2014.5 Citroen NEMO RHD Owner's Manual

167
CHANGING A FUSE
The two fuseboxes are placed on the
dashboard on the driver's side and under the
bonnet.
Removing and fitting a fuse
Before changing a fuse, the cause of the
fault must be found and rectified. The fuse
numbers are indicated on the fusebox.
a
lways use the special tweezer to extract
the fuse from its housing and check the
condition of its filament.
Always replace a faulty fuse with a fuse
of the same rating.
If a fuse fails again soon after replacement,
have the electrical system of your vehicle
checked by a CITROËN dealer or a qualified
workshop. Access to fuses in the dashboard
-

T
o gain access to the dashboard fuses,
remove the 2 screws using the ignition
key and tilt the housing.
CITR
o
Ë
n
will not accept responsibility
for the cost incurred in repairing your
vehicle or for rectifying the malfunctions
resulting from the installation of accessories
not supplied and not recommended by
CITR
o
Ë
n
dealers and not installed in
accordance with its instructions, in particular
when the combined consumption of all of the
additional equipment connected exceeds
10 milliamperes. A.
Good.
B.

Failed.
C.

T
weezer.
Access to fuses in the engine compartment
-
For access to the fuses in the engine

compartment, remove the left hand front
headlamp connector, then unclip the
fusebox cover.
9
QUICK HELP
Changing a fuse

168
Table of dashboard fuses, driver's sideMarking RatingFunctions
F12 7.5
a
Right-hand dipped beam headlamp supply
F13 7.5

a
Left-hand dipped beam headlamp supply - headlamp height

adjuster
F31 5
a
Engine control unit supply switch
F32 7.5

a
Front lamp - front courtesy lamp - rear courtesy light lamp
F36 10

AAudio system - mobile telephone pre-equipment - air
conditioning control panel - EODB diagnostic socket
F37 5
a
Brake lamp - instrument panel
F38 20

a
Door locking
F43 15

AScreenwash pump
F47 20
ad
river's electric window motor supply
F48 20
a
Passenger's electric window motor supply
F49 5

a
Parking sensors control unit - rear lighting switch - electric

door mirrors - volumetric alarm control unit
F50 7.5
a
Airbags control unit
F51 7.5

a
Switch on brake pedal - switch on clutch pedal - door mirror

controls - central Bluetooth system
F53 5
a
Instrument panel - rear foglamps
Changing a fuse

169Marking RatingFunctions
F41 7.5
a
Door mirror demisting.
F94 15

A Cigar lighter.
F96 15 A 12 V accessory socket.
F97 10 AHeated seat, driver's side.
F98 10 A heated seat, passenger's side.
9
QUICK HELP
Changing a fuse

170Marking RatingFunctions
F01 60
a
Control unit
F02 40

A Passenger compartment fan.
F03 20
a
Starter motor supply
F04 40

A ABS hydraulic block pump supply
F06 30 A Single speed cooling fan control
F07 40 A High speed cooling fan control
F08 30 A Air conditioning compressor
F09 15 ATowbar harness.
F10 10 AHorn
F 11 10 A Engine management secondary load supply
F14 15 AMain beam headlamps
F15 15 A 12 V accessory socket.Table of fuses in the engine
compartment
Changing a fuse

171Marking RatingFunctions
F16 7.5
a
Engine management control unit - electronic gearbox control uni
t and gear lever -
T20 relay coil
F17 15 A Supply for ignition coil - injectors - engine management control unit (1.3 HDi)
F18 7.5
a
Engine management control unit (1.3 HDi) -
T09 relay coil
F19 7.5
a
Air conditioning compressor
F20 30

ASupply for heated rear screen, electric door mirrors heater elements
F21 15 A Fuel pump (1.4 petrol and 1.3 HDi)
F22 20
a
Engine management control unit (1.3 HDi)
F23 20

a
ABS hydraulic block electrovalves supply
F24 7.5

aab
S
F30 15 A Foglamps
F81 60
a
Pre-heat unit (1.3 HDi)
F82 30

A Electronic gearbox pump - electronic gearbox supply
F84 10 A Electronic gearbox control unit and electrovalves
F85 30 A Cigar lighter - 12 V accessory socket
F87 7.5
a
Reversing lamps - water in Diesel sensor - airflow sensor -
T02, T05, T14, T17 and T19 relay coils
(except 1.3 HDi)
5
a
Reversing lamps - water in Diesel sensor - airflow sensor -
T02, To5, T14, T17 and T19 relay coils -
battery state of charge sensor (except 1.3 HDi)
9
QUICK HELP
Changing a fuse

172 172
TOWING
The removable towing eye is located in the
tool kit behind the driver's seat (Light van) or
behind the rear bench seat (Combi).
Towing the vehicle
In the front bumper, unclip the cover on the
right using a flat tool.
Screw the removable towing eye in fully.
Then hook the towing arm on the towing
eye.
Unlock the steering by turning the the
ignition key one notch and release the
parking brake.
Switch on the hazard warning lamps on both
vehicles.
Move off gently and drive slowly, towing for
a short distance only.On the towed vehicle, the gear
lever must be put in neutral; failure
to observe this special condition
may result in damage to certain braking
components (brakes, transmission...) and
the absence of braking assistance when the
engine is started.
Towing another vehicle
In the rear bumper, unclip the cover at the
bottom using a flat tool.
Screw the removable towing eye in fully.
Then hook the towing arm on the towing
eye.
Switch on the hazard warning lamps on both
vehicles.
Move off gently and drive slowly, towing for
a short distance only.
General recommendations
Observe the legislation in force in your
country.
Ensure that the weight of the towing vehicle
is higher than that of the towed vehicle.
The driver must remain at the wheel of the
towed vehicle and must have a valid driving
licence.
When towing a vehicle with all four wheels
on the ground, always use an approved
towing arm; rope and straps are prohibited.
The towing vehicle must move off gently.
When towing a vehicle with the engine off,
there is no longer any power assistance for
braking or steering.
In the following cases, you must always call
on a professional recovery service:
-

vehicle broken down on a motorway or

fast road,
-

four-wheel drive vehicle,
-


when it is not possible to put the gearbox

into neutral, unlock the steering, or
release the parking brake,
-

towing with only two wheels on the

ground,
-

where there is no approved towing arm

available...
Being towed or towing

173
9
QUICK HELP

174
