2013 VOLKSWAGEN JETTA Owners Manual

Applicable only in the United States
Front passenger side overview

Fig. 8 Overview of the front passenger side.
Key to fig. 8:
(1) Inside the glove compartment: SET button for Tire Pressure Monitoring System

Applicable only in Canada
Front passenger side overview

Fig. 9 Overview of the front passenger side.
Key to ⇒fig. 9:
(1) Opening handle for the glove compartment
(2) Passenger front airbag location in the instrument panel (approximate)
(3) Air vent  –

Applicable only in the United States
Symbols on the roof console

Symbol Meaning
*  / s  Interior and reading lights .
g c h Power sunroof .
a
/ Three-button module ⇒Booklet Mobile Phone Package.

Applicable only in Canada
Symbols on the roof console

Symbol Meaning
*  / s  Interior and reading lights .
g c hª ¯ Power sunroof

Instrument cluster

– To advance the clock, push the E

– To advance the clock, push the E

For information on maintenance intervals, please see the ⇒Booklet Warranty and Maintenance.
For vehicles with time- or distance driven-dependent service, only fixed service intervals are dis-
played.
Service reminder
If service is due in the near future, a service reminder is displayed when the ignition is switched on.
On vehicles without text messages, a wrench symbol > and a miles (kilometers) indicator are
shown in the instrument cluster display. The distance shown in miles (kilometers) is the maximum
distance the vehicle can be driven without having a service completed. The display changes after a
few seconds. A clock symbol is displayed and the number of days until the required service is shown.
Service event
When service is due, a warning chime sounds when the ignition is switched on, and a flashing
wrench symbol > is displayed for several seconds.
Viewing service message
The current service message can be accessed when the ignition is switched on, the engine is
switched off, and the vehicle is stopped:
x Push the

Volkswagen Information System
