2. Install rear corner panels.3. Rotate the header forward.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 263

4. Engage the header latches.5. Install the back window.
264 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

6. Install the side windows.7. To install the side windows, affix the window tempo-
rarily by attaching to the Velcro® in the rear corner.
Start the zipper but close only about 1 in (2.5 cm).
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 265

8. Insert the front retainer of the window into the doorchannel, making sure the retainer is fully seated and
properly positioned on the door frame. Failure to do
so can result in wind and water leaks or damage to the
window.1 — Incorrect Insertion
2 — Correct Insertion
266 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

9. Insert the retainer along the bottom edge of thewindow into the bottom side channel, beginning at the
front and working to the rear of the vehicle. Finish by
closing the zipper completely and attaching the Vel-
cro® along the top and rear of the window. Repeat this
step for the opposite side.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 267

Folding Down The Soft Top
1 — Header Bow6 — Body Side Retainer
2 — 2–Bow 7 — Quarter Window
3 — 3–Bow 8 — Check Strap
4 — 4–Bow 9 — Front Retainer — Quarter Window
5 — Sail Panel 10 — Bottom Retainer — Quarter Window
268 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

1 — Zipper Start
2 — Zipper Finish
3 — Swing Gate Bar
4 — Swing Gate Brackets
5 — Sail Panels
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 269

NOTE:Clean side and rear windows before removal to
assist in preventing scratching during removal of the soft
top. If zippers are difficult to operate due to road dust,
etc., clean them with a mild soap solution and a small
brush. Cleaning products are available through your
authorized dealer.
1. If your vehicle has half-doors, remove each half-door window by opening the door and lifting the half-door
window out.
NOTE: Stow half-door windows carefully outside of the
vehicle, never inside, to avoid scratches.
2. Unclip and move the sun visors to the side.
3. Release the header latches and hooks from the loops on the windshield frame. 4. Open the swing gate.
