2014 INFINITI Q60 CONVERTIBLE Quick Reference Guide

Quick Reference Guide2014 Infiniti Q60
1276473_14a_Q60_Convertible_QRG_062113.indd 26/21/13 3:30 PM

*See your Owner’s Manual for information.
01 INSTRUMENT BRIGHTNESS CONTROL*
02 TRIP COMPUTER SWITCHES
03 HEADLIGHT AND TURN SIGNAL CONTROL
04 LOW TIRE PRESSURE WARNING LIGHT
05 VEHICLE INFORMATION DISPLA y
06 WINDSHIELD WIPER AND WASHER SWITCH
07 TRIP A/B RESET BUTTON*
08 STEERING WHEEL SWITCHES FOR AUDIO* / BLUETOOTH®
09 CRUISE CONTROL
10 PUSH BUTTON IGNITION SWITCH
11 VEHICLE Dy NAMIC CONTROL (VDC) OFF SWITCH*
01
0710
19
18
20
212221
111213
14
040317
12 TRUNK RELEASE SWITCH
13 REAR SONAR S y STEM SWITCH *
14 TILT AND TELESCOPIC STEERING COLUMN*
15 INTELLIGENT KEy PORT
16 HOOD RELEASE*
17 CONTROL PANEL DISPLA y
18 AUDIO Sy STEM
19 AUTOMATIC CLIMATE CONTROLS
20 FRONT PASSENGER AIR BAG STATUS LIGHT*
21 CLIMATE CONTROLLED SEAT SWITCH ES *
22 HARD TOP OPEN / CLOSE SWITCH
(C
ONVERTIBLE MODELS )
0908
Behind
steering wheel
Behind
steering wheel
Behind
steering wheel
Behind
steering wheel
Behind
steering wheel
Behind
steering wheel
05
02
06
15
16
1276473_14a_Q60_Convertible_QRG_062113.indd 36/21/13 3:30 PM

table of contents
Additional information about your vehicle is also available
in your Owner’s Manual, Navigation System Owner’s Manual
and at www.InfinitiUSA.com.
essential information Tire Pressure Monitoring System (TPMS) ............................2 Loose Fuel Cap.................................................2 Fuel-Filler Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . 3 Automatic Power Windows

.......................................
3 Accessing the Front Cup Holders

..................................
3
first drive features INFINITI Intelligent Key System...................................4 Trunk Lid Release...............................................5 Seat Adjustments...............................................5 Automatic Drive Positioner (if so equipped)
.........................
6 Seat Belt Guide (Convertible models)

..............................
6 Passenger Rear Seat Entry/Exit....................................6 Outside Mirror Control Switch.....................................7 Starting/Stopping the Engine

.....................................
7


Headlight Control Switch.........................................8 Windshield Wiper and Washer Switch

..............................
9


Automatic Climate Controls.......................................9 FM/AM/SiriusXM Satellite Radio With CD/DVD Player


(with Navigation System) (if so equipped)..........................11

USB/iPod
® Interface ...........................................12 Conventional (Fixed Speed) Cruise Control
.........................12 Intelligent Cruise Control (ICC) System (if so equipped) ..............13


Opening/Closing the Hard Top (Convertible models)

.................
14
system guide Trip Computer.................................................15 Bluetooth® Hands-free Phone System .............................15
System Operating Tips........................................15


Bluetooth
® System with Navigation (if so equipped) ...............16

Bluetooth® System without Navigation (if so equipped) ............18 Navigation System (if so equipped) ...............................19
DVD Player (if so equipped)......................................20

HomeLink
® Universal Transceiver.................................21
To view detailed
instructional videos, go to
www.infinitiownersinfo.mobi/2014/q60 or snap this barcode with an
appropriate barcode reader.
•

A cellular telephone should not be used for any purpose while


driving so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
•

Children 12 and under should always ride in the rear seat


properly secured in child restraints or seat belts according to
their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety –– Seats, seat belts and
supplemental restraint system (section 1)”, “Monitor, climate,
audio, phone and voice recognition systems (section 4)” and the
“Starting and driving (section 5)” of your Owner’s Manual.
1276473_14a_Q60_Convertible_QRG_062113.indd 46/21/13 3:30 PM

2
essential information
Loose Fuel Cap
A LOOSE FUEL CAP
warning message will appear in



the vehicle information display 01 when the fuel-filler

cap is not tightened correctly.

To tighten, turn the cap clockwise until a single click



is heard.
The warning message will disappear when the vehicle



detects the fuel-filler cap is properly tightened and the




reset button 02 is pressed for about 1 second.
If the cap is not properly tightened, the Malfunction




Indicator Light may illuminate.
For more information, refer to the “Instruments and controls (section 2)” and
the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
01
02
Tire Pressure Monitoring System (TPMS)
A
Ch
EC k t I r E P r ESSU r E warning message will
appear in the vehicle information display
01 and

the low tire pressure warning light 02 will illuminate

when one or more tires are low on pressure and air
is needed.



•


The tire pressures should be checked when

the tires are cold. The tires are considered cold
after the vehicle has been parked for 3 hours
or more or driven less than 1 mi (1.6 km) at
moderate speeds.
After tire pressures are adjusted, drive the vehicle
at speeds above 16 MPH (25 km/h). The C
h EC k

t

I r E P r ESSU r E warning message and low tire
pressure warning light will disappear.
When the low tire pressure warning light flashes for 1 minute and then r\
emains on, the TPMS
is not functioning properly. Have the system checked by an INFINITI reta\
iler.
Tire pressure rises and falls depending on the heat caused by the vehicl\
e’s operation and the
outside temperature. Low outside temperature can lower the temperature o\
f the air inside
the tire, which can cause a lower tire inflation pressure. This may caus\
e the low tire pressure
warning light to illuminate. If the warning light illuminates, check the\
tire pressure in your tires.



• Check the tire pressure (including the spare tire) often and always pr\
ior to long distance trips.
The Tire and Loading Information label contains valuable information. Pl\
ease refer to section
9, “Technical and consumer information”, in your Owner’s Manual\
for the location of the Tire
and Loading Information label.
For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and
the“Maintenance and do-it-yourself (section 8)” of your Owner’s Manual. 01
02
01
1276473_14a_Q60_Convertible_QRG_062113.indd 26/21/13 3:30 PM

3
Accessing the Front Cup Holders
To open the cup holders, push the lid 01 down

and release.
The flap 02 will fold down when inserting a

large container.
For more information, refer to the “Instruments and controls (section 2)” of
your Owner’s Manual.
Automatic Power Windows
y our power windows have an automatic adjusting
function to ensure windows close completely to help
seal against wind noise and weather leaks.
When the front doors are being opened, the windows
automatically lower slightly to avoid contact between
the windows and the side roof panels.
If your vehicle’s battery is discharged or
disconnected, your power window automatic
function will not operate.
Refer to your Owner’s Manual for information to
initialize your power window system.
If the power window functions do not operate
properly after initializing the system, have your
vehicle checked by an INFINITI retailer.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
01
02
Fuel-Filler Door
The fuel-filler door is located on the passenger’s side of
the vehicle.
Unlock the fuel-filler door using one of the following
operations, then push and release the left side of the
door to open.
•


Push the door handle request switch while

carrying the INFINITI Intelligent Key with you.
•


Press the
UNLOC k button on the Intelligent Key.
•


Push the power door lock switch to the UNLOCK position.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
1276473_14a_Q60_Convertible_QRG_062113.indd 36/21/13 3:30 PM

01
07
06
02
03
04
05
4
first drive features
INFINITI Intelligent Key System
The INFINITI Intelligent Key system allows you to lock or
unlock the vehicle, open the trunk and start the engine.
It is important to make sure the Intelligent Key is
with you (that is, in your pocket or purse).
The operating range of the Intelligent Key is within
31.5 in (80 cm) from each request switch.
To lock the vehicle, push either door handle request
switch
01 once or press the
button
02 on the key fob.
To unlock the vehicle, perform one of the following procedures:



•

Push either door handle request switch 01 once; the

corresponding door will unlock. Push the door handle
request switch
01 again within 1 minute; all other doors

will unlock, or



•


Press the
button
03 on the key fob to unlock the driver’s

side door. Press the
button again; all other doors will unlock.
To release the trunk lid, press the hOLD button
04 for more than

1 second. Lift the trunk lid to access the trunk.
To retract the hard top (Convertible models), push and hold the
door handle request switch
01 until the hard top is fully open.
The Intelligent Key can also be used to activate the panic alarm by pres\
sing and holding the

button
05 for more than 1 second. Once activated, the panic alarm and headlights w\
ill
stay on for a period of time.
INFINITI INTELLIGENT KE
y BATTER y DISCHARGE
If the battery in the Intelligent Key is almost
discharged, the guide light
06 of the Intelligent

Key port blinks and the Intelligent Key battery
discharge indicator
07 is displayed in the vehicle

information display.
To start the engine under these circumstances, insert
the Intelligent Key into the key port with the buttons
facing upward and the key ring end toward you until
it latches into place. Then push the ignition switch to
start the engine.
To remove the Intelligent Key from the port, push the
ignition switch to turn the engine off and then pull the
Intelligent Key out of the port.
The Intelligent Key port does not charge the Intelligent Key battery. If\
you see the low battery
indicator
07 , replace the battery in the Intelligent Key.
Do not insert the mechanical key or any other objects into the key port \
because it will

damage the key port.
For more information, refer to the “Pre-driving checks and adjustments (section 3)”, the “Starting and driving (section 5)” and the
“Maintenance and do-it yourself (section 8)” of your Owner’s Manual.
1276473_14a_Q60_Convertible_QRG_062113.indd 46/21/13 3:31 PM

Seat Adjustments
To slide the seat forward or backward, push the
control switch
01 forward or backward.
To recline the seatback, push the switch
02

forward or backward.
SEAT LIFTER
To adjust the angle of the front seat cushion or height
of the seat, push the front or rear end of the switch
01 up or down.
POWER LUMBAR SUPPORT (driver’s seat)

To adjust the seat lumbar support, push the front or back end of the swi\
tch 03 .
For more information, refer to the “Safety –– Seats, seat belts and supplemental restraint system (se\
ction 1)” of your

Owner’s Manual.
01
02
010203
Trunk Lid Release
Use one of the following methods to open the trunk:
Push the trunk open request switch
01 for more

than one second while carrying the INFINITI



Intelligent Key with you.
Press the trunk button hOLD on the Intelligent Key for
more than one second.
Push down on the trunk lid
release switch
02
located on the instrument panel to the left of the




steering wheel.
For more information, refer to the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
5
1276473_14a_Q60_Convertible_QRG_062113.indd 56/21/13 3:31 PM

6
first drive features
Seat Belt Guide (Convertible models)
Unsnap the seat belt guide 01 to allow rear seat passengers easier access.
Before fastening the seat belt, ensure the seat belt is




inserted into the seat belt guide and the snaps are




securely fastened.
When using the seat belt guide, do not allow the seat



belt to twist so that it will retract correctly.
For more information, refer to the “Safety –– Seats, seat belts and supplemental restraint system (section 1)”\
of your Owner’s Manual.
Automatic Drive Positioner (if so equipped)
Two positions for the driver’s seat, steering column
and outside mirrors can be stored in the automatic
drive positioner memory.
Follow these procedures to set the memory positions:



•

Confirm the shift lever is in the
P (PA rk ) position
(automatic transmissions) or the parking brake is applied (manual tra\
nsmissions).



•

Push the ignition switch to the
ON position.



•

Adjust the driver’s seat, steering column and outside mirrors to the \
desired positions using
the adjusting switches for each feature.



•
Push the SE
t switch and within 5 seconds, push the memory switch (1 or 2) for at least 1 second.



•

The indicator light on the memory switch you select will illuminate for \
approximately 5 seconds.




•

The driver’s seat, steering column and outside mirror positions are n\
ow set to your preference.
These memorized positions can also be linked to your INFINITI Intelligen\
t Key.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
Passenger Rear Seat Entry/Exit
For ease in entering and exiting the rear passenger
areas of the vehicle, perform the following steps:



1.

Release the front seatbelt guide and seat belt.

(Convertible models)



2.

Pull the seatback lever 01 upward to fold the
front seatback forward. Make sure that the front
seatback is completely folded.



3.


To slide the front seat forward, firmly push

the seatback button
02. The front seat will
move forward.
To stop the front seat from sliding, press the seatback button 02 again. To return the front seat to its original position:



1.

Push or pull the seatback backward until it locks in place.



2.

Press the seatback button 02 to slide the front seat backward.
For more information, refer to the “Safety –– Seats, seat belts and supplemental restraint system (se\
ction 1)” of your

Owner’s Manual.
Coupe
Convertible
01
01
02
02
01
1276473_14a_Q60_Convertible_QRG_062113.indd 66/21/13 3:31 PM
