ENGINE
Versions 1.4 Turbo MultiAir 136/140 HP 1.6 16V MultiJet 115/120 HP
Type code 55263624 55263113
Cycle Otto Diesel
Number and position of cylinders 4 in line 4 in line
Piston bore and stroke (mm) 72.0 x 84.0 79.5 x 80.5
Total displacement (cm³) 1368 1598
Compression ratio 10 : 1 16.5 : 1
Maximum power (EC) (kW)
100
(*)/ 103 85(*)/88
Maximum power (EC) (HP)
136
(*)/ 140 115(*)/ 120
corresponding engine speed (rpm) 5000 3750
Maximum torque (EC) (Nm) 230 320
Maximum torque (EC) (kgm) 23.5 32.6
corresponding engine speed (rpm) 1750 1750
Spark plugs NGK IKR9J8 –
FuelUnleaded petrol 95 RON (EN 228
Specification)Diesel for motor vehicles (EN 590
Specification)
(*) Where provided
167

Versions 2.0 16V MultiJet 120 HP 2.0 16V MultiJet 140 HP 2.0 16V MultiJet 170 HP
Type code 55263087 55263087 55263088
Cycle Diesel Diesel Diesel
Number and position of cylinders 4 in line 4 in line 4 in line
Piston bore and stroke (mm) 83 x 90.4 83 x 90.4 83 x 90.4
Total displacement (cm³) 1956 1956 1956
Compression ratio 16.5 16.5 16.5
Maximum power (EC) (kW) 88 103 125
Maximum power (EC) (HP) 120 140 170
corresponding engine speed (rpm) 4000 3750 3750
Maximum torque (EC) (Nm) 320 350 350
Maximum torque (EC) (kgm) 32.6 35.7 35.7
corresponding engine speed (rpm) 1250 1500 1750
FuelDiesel for motor vehicles (EN
590 Specification)Diesel for motor vehicles (EN
590 Specification)Diesel for motor vehicles (EN
590 Specification)
168
TECHNICAL SPECIFICATIONS

WHEELS
RIMS AND TYRES PROVIDED
180) 181)
Versions Rims Tyres Snow tyres
1.4 Turbo MultiAir6.5J x 16 ET40 215/65 R16 98H 215/65 R16 98Q (M+S)
7J x 17 ET40 215/60 R17 96H 215/60 R17 96Q (M+S)
7J x 18 ET 40 225/55 R18 98V 225/55 R18 98Q (M+S)
1.6 16V MultiJet6.5J x 16 ET40 215/65 R16 98H 215/65 R16 98Q (M+S)
7J x 17 ET40 215/60 R17 96H 215/60 R17 96Q (M+S)
7J x 18 ET 40 225/55 R18 98V 225/55 R18 98Q (M+S)
2.0 16V MultiJet6.5J x 16 ET40 215/65 R16 98H 215/65 R16 98Q (M+S)
6.5J x 17 ET40
(*)215/60 R17 96V(*)215/60 R17 96Q (M+S)(*)
7J x 17 ET40 215/60 R17 96H 215/60 R17 96Q (M+S)
7J x 18 ET 40 225/55 R18 98V 225/55 R18 98Q (M+S)
(*) Trailhawk versions
Space-saver wheel (where provided)
Tyre:T145/90 R16 106M
Rim:4.0 B x 16H ET22
WARNING
180)If winter tyres with a lower speed rating than that indicated in the Registration Document are used, do not exceed the maximum speed
corresponding to the speed rating of the tyres used.
181)DO NOT fit wheel hub caps when using integral hub caps fixed (with springs) to the steel rim and after sale tyres provided with Rim
Protector. Use of unsuitable tyres and hub caps may cause sudden decrease of tyre pressure.
169

COLD TYRE INFLATION PRESSURE (bar)
When the tyres are warm, the inflation pressure should be +0.3 bar compared with the prescribed value. However, recheck that
the value is correct with the tyre cold. With snow tyres, add +0.2 bar to the pressure value prescribed for standard tyres.
Ty r e sUnladen/medium load Full load
Full size spare
wheel(*)Space-saver
wheel
Front Rear Front Rear
215/65 R16 98H 2,4 2,2 2,4 2,4
2,4 4,2 215/60 R17 96H / 96V 2,4 2,2 2,4 2,4
225/55 R18 98V 2.4 2.2 2.4 2.4
(*) After using the spare wheel in an emergency, where necessary, align the pressure of the wheel to the recommended value as soon as possible, with reference to
the following table.
SNOW CHAINS78)
Front- and all-wheel drive versions: 7-mm snow chains can be used on 215/65 R16 tyres. Chains cannot be fitted on
215/60 R17 and 225/55 R18 tyres.
Important
The use of snow chains should be in compliance with local regulations of each country. In certain countries, tyres marked with
code M+S (Mud and Snow) are considered as winter equipment; therefore their use is equivalent to that of the snow chains.
The snow chains may be applied only to the front wheel tyres.
Check the tension of the snow chains after the first few metres have been driven.
Using snow chains with tyres with non-original dimensions may damage the vehicle.
Using different size or type (M+S, snow, etc.) tyres between front and rear axle may adversely affect vehicle driveability, with the
risk of losing control of the vehicle and resulting accidents.
WARNING
78)Keep your speed down when snow chains are fitted; do not exceed 50 km/h. Avoid potholes, steps and pavements and avoid driving for
long distances on roads not covered with snow to prevent damaging the vehicle and the road surface.
170
TECHNICAL SPECIFICATIONS

DIMENSIONS
Dimensions are expressed in mm and refer to the vehicle equipped with its standard-supplied tyres. Height is measured with
vehicle unladen.
AB C D
E(*)FGH I
4255 / 4259(**)892 2570
793 / 797(**)1667 / 1697(***)1551 / 1541(**)20231553 / 1541(**)1805
(*) Trailhawk versions: 1697 / 1727 (with roof rack bars)
(**) Trailhawk versions
(***) With roof rack bars
157J0A0019C
171

MINIMUM GROUND CLEARANCE/TYPICAL ANGLES
"Minimum ground clearance" (reference A fig. 158)
The clearance value is measured next to the lower edge of the differential. This value also defines those for the "Approach
angle" the "Departure angle" and the "Breakover angle".
Dimensions are expressed in mm and refer to the vehicle equipped with its standard-supplied tyres.
Front wheel drive (FWD) versions: 171 mm
Four wheel drive (4WD) versions: 201 mm
Trailhawk versions with four wheel drive (4WD LOW): 225 mm
158J0A0242C
172
TECHNICAL SPECIFICATIONS

"Approach angle" (reference B fig. 158)
The approach angle is determined by the horizontal line of the road surface and by the tangent line passing between the front
wheel and the most projecting low point of the vehicle.
The wider the angle, the lower the chance to hit an obstacle with the body or chassis, climbing a steep slope or overcoming an
obstacle.
Front wheel drive (FWD) versions: 17.9°
Four wheel drive (4WD) versions: 21°
Trailhawk versions with four wheel drive (4WD LOW): 30.5°
"Departure angle" (reference C fig. 158)
The departure angle is determined by the same lines of the "Approach angle", and refers to the rear part of the vehicle.
Front wheel drive (FWD) versions: 29.7°
Four wheel drive (4WD) versions: 32.1°
Trailhawk versions with four wheel drive (4WD LOW): 34.3°
"Breakover angle" (reference D fig. 158)
The value of the "Breakover angle" is linked to the ground clearance of the vehicle and indicates the attitude of the vehicle to
overcome a wedge, more or less steep, preventing the vehicle from resting on the ground with the body or chassis after
touching the wedge with its lowest and most projecting parts (usually the underbody), this would highly reduce wheel grip.
The wheels, without a suitable grip to the ground, will not have sufficient hold to move the vehicle, and will surge.
The higher the ground clearance, the wider the breakover angle. Always bear in mind that the higher the ground clearance, the
lower the stability, due to a higher centre of gravity which reduces the side tipping angle.
Front wheel drive (FWD) versions: 21.2°
Four wheel drive (4WD) versions: 24°
Trailhawk versions with four wheel drive (4WD LOW): 25.7°
173

WEIGHTS
Weights (kg) 1.4 Turbo MultiAir 1.6 16V MultiJet 2.0 16V MultiJet 120 / 140 HP 2.0 16V MultiJet
Unladen weight (with all fluids, fuel tank filled to 90% and without optional equipment) 1320 1390 1430 / 1530(*)1535
Payload including the driver(**)545 515 580 / 550(*)545
Maximum permitted loads(***)
1050 1050 1150 1150 – front axle
– rear axle 900 900 1000 1000
– total: 1865 1905 2010 / 2080(*)2080
Towable loads 1000 1000 1500 1500 – braked trailer
– trailer without brakes 400 400 400 400
Maximum load on roof(****)70 70 70 70
Maximum load on tow hitch (trailer with brakes) 60 60 60 60
(*) Versions with automatic transmission
(**) If special equipment is fitted (sun roof, tow hitch, etc.) the unladen vehicle weight increases, thus reducing the specified payload in relation to the maximum permitted loads.
(***) Loads not to be exceeded. The user is responsible for arranging goods in the luggage compartment and/or load platform within the maximum permitt ed loads.
(****) Versions with roof bars
174
TECHNICAL SPECIFICATIONS
