56 Imp qt)
Automatic transaxle fluid 7.0 L (7.4 US qt, 6.2 Imp qt)
Fuel tank 42.8 L (11.3 US gal, 9.41 Imp gal)
Check oil and fluid levels with dipsticks or reservoir gauges.
q Dimensions
Item Vehicle specification
Overall length With front license plate mount cover
3,965 mm (156.1 in)
Without front license plate mount
cover 3,955 mm (155.7 in)
Overall width 1,695 mm (66.7 in)
Overall height 1,475 mm (58.1 in)
Front tread 1,476 mm (58.1 in)
Rear tread 1,466 mm (57.7 in)
Wheelbase 2,490 mm (98 in)
qWeights
Item Weight
Manual transaxle Automatic transaxle
GVWR (Gross Vehicle Weight Rating) 1,480 kg (3,263 lbs) 1,502 kg (3,311 lbs)
GAWR
(Gross Axle Weight Rat-
ing) Front 774 kg (1,706 lbs) 799 kg (1,761 lbs)
Rear 706 kg (1,556 lbs) 703 kg (1,550 lbs)
q
Air Conditioner
Item Classification
Refrigerant Type HFC134a (R-134a)
Specifications
10-5
Mazda2_8DB2-EA-13G_Edition4 Page347
Thursday, May 15 2014 1:38 PM
Form No.8DB2-EA-13G

Black plate (348,1)
qLight Bulbs
Exterior light
Light bulb Category
Wattage UNECE
*1(SAE)
Headlights 60/55 ―(HB2)
Front turn signal lights 21 PY21W ( ―)
Parking lights (Front side-marker lights) 5 W5W ( ―)
Fog lights
í55 H11 (H11)
Side turn signal lights*25 WY5W (―)
High-mount brake light LED*3― (― )
Rear turn signal lights 21 WY21W (7443NA)
Brake lights/Taillights (Rear side-marker lights) 21/5 W21/5W (7443)
Reverse lights 18 W16W (921)
License plate light 5 W5W ( ―)
*1 UNECE stands for United Nations Economic Commission for Europe.
*2 Bulb replacement is not possible because it is built into the unit. Replace the unit.
*3 LED is the abbreviation for Light Emitting Diode.
Interior light
Light bulb Category
Wattage UNECE
*1
Luggage compartment light 5―
Overhead light 10―
*1 UNECE stands for United Nations Economic Commission for Europe.
q Tires
NOTE
The tires have been optimally matched with the chassis of your vehicle.
When replacing tires, Mazda recommends that you replace tires of the same type originally fitted to
your vehicle. For details, contact an Authorized Mazda Dealer.
Check the tire pressure label for tire size and inflation pressure. Refer to Tire Inflation
Pressure on page 8-27.
Standard tire
Tire size Inflation pressure
Front Rear
185/55R15 82V 220 kPa (32 psi) 210 kPa (30 psi)
Temporary spare tire
Tire size Inflation pressure
T115/70D14 88M 420 kPa (60 psi)
10-6íSome models.
Specifications
Mazda2_8DB2-EA-13G_Edition4 Page348
Thursday, May 15 2014 1:38 PM
Form No.8DB2-EA-13G

Black plate (349,1)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
88―118 N·m (9 ―12 kgf·m, 65 ―87 ft·lbf)
q Fuses
Refer to Fuses on page 8-40.
Specifications
10-7
Mazda2_8DB2-EA-13G_Edition4 Page349
Thursday, May 15 2014 1:38 PM
Form No.8DB2-EA-13G

Black plate (350,1)
Personalization Features
The following“Personalization Features ”are available. These settings can only be changed by an Authorized
Mazda Dealer.
Item Feature Factory Setting Available Settings
Auto headlight on/off The headlight illumination on/off timing based
on surrounding lightness/darkness can be
changed Standard
(Illuminates under average levels of
darkness) Earlier/
Somewhat earlier/ Somewhat later/
Later
Two-step down
power window The two-step down power window function can
be changed
Activated Deactivated
Adjusts the window opening range 3 cm (1 in) 2―10 cm (0.8― 3.9 in)
10-8
Personalization Features
Mazda2_8DB2-EA-13G_Edition4 Page350
Thursday, May 15 2014 1:38 PM
Form No.8DB2-EA-13G

Black plate (351,1)
11Index
