2013 VOLKSWAGEN JETTA Owners Manual

Buttons,
knobs More information: Manual AC ⇒fig. 123
<
Defroster: Airflow is directed to the windshield. Recirculation mode switches off
automatically in this position. Increases the fan speed to clear the windshield as
quickly as possible. The cooling system switches on automatically to dehumidify the
air.
K Air distribution to the air vents in the instrument panel.
L Air distribution to the footwells.
u Air distribution to the windshield and footwells.
= Rear window defroster: Works only when the engine is running and switches off
automatically after 10 minutes or less.
3 Air recirculation mode .
A, [ Buttons for seat heating
!

Heating and ventilation system

Fig. 124 In the center console: Heating system controls.

Settings for optimum visibility
When you switch on the cooling system, both the temperature and humidity in the vehicle are reduced.
This will help make passengers feel more comfortable and help keep the windows from fogging up.
x Switch off the air recirculation .
x Set the fan to the desired speed.
x Turn the temperature knob to the center position.
x Open and adjust all air vents in the instrument panel .
x Turn the air distribution knob to the desired setting.
x Push the !

Air vents

Fig. 125 In the instrument panel: Air vents.

The air recirculation mode helps prevent outside air from entering the vehicle interior
In very hot outside temperatures, temporarily switch to air recirculation in order to cool the vehicle
interior faster.
For safety reasons, air recirculation is switched off when the air distribution switch is turned to <\
⇒.
Switching air recirculation on and off - Manual AC
Switching on: Press the button 3 until the indicator light in the button comes on.
Switching off: Press the button 3 until the indicator light in the button goes out.
Switching air recirculation on and off - Heating and ventilation system
Switching on: Press the button  until the indicator light in the button comes on.
Switching off: Press the button until the indicator light in the button goes out.
WARNING
Stale air causes driver fatigue and reduces driver alertness, which can cause accidents,
collisions and serious personal injury.
x Never use air recirculation mode over an extended period of time, since no fresh air will
enter the passenger compartment.
x When the air conditioner is off and recirculation mode is on, condensation can quickly
form on the windows and greatly reduce visibility.
x Always switch off recirculation mode when it is not needed.

NOTICE
Do not smoke when air recirculation is switched on. Smoke drawn into the ventilation system
can leave residue on the evaporator and on the dust and pollen active carbon filter, resulting in
permanent odors whenever the air conditioner is switched on.

Refueling

WARNING
Even if empty, portable fuel containers can leak and cause a fire and serious personal
injuries, especially in a crash.
x For your safety, we strongly recommend that you do not travel with a portable fuel
container in your vehicle.
x If, under exceptional circumstances, you must transport a portable fuel container, please
observe the following:
– Never fill a portable fuel container while it is anywhere in or on the vehicle (for
example, in the luggage compartment or on top of the luggage compartment lid). Static
electricity can build up while filling and can ignite fuel vapors, causing a fire.
– Always place a portable fuel container on the ground before filling. Never spill fuel
inside the vehicle or luggage compartment. Fuel vapors are highly flammable.
– Always keep the filler nozzle completely inside the portable container before and
during filling.
– If filling a portable container made of metal, the filler nozzle must always be in contact
with the container. This will help prevent static electricity from discharging and causing a
fire.
– Always observe local and state or provincial laws about the use, storage, and
transportation of portable fuel containers.
– Make certain that the portable fuel container meets industry standards, such as
ANSI/ASTM F852-86.

NOTICE
x Remove fuel spills from the vehicle immediately to help prevent damage to the paint, tires,
and wheel housings.
x Refueling with gasoline when your vehicle has a diesel engine or refueling with diesel fuel
when your vehicle has a gasoline engine can cause very serious and expensive engine and
fuel system damage that is not covered by any Volkswagen Limited Warranty.
x If you put any amount of incorrect fuel in the fuel tank, do not start the engine under any
circumstances. Immediately contact the nearest authorized Volkswagen dealer or authorized
Volkswagen Service Facility for assistance. These fuels contain substances that can severely
damage the fuel system and the engine if the engine is started.
x Vehicles with diesel engines must never be refueled or driven with gasoline, kerosene,
heating oil, or other non-specified fuels that have not been expressly approved for use with the
diesel engine. Other kinds of fuel can cause serious damage to the fuel system and the engine
that is not covered by any Volkswagen Limited Warranty.
Fuels can pollute the environment. Spilled fuel must be collected and disposed of properly,
following all applicable environmental regulations.
There is no emergency release for the fuel filler flap. Contact an authorized Volkswagen dealer or
an authorized Volkswagen Service Facility for assistance.

Indicator lights and fuel gauge

Fig. 126 In the instrument cluster display: Fuel gauge.
