2014 Lexus ES300h Instrument cluster / Owner's Manual (OM33A60U)

872
ES350_300h_OM_OM33A60U_(U)
8-2. Customization
■Illumination (P. 6 1 1 )
FunctionDefault
settingCustom-
ized setting
Interior lights illumination
controlOnOff—————O
“Interior Lights Off Timer”
(Time elapsed before the
interior lights turn off)
15 seconds
Off
O—O—OO7. 5 s e c o n d s
30 seconds
Operation after the
“START STOP ENGINE”
<“POWER”> switch is
turned off
OnOff—————O
Operation when the doors
are unlockedOnOff—————O
Operation when you
approach the vehicle with
the electronic key on your
person
OnOff—————O
Footwell lightingOnOff—————O
Outer foot lightsOnOff—————O
“Exterior Lights Off Timer”
(Time elapsed before the
outer foot lights turn off)
15 seconds
Off
O—O—OO7. 5 s e c o n d s
30 seconds
“Ambient illumin. (instru-
ment panel)”
(Enable/disable operation
of the ornament lights on
the instrument panel)*
OnOff—O—OOO
Sensitivity of the ambient
light sensor used for dim-
ming the meter lights etc.
Standard-2 to +2—————O
Sensitivity of the ambient
light sensor used for
brightening the meter
lights etc.
Standard-2 to +2—————O
123456

ES350_300h_OM_OM33A60U_(U)
8738-2. Customization
8
Vehicle specifications
*:If equipped
■Rear sunshade* ( P. 631)
*:If equipped
Enable/disable operation
of the outer foot lights
when you approach the
vehicle with the electronic
key on your person
OnOff—————O
Enable/disable operation
of the outer foot lights
when the doors are
unlocked with the power
door lock switch
OnOff—————O
FunctionDefault
settingCustom-
ized setting123456
FunctionDefault settingCustom-
ized setting
Reverse operationOnOff—————O
Ti m e e l a p s e d b e f o r e t h e
reverse operation feature
activates
0.7 seconds
0 second
—————O0.9 seconds
1.2 seconds
123456

874
ES350_300h_OM_OM33A60U_(U)
8-2. Customization
■Vehicle customization
●When the “Auto Lock by Speed” and “Auto Lock by Shift from P” are both on, the
door lock operates as follows.
• When shifting the shift lever to any position other than P, all the doors will be
locked.
• If the vehicle is started with all the door s locked, the “Auto Lock by Speed” would
not operate.
• If the vehicle is started with any door unlocked, the “Auto Lock by Speed” will operate.
●When the smart access system with push-b utton start is off, the “Select Doors to
Unlock” cannot be customized.
●When the doors remain closed after un locking the doors and the “Auto Relock
Timer” activates, the signals will be generated in accordance with the “Lock/
Unlock Feedback-Tone” and the “Lock/Unlock Feedback-Lights” settings.
■When customizing using Remote Touch
Stop the vehicle in a safe place, apply the parking brake, and shift the shift lever to P.
Also, to prevent 12-volt battery discharge, leave the engine running
while customizing the features.
CAUTION
■During customization
As the engine needs to be running during customiza-
tion, ensure that the vehicle is parked in a place with adequate ventilation. In a
closed area such as a garage, exhaust gases including harmful carbon monoxide
(CO) may collect and enter the vehicle. This may lead to death or a serious health
hazard.
NOTICE
■During customization
To prevent 12-volt battery discharge, ensure that the engine is run-
ning while customizing features.

875
ES350_300h_OM_OM33A60U_(U)
8-3. Items to initialize
8
Vehicle specifications
Items to initialize
The following items must be initialized for normal system operation
after such cases as the batter y being reconnected, or maintenance
being performed on the vehicle:
ItemWhen to initializeReference
Maintenance data (U.S.A.
only)• After the maintenance is per- formedP. 666
Tire pressure warning system
• When rotating the tires
• When changing the tire infla-tion pressure by changing trav-
eling speed or load weight, etc.
P. 7 0 4

876
ES350_300h_OM_OM33A60U_(U)
8-3. Items to initialize

877
ES350_300h_OM_OM33A60U_(U)
9For owners
Reporting safety defects for U.S. owners ..................................... 878
Seat belt instructions for Canadian owners
(in French) .............................................. 879
SRS airbag instructions for Canadian owners
(in French) ............................................... 881

878
ES350_300h_OM_OM33A60U_(U)
Reporting safety defects for U.S. owners
If you believe that your vehicle has a defect which could cause a crash or
could cause injury or death, you sh ould immediately inform the National
Highway Traffic Safety Ad ministration (NHTSA) in addition to notifying
the Lexus Division of Toyota Motor Sa les, U.S.A., Inc. (Toll-free: 1-800-
25-LEXUS).
If NHTSA receives similar complaints , it may open an investigation, and
if it finds that a safety defect exists in a group of vehicles, it may order a
recall and remedy campaign. However, NHTSA cannot become
involved in individual problems between you, your dealer, or Lexus Divi-
sion of Toyota Motor Sales, U.S.A., Inc.
To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at
1-888-327-4236 (TTY: 1-800-424-9153); go to
http://www.safercar.gov ;
or write to: Administrator, NHTS A, 1200 New Jersey Ave, S.E.,
Washington, DC 20590. You can a lso obtain other information about
motor vehicle safety from
http://www.safercar.gov.

879
ES350_300h_OM_OM33A60U_(U)
9
For owners
Seat belt instructions for Canadian owners
(in French)
●Tirez sur la ceinture épaulière
jusqu’à ce qu’elle recouvre entiè-
rement l’épaule; elle ne doit
cependant pas toucher le cou ni
glisser de l’épaule.
●Placez la ceinture abdominale le
plus bas possible sur les hanches.
●Réglez la position du dossier.
Tenez-vous assis bien au fond du
siège, le dos droit.
●Ne vrillez pas la ceinture de
sécurité.
The following is a French explanation of seat belt instructions extracted
from the seat belt section in this manual.
See the seat belt section for more detailed seat belt instructions in
English.
Utilisation adéquate de s ceintures de sécurité
