2014 Citroen DS5 HYBRID4 display

149Driving
DS5-HYBRID_EN_CHAP04_CONDUITE_ED02-2013
Memorising speeds This memorising of speeds applies to both the speed limiter and the cruise control.
 Go to the main menu by pressing the "MENU"button.
You can memorise up to 5 speeds in the system. By default, some speeds are already memorised.
For safety reasons, the driver must only carry out these operations using the audio system screen when stationary.
 Go to the main menu by pressing "SET UP" .
With the Audio System With eMyWay
 Select the "Personalisation-configuration" menu and confirm.  Select " Vehicle parameters" menu and confirm.  Select the "Driving assistance" line and conform.  Select the "Speeds memorised" line and confirm.  Modify the speed.  Select " OK " and confirm to save the modifications.
 Select the "Configuration" menu and confirm.  Select the " Vehicle parameters" menu and confirm.  Select the "Driving assistance" line and confirm.  Select the "Speeds memorised" line and confirm.  Modify the speed.  Select " OK " and confirm to save the modifications.
Access
 press the steering mounted "MEM" button to display the list of memorised speeds.
Selection
To select a memorised speed:  Press and hold the "+" or "-" button; the system stops at the nearest memorised speed.  Press and hold the "+" or "-" button again to select another memorised speed. A reminder of the speed and the state of the system (active / inactive) is displayed in the instrument panel.

DS5-HYBRID_EN_CHAP04_CONDUITE_ED02-2013
The programmed information is grouped together in the instrument panel screen. 6. Speed limiter on / off indication. 7. Speed limiter mode selection indication. 8. Programmed speed value. 9. Selection of a memorised speed.
Displays in the instrument panel
Speed limiter
The speed limiter cannot, in any circumstances, replace the need to respect speed limits, nor can it replace the need for vigilance and
responsibility on the part of the driver.
The functions of this system are grouped together on the steering mounted controls. 1. Speed limiter mode selection wheel. 2. Programmed value decrease button. 3. Programmed value increase button. 4. Speed limiter on / off button. 5. List of memorised speeds display button.
Steering mounted controls
System which prevents the vehicle from exceeding the speed programmed by the driver. When the programmed speed limit is reached, pressing the accelerator pedal no longer has any effect.
This information also appears in the head-up display. For more information, refer to the "Head-up display" section.
Operation
The speed limiter is switched on manually: it requires a programmed speed of at least 20 mph (30 km/h). The speed limiter is switched off by manual switched off by manual switched offoperation of the control. The programmed speed can be exceeded temporarily by pressing the accelerator firmly beyond the point of resistance. To return to the programmed speed, simply release the accelerator pedal. The programmed speed remains in the memory when the ignition is switched off.
For more information on the list of memorised speeds, refer to the "Memorising speeds" section.

151Driving
DS5-HYBRID_EN_CHAP04_CONDUITE_ED02-2013
Programming
Exceeding the programmed speed
Exiting the speed limiter mode
Operating fault
On a steep descent or in the event of sharp acceleration, the speed limiter will not be able to prevent the vehicle from exceeding the programmed speed. To avoid any risk of jamming of the pedals: - ensure that the mat is positioned c o r r e c t l y, - do not fit one mat on top of another.
 Switch the speed limiter back on by pressing button 4 again.
You can then change the programmed speed using buttons 2 and 3 : - by + or - 1 mph (km/h) = short press, - in steps of + or - 5 mph (km/h) = maintained press. If speed memorisation is available and activated on your vehicle, the programmed speed will stop at the closest memorised speed; refer to the corresponding section.
 Turn dial 1 to the "LIMIT" position: the speed limiter mode is selected but is not switched on (Pause). You do not have to switch the speed limiter on in order to set the speed.  Set the speed value by pressing button 2or 3 (e.g.: 55 mph (90 km/h)).
 Switch the speed limiter on by pressing button 4 .  Switch the speed limiter off by pressing button 4 : the display confirms that it has been switched off (Pause).
Pressing the accelerator pedal to exceed the programmed speed will not have any effect unless you press the pedal firmly past the firmly past the firmlypoint of resistance . The speed limiter is deactivated temporarily and the programmed speed, which is still displayed, flashes. Returning to the programmed speed, by means of intentional or unintentional
deceleration of the vehicle, automatically cancels the flashing of the programmed speed.
 Turn dial 1 to the "0" position: the speed limiter mode is deselected. It disappears from the screen.
In the event of a fault with the speed limiter, the speed is cleared resulting in flashing of the dashes. Have it checked by a CITROËN dealer or a qualified workshop.

DS5-HYBRID_EN_CHAP04_CONDUITE_ED02-2013
The cruise control system cannot, in any circumstances, replace the need to respect speed limits, nor can it replace the need for vigilance and responsibility on the part of the driver. You are advised to keep your feet near the pedals
at all times.

Cruise control
The functions of this system are grouped together on the steering mounted controls. 1. Cruise control mode selection dial. 2. Speed programming / value decrease button. 3. Speed programming / value increase
button. 4. Cruise control off / resume button. 5. Stored speeds display button.
Steering mounted controls
The programmed information is grouped together in the instrument panel screen. 6. Cruise control off / resume indication. 7. Cruise control mode selection indication. 8. Programmed speed value. 9. Selecting a stored speed.
Displays in the instrument panel System which automatically maintains the speed of the vehicle at the value programmed by the driver, without any action on the accelerator pedal.
This information also appears in the head-up display. For more information, refer to the "Head-up display" section.
Operation
The cruise control is switched on manually: it requires a minimum vehicle speed of 25 mph (40 km/h) and the engagement of second gear with sequential gear changing (position M ). The cruise control is switched off manually or switched off manually or switched offby pressing the brake pedal or on triggering of the "electronic stability programme" system for safety reasons. It is possible to exceed the programmed speed temporarily by pressing the accelerator pedal. To return to the programmed speed, simply release the accelerator pedal. Switching off the ignition cancels any programmed speed value.
For more information on the list of memorised speeds, refer to the "Memorising speeds" section.

DS5-HYBRID_EN_CHAP04_CONDUITE_ED02-2013
This system indicates the proximity of an obstacle (person, vehicle, tree, gate, etc.) which comes within the field of detection of sensors located in the bumper. Certain types of obstacle (stake, roadworks cone, etc.) detected initially will no longer be detected at the end of the manoeuvre due to the presence of blind spots.

Parking sensors
This function cannot, in any circumstances, take the place of the vigilance and responsibility of the driver.
Rear parking
sensors
The system is switched on by engaging reverse gear. This is accompanied by an audible signal. The system is switched off when you come out of reverse gear.
Audible assistance
The proximity information is given by an intermittent audible signal, the frequency of which increases as the vehicle approaches the obstacle. The sound emitted by the speaker (right or left) indicates the side on which the obstacle is located.
When the distance between the vehicle and the obstacle becomes less than approximately thirty centimetres, the audible signal becomes continuous.
Visual assistance
This supplements the audible signal by displaying bars in the multifunction screen
which move progressively nearer to the vehicle. When the obstacle is near, the "Danger" symbol is displayed in the screen.

155Driving
DS5-HYBRID_EN_CHAP04_CONDUITE_ED02-2013
In bad weather or in winter, ensure
that the sensors are not covered with mud, ice or snow. When reverse gear is engaged, an audible signal (long beep) indicates that the sensors may be dirty. Certain sound sources (motorcycle, lorry, pneumatic drill, etc.) may trigger the audible signals of the parking sensor system.
In the event of a malfunction of the system, when reverse gear is engaged this warning lamp is displayed in the instrument panel and/or a message appears in the screen, accompanied by an audible signal (short beep). Contact a CITROËN dealer or a qualified workshop.
Operating fault
In addition to the rear parking sensors, the front parking sensors are triggered when an obstacle is detected in front and the speed of the vehicle is still below 6 mph (10 km/h). The front parking sensors are interrupted if the vehicle stops for more than three seconds in for ward gear, if no further obstacles are detected or when the speed of the vehicle exceeds 6 mph (10 km/h).
Front parking sensors
The function will be deactivated automatically if a trailer is being towed or a bicycle carrier is fitted (vehicle fitted with a towbar or bicycle carrier recommended by CITROËN).
Deactivation / Activation of the front and rear parking sensors
The function is deactivated by pressing this button. The indicator lamp in the button comes on. Pressing this button again reactivates the
function. The indicator lamp in the button goes off.
The sound emitted by the speaker (front or rear) indicates whether the obstacle is in front or behind.

161Visibility
DS5-HYBRID_EN_CHAP05_VISIBILITE_ED02-2013
Selection ring for main lighting mode
Turn the ring to position the symbol required facing the mark.
Lighting off.
Automatic illumination of headlamps.
Sidelamps only.
Dipped or main beam headlamps. Dipping the headlamps
Pull the stalk to switch the lighting between dipped / main beam headlamps.
In the lighting off and sidelamps modes, the driver can switch on the main beam headlamps
temporarily ("headlamp flash") by maintaining a pull on the stalk.
Displays
Illumination of the corresponding indicator lamp in the instrument panel confirms the lighting switched on.

DS5-HYBRID_EN_CHAP05_VISIBILITE_ED02-2013
The sidelamps and dipped beam headlamps are switched on automatically, without any action on the part of the driver, when a low level of external light is detected or in certain cases of activation of the windscreen wipers. As soon as the brightness returns to a sufficient level or after the windscreen wipers are switched off, the lamps are switched off automatically.
Automatic illumination of headlamps
Activation
Turn the ring to the "AUTO" position, automatic illumination of headlamps is activated and a message is displayed in the screen.
Deactivation
 Turn the ring to another position. Deactivation is accompanied by a message in the screen.
Association with the automatic "Guide-me-home" lighting
Association with the automatic lighting provides the "guide-me-home" lighting with the following additional options after the ignition is switched off: - selection of the lighting duration of 15, 30 or 60 seconds in the vehicle parameters in the vehicle configuration menu, - automatic activation of "guide-me-home" lighting when automatic illumination of headlamps is in operation.
Operating fault
In the event of a malfunction of the sunshine sensor, the lighting comes on, this warning lamp is displayed in the instrument panel and/or a message appears in the screen, accompanied by an audible signal. Contact a CITROËN dealer or a qualified workshop.
In fog or snow, the sunshine sensor may detect sufficient light. In this case, the lighting will not come on automatically. Do not cover the sunshine sensor, coupled with the rain sensor and located in the centre of the windscreen behind the rear view mirror; the associated functions would no longer be controlled.
