2013 VOLKSWAGEN JETTA Owners Manual

Elastic straps can snap back toward you if they are not properly attached ⇒.
If you use elastic straps to secure items in the luggage compartment, be sure to fist securely attach
them to the tie-downs just behind the rear seat backrest first and then to the tie-downs at the loading
edge of the luggage compartment.
Remove the hooks from the tie-downs in the reverse order described above, first from the tie-downs at
the loading edge and then from the tie-downs behind the rear seat backrest so that if the hooks come
loose suddenly, they will move away from you.
WARNING
Unsuitable, worn, or damaged tie-down straps (elastic or non-elastic) can snap or come
loose during braking or other maneuvers or in a collision. Objects secured with these straps
can then come loose and fly through the passenger compartment, causing severe personal
injuries or death.
x To help prevent baggage or other items from coming loose and flying around, always use
suitable undamaged tie-down straps.
x Securely fasten the tie-down straps to the tie-downs.
x Loose or improperly secured objects in the luggage compartment can slide about
suddenly and change the vehicle's handling.
x Secure even small and light objects. Loose objects in the luggage or passenger
compartment can fly about during sudden braking maneuvers or in the event of an accident
and injure occupants.
x Never exceed the maximum allowable load on the tie-downs when securing objects.
x Never secure a child seat to the tie-downs.

WARNING
Elastic straps have to be stretched when being attached to the tie-downs in the luggage
compartment. Hooks on these straps can cause serious personal injury if not handled
properly and attached securely.
x Always protect eyes and face from injury from the hooks when attaching them to the tie-
downs in the luggage compartment.
x Always hold the hooks on elastic straps firmly when attaching to the vehicle and do not
let them snap back and hit you.
x First attach the hooks on the straps to the tie-downs at the rear seat backrest in the
luggage compartment and then to the tie-downs near the loading edge of the luggage
compartment. This way, if one of the hooks on the elastic straps snaps back, it will move
away from you, decreasing the risk of personal injury.
The maximum load for the tie-downs is about 785 lbs. (356 kg).
For suitable straps and luggage stowage systems, please see an authorized Volkswagen dealer
or authorized Volkswagen Service Facility.

Roof rack

x Always make sure that the roof rack system and anything being carried on it does not
interfere with the roof antenna, the power sunroof or the luggage compartment lid.
x Make sure that the luggage compartment lid does not touch items on the roof rack when
opened.
If a roof rack is installed, fuel consumption increases due to increased air resistance.
Securing a load on the roof rack

WARNING
Loose or improperly secured items can fall off the roof rack and cause accidents and
injuries.
x Always use suitable, undamaged tie-down ropes and ratchet straps.
x Secure the load properly.

Trailer towing

WARNING
Improper use of the trailer hitch can cause accidents and injuries. An improperly installed,
incorrect, or damaged trailer hitch can cause the trailer to separate from the towing vehicle
and cause serious personal injuries.
x Only use an undamaged, properly mounted trailer hitch.
x Never repair or modify the trailer hitch.
x To reduce the risk of injury in rear-end collisions, and the risk to pedestrians and cyclists
when the vehicle is parked, always remove the ball mount when you are not towing a trailer.
x Never install a “weight distributing” or “load equalizing” trailer hitch on your vehicle. The
vehicle was not designed for these kinds of trailer hitches. The trailer hitch attachment can
fail, causing the trailer to tear loose from the vehicle.

WARNING
Improper trailer towing can cause loss of vehicle control and serious personal injury.
x Driving with a trailer and carrying heavy or large things can change the way the vehicle
handles, increase the distance it needs to stop safely, and cause accidents.
x Always secure the load properly with suitable and undamaged straps so that the load will
not shift.
x Always adapt your speed and driving to the heavier load and the weight distribution in the
vehicle. Take road, weather, traffic, and visibility conditions into account as well.
x Reduce your speed even more than you otherwise would when going downhill and under
unfavorable load, weather, or wind conditions.
x Trailers with a high center of gravity tip more easily than trailers with a low center of
gravity.
x Always avoid sudden maneuvers and hard braking.
x Be especially careful when passing other vehicles.
x Reduce speed immediately if the trailer shows the slightest sign of swaying.
x Never try to stop the swaying by accelerating.
x Always obey speed limits. In some areas, the speed limits for vehicles towing trailers are
lower than for vehicles without trailers. Never drive faster than 50 mph (80 km/h; under
exceptional circumstances 60 mph - 100 km/h) when towing a trailer. This applies even if the
local speed limit is higher.
If you are driving a new vehicle or a vehicle with a new or rebuilt engine, do not tow a trailer
during the break-in period, about 600 miles (1000 km) .
If you tow a trailer, your vehicle may need maintenance more often because of the extra load it
has to move.
When you are not towing, remove the trailer hitch ball. This helps keep the trailer hitch from
causing damage to your vehicle and to others if your vehicle is hit from behind.

Some models need a trailer hitch to tow or tow-start other vehicles. You may want to always
carry the ball mount in the vehicle after it has been removed. Be sure to stow it securely.
Technical requirements
