2014 DODGE JOURNEY Owners Manual

WARNING!
Cargo must be securely tied before driving your
vehicle. Improperly secured loads can fly off the
vehicle, particularly at high speeds, resulting in per-
sonal injury or property damage. Follow the roof rack
cautions when carrying cargo on your roof rack.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 295

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
INSTRUMENT PANEL FEATURES ..........300
 INSTRUMENT CLUSTER .................301
 INSTRUMENT CLUSTER DESCRIPTIONS .....302
 ELECTRONIC VEHICLE INFORMATION
CENTER (EVIC) .......................311
▫ Electronic Vehicle Information Center (EVIC)
Displays ............................313
▫ EVIC White Indicators ..................316
▫ EVIC Amber Indicators .................317
▫ EVIC Red Indicators ...................317 ▫
Oil Change Due ..................... .320
▫ Fuel Economy ........................321
▫ Vehicle Speed ........................322
▫ Trip Info .......................... .323
▫ TirePSI............................ .324
▫ Vehicle Info (Customer Information Features) . .324
▫ Messages .......................... .324
▫ Turn Menu OFF .......................325
4

Uconnect® SETTINGS ...................325
▫ Hard-Keys ..........................325
▫ Soft-Keys .......................... .325
▫ Customer Programmable Features —
Uconnect® 4.3 Settings ..................325
▫ Customer Programmable Features —
Uconnect® System 8.4 Settings ............337
 Uconnect® MULTIMEDIA — VIDEO
ENTERTAINMENT SYSTEM (VES™) —
IF EQUIPPED ........................ .350
▫ Getting Started .......................351
▫ Single Video Screen ....................351
▫ Play Video Games .....................352
▫ Listen To An Audio Source On Channel 2
While A Video Is Playing On Channel 1 ......353▫
Important Notes For Single Video Screen
System ............................ .354
▫ Play A DVD Using The Touchscreen Radio . . .355
▫ VES™ Remote Control — If Equipped .......356
▫ Remote Control Storage .................358
▫ Locking The Remote Control .............359
▫ Replacing The Remote Control Batteries ......360
▫ Headphones Operation .................360
▫ Replacing The Headphone Batteries .........361
▫ Controls ............................361
▫ Unwired® Stereo Headphone Lifetime Limited
Warranty .......................... .362
▫ System Information ....................364
298 UNDERSTANDING YOUR INSTRUMENT PANEL

iPod®/USB/MP3 CONTROL ..............372
 STEERING WHEEL AUDIO CONTROLS ......373
▫ Right-Hand Switch Functions .............373
▫ Left-Hand Switch Functions For Radio
Operation .......................... .373
▫ Left-Hand Switch Functions For Media (i.e., CD)
Operation ..........................374
 CD/DVD DISC MAINTENANCE ...........374
 RADIO OPERATION AND MOBILE PHONES . .375
CLIMATE CONTROLS ...................375
▫ Manual Climate Controls With Touchscreen —
If Equipped ..........................376
▫ Rear Manual Temperature Control (MTC) —
If Equipped ........................ .385
▫ Automatic Temperature Control (ATC) With
Touchscreen — If Equipped ..............389
▫ Rear Automatic Temperature Control (ATC) —
If Equipped ........................ .398
4
UNDERSTANDING YOUR INSTRUMENT PANEL 299

INSTRUMENT PANEL FEATURES
1 — Side Window Demist Outlet6 — Switch Bank11 — Engine Start/Stop Button
2 — Air Outlet 7 — Uconnect® Hard Controls12 — Hood Release Lever
3 — Instrument Cluster 8 — SD Memory Card Slot13 — Dimmer Controls
4 — Uconnect® System 9 — Power Outlet14 — Headlight Switch
5 — Glove Compartment 10 — CD/DVD Slot
300 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT CLUSTER
4
UNDERSTANDING YOUR INSTRUMENT PANEL 301

INSTRUMENT CLUSTER DESCRIPTIONS
1. Tachometer
This gauge measures engine revolutions per minute
(RPM x 1000). Before the pointer reaches the red area,
ease up on the accelerator to prevent engine damage.
2. Air Bag Warning LightThis light will turn on for four to eight seconds
as a bulb check when the ignition switch is first
turned to ON/RUN. If the light is either not on
during starting, stays on, or turns on while
driving, have the system inspected at an authorized
dealer as soon as possible. Refer to “Occupant Restraints”
in “Things To Know Before Starting Your Vehicle” for
further information. 3. Malfunction Indicator Light (MIL)
The Malfunction Indicator Light (MIL) is part of
an onboard diagnostic system, called OBD II, that
monitors engine and automatic transmission con-
trol systems. The light will illuminate when the key is in
the ON/RUN position, before engine start. If the bulb
does not come on when turning the key from OFF to
ON/RUN, have the condition checked promptly.
Certain conditions, such as a loose or missing gas cap,
poor fuel quality, etc., may illuminate the MIL after
engine start. The vehicle should be serviced if the light
stays on through several of your typical driving cycles. In
most situations, the vehicle will drive normally and will
not require towing.
