2014 HONDA ACCORD HYBRID display

102
uuGauges and Multi-Information DisplayuMulti-Information Display
Instrument Panel
■Customization flow
Press the button.
SEL/RESETVehicle Settings
“Trip A” Reset Timing
Language SelectionAdjust Outside Temp. Display
Memory Position Link
Door Unlock Mode
Keyless Access Light Flash
4
4
4
4
TPMS Calibration
Driver Assist System Setup*
Meter Setup
Driving Position Setup *
Keyless Access Setup
SEL/RESET
SEL/RESET
SEL/RESET
SEL/RESET
“Trip B” Reset TimingFuel Efficiency Backlight
4
Head-up WarningACC Pre-Running Car Detect Beep *
ACC Display Speed Unit*
4Turn-by-Turn Display
*
SEL/RESET
Keyless Access Beep
Forward Collision Warning Distance
4
4
4
* Not available on all models
Main MenuTable of Contents

103
uuGauges and Multi-Information DisplayuMulti-Information Display
Continued
Instrument Panel
Exit
4
4
4
Door Setup
Maintenance Reset
Default All
SEL/RESET
4
SEL/RESET
4
Lighting SetupSEL/RESET
4
Key And Remote Unlock Mode
Auto Door Lock
Auto Door Unlock
Keyless Lock Answer Back
Security Relock Timer
Interior Light Dimming Time
Headlight Auto Off Timer
Auto Light Sensitivity
4
4
Main MenuTable of Contents

104
uuGauges and Multi-Information DisplayuMulti-Information Display
Instrument Panel
■List of customizable options
*1:Default Setting Setup Group Customizable Features Description Selectable Settings
TPMS
Calibration—Calibrates the TPMS.Cancel
/Calibrate
Driver Assist
System
Setup *
Forward Collision
Warning DistanceChanges at which distance
FCW alerts, or turns FCW
on and off.Long /Normal *1
/Short /Off
Head-up WarningTurns the heads-up warning lights on to flash or off.On *1
/Off
ACC Pre-Running Car
Detect Beep *Causes the system to beep when the system detects
a vehicle, or when the vehicle goes out of ACC range.On
*1
/Off
ACC Display Speed Unit *Changes the ACC display speed unit.mph
*1
/km/h (U.S.)
mph /km/h *1
(Canada)
Meter Setup
Language SelectionChanges the displayed language.English *1
/French /Spanish
Adjust Outside Temp.
DisplayAdjusts the temperature reading by a few degrees.-5°F ~ ±0°F *1
~ +5°F (U.S.)
-3°C ~ ±0°C *1
~ +3°C (Canada)
“Trip A” Reset TimingChanges the setting of how to reset trip meter A,
average fuel economy A, average speed A, and
elapsed time A.When Refueled /IGN Off /
Manually Reset *1
“Trip B” Reset TimingChanges the setting of how to reset trip meter B,
average fuel economy B, average speed B, and
elapsed time B.When Refueled
/IGN Off /
Manually Reset *1
* Not available on all models
Main MenuTable of Contents

105
uuGauges and Multi-Information DisplayuMulti-Information Display
Continued
Instrument Panel
*1: Default Setting
*2: Refer to the navigation system manual for complete details.Setup Group Customizable Features Description Selectable Settings
Meter Setup
Fuel Efficiency BacklightTurns the ambient meter feature on and off.On
*1
/Off
Turn by Turn Display *, *2Selects whether the turn-by-turn display comes on
or not during the route guidance.On*1
/Off
Driving
Position
Setup * Memory Position Link
Changes the driver's seat position to a stored setting. On
*1
/Off
Keyless
Access
Setup
Door Unlock ModeChanges which doors unlock when you grab the
driver’s door handle.Driver Door Only *1
/All Doors
Keyless Access Light FlashCauses some exterior lights to blink when you
unlock/lock the doors.On *1
/Off
Keyless Access BeepSets the beeper sound or not when you grab either
front door handle.On *1
/Off
Lighting
Setup Interior Light Dimming
Time
Changes the length of time the interior lights stay on
after you close the doors.
60sec
/30sec *1
/15sec
Headlight Auto Off
Timer Changes the length of time the exterior lights stay
on after you close the driver's door.
60sec
/30sec /15sec *1
/0sec
Auto Light Sensitivity Changes the timing for the headlights to come on. Max/High /Mid *1
/Low /Min
* Not available on all models
Main MenuTable of Contents

106
uuGauges and Multi-Information DisplayuMulti-Information Display
Instrument Panel
*1: Default SettingSetup Group Customizable Features Description Selectable Settings
Door Setup
Auto Door LockChanges the setting for when the doors
automatically lock.With Vehicle Speed
*1
/Shift
from P /Off
Auto Door UnlockChanges the setting for when the doors
automatically unlock.
All Doors When Driver’s
Door Opens *1
/All Doors
When Shifted To Park /All
Doors When Ignition Switched Off/Off
Key And Remote Unlock
ModeSets up either the driver's door or all doors to unlock
on the first operation of the remote or built-in key.Driver Door *1
/ All Doors
Keyless Lock Answer
BackLOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.On *1
/Off
Security Relock TimerChanges the time it takes for the doors to relock and
the security system to set after you unlock the
vehicle without opening any door.90sec /60sec /30sec *1
Maintenance Reset—Resets/Cancels the engine oil life display when you
have performed the maintenance service. Cancel
/Reset
Default All—Cancels/Resets all the customized settings as default.Cancel /Set
Main MenuTable of Contents

107
uuGauges and Multi-Information DisplayuMulti-Information Display
Continued
Instrument Panel
■Example of customization settings
The steps for changing the “Trip A” Reset Timing setting to When Refueled are
shown below. The default setting for “Trip A” Reset Timing is Manually Reset .
1. Press the button to select Vehicle
Settings , then press the SEL/RESET
button.
2. Press the button until Meter
Setup appears on the display.
3. Press the SEL/RESET button.
uLanguage Selection appears first in the
display.
Main MenuTable of Contents

108
uuGauges and Multi-Information DisplayuMulti-Information Display
Instrument Panel
4.Press the button until “Trip A”
Reset Timing appears on the display, then
press the SEL/RESET button.
uThe display switches to the
customization setup screen, where you
can select When Refueled , IGN Off ,
Manually Reset , or Exit .
5. Press the button and select When
Refueled , then press the SEL/RESET
button.
uThe When Refueled Setup screen
appears, then the display returns to the customization menu screen.
6. Press the button until Exit appears
on the display, then press the SEL/RESET
button.
7. Repeat Step 6 until you return to the normal screen.
Main MenuTable of Contents

110
Controls
Clock
Adjusting the Clock
You can adjust the time in the clock display with the power mode is in ON. ■Using the Settings menu on th e audio/information screen
1. Press the SETTINGS button.
1. Press and hold the DISP button.
2. Rotate to select System Settings, then
press .
uRepeat the procedure to select Clock,
then Clock Adjustment .
3. Rotate to change hour, then press .
4. Rotate to change minute, then press .
■Adjusting the Time
1Adjusting the Clock
The clock is automatically updated through the
navigation system, so the time does not need to be
adjusted.
These indications are used to show how to operate
the selector knob.
Rotate to select.
Press to enter.
You can customize the clock display to show the 12
hour clock or 24 hour clock.
2 Customized Features P. 293
You can turn the clock display on and off. 2 Customized Features P. 293
Models with navigation system
Models without navigation system
Models without navigation system
Models with one display
Models with two displays
All models
