2014 HONDA RIDGELINE display

When VSA is off, the VSA OFF
indicator comes on as a reminder.
When VSA activates, you will see the
VSA system indicator blink.
If this indicator comes on while
driving, pull to the side of the road
when it is saf e, and turn of f the
engine. Reset the system by
restarting the engine. If the VSA
system indicator stays on or comes
back on while driving, have the VSA
system inspected by your dealer.The main f unction of the
VSA system is generally known as
Electronic Stability Control (ESC).
The system also includes a traction
control f unction. If the low tire pressure/TPMS
indicator comes on, see page .
Or, if the multi-inf ormation display
shows a ‘‘CHECK TPMS
SYSTEM’’ message with the
indicator f lashing, see page . If the low tire pressure indicator or
TPMS indicator comes on, see
page .
You will also see a ‘‘CHECK VSA
SYSTEM’’ message on the multi-
inf ormation display if there is a
problem with the VSA system. If the indicator does not come on
when the ignition switch is turned to
the ON (II) position, there may be a
problem with the VSA system. Have
your dealer inspect your vehicle as
soon as possible.
In this case, you cannot turn of f the
VSA using the OFF switch again.
Without VSA, your vehicle will have
normal braking and cornering ability,
but it will not have VSA traction and
stability enhancement.
91
276
279
On models with navigation system
On models with navigation system
On models without navigation system
Vehicle Stability A ssist (VSA), aka Electronic Stability Control (ESC), System
VSA OFF Indicator
Vehicle Stability Assist
(VSA ) System Indicator
289
NOTE:
12/08/09 16:37:16 31SJC670_296
Driving

Drive slower than normal in all
driving situations, and obey posted
speed limits for vehicles with trailers.
When towing a fixed-sided trailer (e.g.,
camper), do not exceed 55 mph (88
km/h). At higher speeds, the trailer
may sway or affect vehicle handling.
When towing a trailer on level roads
under normal driving conditions, do
not use D3. This will increase the
automatic transmission fluid
temperature and may cause
overheating.With heavy cargo on the pickup
bed, your vehicle has a higher
center of gravity. Drive slowly
and cautiously, and allow more time
and distance for braking. Loading
heavy cargo could affect your
vehicle’s handling and performance.
Maketurnsmoreslowlyandwider
than normal. The trailer tracks a
smaller arc than your vehicle, and it
canhitorrunoversomethingthe
vehicle misses.
Allow more time and distance f or
braking. Do not brake or turn
suddenly as this could cause the
trailer to jackknif e or turn over.
When driving down hills, reduce
your speed, and use D3. Do not
‘‘ride’’ the brakes. If youmuststopwhenfacinguphill,
use the f oot brake or parking brake.
Do not try to hold the vehicle in
place by pressing on the accelerator,
as this can cause the automatic
transmission to overheat. When climbing hills, closely watch
your temperature gauge. If it nears
the red (Hot) mark, turn the air
conditioning of f , reduce speed and, if
necessary, pull to the side of the
road to let the engine cool.
If the automatic transmission f luid
temperature increases and exceeds
the specif ied limit, the A/T
temperature indicator comes on (see
page ).
You will also see an ‘‘A/T TEMP
HIGH’’ message on the multi-
inf ormation display (see page ). 69
91
On models with navigation system
T owing Speeds and Gears
Making T urns and BrakingDriving on Hills
Towing a Trailer
Remember, it
takes longer to slow down and
stop when towing a trailer.
302
12/08/09 16:39:06 31SJC670_309
Driving

This section explains why it is
important to keep your vehicle well
maintained and how to f ollow basic
maintenance saf ety precautions.
This section also includes
instructions on how to read the
Maintenance Minder messages on
the inf ormation display or multi-
inf ormation display (depending on
the model), and instructions for
simple maintenance tasks you may
want to take care of yourself.U.S. Vehicles:
If you have the skills and tools to
perf orm more complex maintenance
tasks on your vehicle, you may want
to purchase the service manual. See
page f or inf ormation on how to
obtain a copy, or see your dealer. ......................
Maintenance Saf ety .310
.................
Maintenance Minder . 311
..............................
Fluid Locations .323
........................
Adding Engine Oil .324
Changing the Engine Oil and ...........................................
Filter .325
..............................
Engine Coolant .327
....................
Windshield Washers .328
....
Automatic Transmission Fluid . 329
....................................
Brake Fluid .331
....................
Power Steering Fluid . 332
....................................
Timing Belt .333
.............................................
Lights .333
................
Cleaning the Seat Belts . 341
.....................................
Floor Mats .342
..................
Dust and Pollen Filter . 342
.................................
Wiper Blades .343
...........................................
Wheels .345
...............................................
Tires .345
...................
Checking the Battery . 353
.............................
Vehicle Storage .354
..................................
Interior Care .355
405
Maintenance
Maintenance, replacement, or
repair of emissions control
devices and systems may
be done by any automotive
repair establishment or
individual using parts that are
‘‘certif ied’’ to EPA standards.
309
TM
12/08/09 16:40:00 31SJC670_316

µ
µ
µ
µ
µ
µ
µ
µ
µ
µ µ
µ
Your vehicle displays engine oil lif e
and maintenance service items on
the inf ormation display or multi-
inf ormation display (depending on
the model) to show you when you
should have your dealer perf orm
engine oil replacement and indicated
maintenance services.
Based on the engine operating
conditions and accumulated engine
revolutions, the onboard computer
in your vehicle calculates the
remaining engine oil life and
displays it as a percentage. The remaining engine oil lif e is
shownonthedisplayaccordingto
this table:
To see the current engine oil lif e,
turn the ignition switch to the ON
(II) position, and press the SELECT
button repeatedly until the engine oil
life display appears (see page ).78
CONT INUED
Calculated Engine
Oil Lif e (%)100% 91% 90% 81%
80% 71%
70% 61%
60% 51%
50% 41%
40% 31%
30% 21%
20% 16%
15% 11%10% 6% 5% 1% 0% Displayed
Engine Oil Lif e (%) 100%90%
80%
70%
60%
50%
40%
30%
20%
15%
10%5%
0%
On models without navigation system
Engine Oil L if e Display
Maintenance Minder
Maint enance
311
SELECT BUTTON
ENGINE OIL LIFE DISPLAY
U.S. model is shown.
TM
12/08/09 16:40:18 31SJC670_318

The 15 and 10 percent oil lif e
indicator reminds you that the time
is coming soon to take your vehicle
in f or the required maintenance.
If the remaining engine oil lif e is 15
to 6 percent, you will see the engine
oil lif e indicator every time you turn
the ignition switch to the ON (II)
position. The Maintenance Minder
indicator will also come on, and the
maintenance item code(s) for other
scheduled maintenance items
needing service will be displayed
near the ‘‘OIL LIFE’’ message. When the remaining engine oil lif e is
5 to 1 percent, you will see a
‘‘SERVICE’’ message along with the
same maintenance item code(s),
everytimeyouturntheignition
switch to the ON (II) position.
Maintenance Minder
312
‘‘SERVICE’’ MESSAGE
ENGINE OIL LIFE INDICATOR
U.S. model is shown. MAINTENANCE ITEM CODE(S)
MAINTENANCE MINDER INDICATOR
TM
12/08/09 16:40:24 31SJC670_319
Maint enance

The maintenance item code or codes
indicate the main and sub items
required at the time of the oil change
(see page ).When the remaining engine oil lif e is
0 percent, the engine oil lif e indicator
will blink. The display comes on
everytimeyouturntheignition
switch to the ON (II) position. The
Maintenance Minder indicator
( ) also comes on and remains
on in the instrument panel. When
you see this message, immediately
have the indicated maintenance done
by your dealer.If you do not perf orm the indicated
maintenance, negative distance
traveled is displayed and begins to
blink af ter the vehicle has been
driven 10 miles (10 km) or more.
Negative distance traveled means
your vehicle has passed the
maintenance required point.
Immediately have the indicated
maintenance done by your dealer.
You can switch the information
display f rom the engine oil lif e
display to the odometer or the trip
meter. Press and release the
SELECT button on the dashboard.
Whentheengineoillifeis15to1
percent, the Maintenance Minder
indicator ( ) comes on every
time you turn the ignition switch to
the ON (II) position, then it goes out
if you switch the inf ormation display.
When you see this message, have
the indicated maintenance
performed by your dealer as soon
as possible.
314
CONT INUED
Maintenance Minder
313
U.S. model is shown.
TM
12/08/09 16:40:34 31SJC670_320
Maint enance

Immediately have the service
perf ormed, and make sure to reset
the display as described as f ollows. When the engine oil lif e is 0 percent
or negative distance traveled, the
Maintenance Minder indicator
( )remainsonevenif you
change the inf ormation display.All maintenance items displayed on
the inf ormation display are in code.
For an explanation of these
maintenance codes, see page .Your dealer will reset the display
after completing the required
maintenance service. You will see
‘‘OIL LIFE 100%’’ on the
information display the next time
you turn the ignition switch to the
ON (II)
position.
If maintenance service is done
by someone other than your
dealer, reset the Maintenance
Minder as f ollows: Turn the ignition switch to the ON
(II) position.
To change the inf ormation display
f rom the engine oil lif e display to the
odometer or the trip meter, press
and release the SELECT button.
Press the SELECT button
repeatedly until the engine oil lif e
is displayed.
1.
2.
322
On models without navigation system On models without navigation system
Maintenance Main
Resetting the Engine
Maintenance Minder
314
MAINTENANCE MAIN ITEMMAINTENANCE SUB ITEM(S)
TM
12/08/09 16:40:43 31SJC670_321
Maint enance
Items and Sub Items
Oil Life Display

CONT INUED
Press the TRIP/RESET button f or
about 10 seconds. The engine oil
lif e and the maintenance item
code(s) will blink.Press the TRIP/RESET button f or
another 5 seconds. The
maintenance item code(s) will
disappear, and the engine oil lif e
will reset to ‘‘100.’’To see the current engine oil life,
turn the ignition switch to the ON
(II) position, and push and release
the SEL/RESET button on the
dashboard repeatedly, until the
engine oil life is displayed (see
page
).
3.
4.
83
On models with navigation system
Maintenance Minder
315
U.S. model is shown.
ENGINE OIL LIFE DISPLAY SEL/RESET BUTTON
TM
12/08/09 16:40:50 31SJC670_322
Maint enance
