2013 VOLKSWAGEN JETTA HYBRID Owners Manual

Lights
up Possible cause Proper response
Vehicle battery was disconnected and
has been reconnected.
Drive a short distance at about 10–12 mph
(15–20 km/h).


Flashes Possible cause Proper response
D Electronic steering column lock
malfunction.

If the driver door is opened before the ignition is switched off, the electronic steering column lock is
activated only after the vehicle has been locked with the vehicle key or via the sensor in the door
handle.
Mechanical steering column lock
Vehicles without Keyless Access: The steering column is locked if the vehicle is stationary and the
vehicle key is removed from the ignition switch.

Engaging the steering column
lock
Disengaging the steering column
lock
Parking the vehicle . Turn the steering wheel slightly to
take pressure off the steering
column lock.
Remove the vehicle key. Insert the vehicle key into the
ignition switch.
Turn the steering wheel slightly until
you hear the steering column lock
engage.
Hold the steering wheel in this
position and turn the ignition switch.

Power steering
Power steering automatically adjusts to driving speed, steering torque, and the steering angle of the
wheels. Power steering works only when the engine is running.
If power steering is reduced or lost completely, it will be much harder to steer and control the vehicle.
Counter-steering assistance
Counter-steering assistance is part of Electronic Stability Control (ESC). This feature makes it easier
for the driver to control the vehicle in difficult situations. For example, if you have to brake hard on a
surface that provides uneven traction, the vehicle could pull to the right or left. ESC detects this
situation and helps the driver counter-steer with additional steering power ⇒ .
WARNING
The counter-steering assistance in ESC can do no more than help the driver steer in difficult
situations. The driver must still control the vehicle. The vehicle does not steer by itself with
this feature!
NOTICE
If the ignition is off, the steering column lock will engage and the vehicle cannot be steered.
For this reason, you must leave the ignition on when going through an automatic car wash, for
example, so that the wheels will still steer.

Hybrid drive

DANGER
The vehicle's high-voltage electrical system and high-voltage battery are dangerous and can
cause burns, other serious personal injuries, electrocution, and death.
x Always assume that high-voltage battery and parts of the high-voltage system are fully
charged and energized.
x Never touch or let jewelry or other metal objects contact high-voltage cables or the high-
voltage battery and battery poles, especially if the cables, battery, and battery poles have
been damaged in any way.
x Never do any work yourself on the high-voltage electrical system, the orange-colored
high-voltage wiring, or on the high-voltage battery.
x Never open, service, repair, or disconnect any part of the hybrid electrical system.
x Never damage the orange-colored high-voltage cables. Never remove them and never
disconnect them from the high-voltage electrical system.
x Never open or remove the orange-colored cover on the high-voltage battery.
x Always have work on the hybrid electrical system and systems that could be indirectly
affected by it done by qualified, trained technicians who have the know-how, experience,
documentation, and tools to do the work safely.
x All work on the high-voltage electrical system and the high-voltage battery must be done
in compliance with Volkswagen standards and guidelines.
x Vehicle keys must be safely stored a safe distance from vehicle so that the ignition cannot
be switched on and energize the electrical system.
x Gases vented or released from the high-voltage battery vapors are potentially poisonous
and can burn.
x Physical damage to the vehicle or the high-voltage battery can result in immediate or
delayed release of poisonous gases that can also cause a fire.
x Always avoid contact with leaking fluids and gases escaping from the battery, particularly
one that has been damaged.
x Always tell emergency responders that the vehicle has a high-voltage battery.
WARNING
Driver distraction causes accidents and serious personal injury. Using the instrument cluster
or accessing Infotainment System menus while driving can take your attention off the road
and cause accidents.
x To help reduce the risk of accidents and injuries, never change settings in the instrument
cluster display or use Infotainment System functions unless the vehicle is standing still.

WARNING
When powered by the electric motor, the vehicle makes much less noise, both when idling
and driving, than when it is running on the internal combustion engine. It is much harder or
even impossible for the drivers of other vehicles and above all for cyclists, pedestrians, and
children to hear the vehicle when it is running on electrical power.
x Pedestrians and others can be struck and seriously injured because they cannot hear the
vehicle and tell that it is getting close to them, for instance when you are parking, backing up,
or driving in a low-speed zone where there is likely to be pedestrian traffic.
x Always watch out for pedestrians, especially small children, cyclists, and others who may
not hear the vehicle or realize that it is about to move or will cross their path of travel.
x Always be especially careful in residential areas, school zones, and other places where
the speed of motor vehicles is restricted and pedestrians may be at greater risk.
x Make sure the ignition and the hybrid drive system have both been turned off before
leaving the vehicle.
WARNING
Never leave the vehicle when hybrid drive system indicator lights are still lit. The vehicle can
move if the accelerator is depressed even though the combustion engine has been stopped.
This can cause accidents and severe or fatal injuries.
x Make sure the transmission is in Park (P) before you get out of the vehicle.
WARNING
Never support the vehicle with cinder blocks, bricks, or other objects to inspect it. The
vehicle could slip or move suddenly and cause an accident with serious personal injury.
WARNING
Never let the hybrid battery get wet. Liquids and other fluids can cause short circuits,
electrical shock, burns, and explosions.
x Never carry large amounts of liquids or other fluids in the luggage compartment.
x Always make sure that any containers with liquids and other fluids are properly secured
and tightly closed to prevent leakage during normal driving as well as hard cornering,
braking, and other vehicle maneuvers. Leaking liquids can get into the cover of the high-
voltage battery and the high-voltage cable connections. This can damage the electrical
system and the high-voltage battery.
Never drive until the fuel tank is completely empty. There may not always be enough charge in
the high-voltage battery to get to the next gas station.
Warning and display messages

Warning messages
When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
Warning lights and text messages are shown in the instrument cluster display. Acoustic warnings may
also sound at the same time.

Lights up Warnings in the instrument cluster
display ⇒  Proper response
∋ Error: Hybrid system
Park vehicle!
Stop the vehicle in a safe place as soon as
it is safe to do so.
*∋ Error: Hybrid system
Contact dealer now!
See an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.
*∋ Hybrid system:
Vehicle still ready to drive.
–
Hybrid system currently
not available.
Never leave the vehicle parked in the ready
position. Remove the remote control vehicle
key out of the ignition or, for vehicles with
Keyless Access, press the starter button.
Restart engine! Start the engine with the ignition switch or
starter button.
Hybrid battery charging
...Leave engine running!
While this message appears, do not stop
the engine.

Warning when leaving the vehicle
Switch off the ignition before leaving the vehicle unattended . In certain situations, a message
Ignition on appears in the instrument cluster display as you are leaving the vehicle. This message
warns you that the vehicle's electric drive is still enabled and that the combustion engine might start
automatically.
Always switch the ignition off, remove the key, and take it with you when leaving the vehicle ⇒ . As
a reminder to do so, the combustion engine may start automatically under the following conditions:
x The ignition is switched ON.
x AND: Electrical drive is functional (Ready).
x AND: The transmission is in Park (P) or Neutral (N).
x AND: The driver safety belt is not fastened OR The driver door is open.
The message in the instrument cluster display also reminds you to switch the ignition off. In addition,
always be sure to apply the parking brake, remove the key, and take it with you when leaving the
vehicle.
WARNING
A parked vehicle that is not properly parked can roll away and cause accidents or severe
injuries. When leaving the vehicle, always move the selector lever into Park (P) and engage
the parking brake.

WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to
break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Special driving tips

Driving situations Requirements and
conditions Vehicle behavior
Driving in city traffic. – Select a moderate speed. Driving in fully electric mode at this level is
possible with a constant speed of up to
about 37 mph (60 km/h) on a flat road
surface .
– Avoid full acceleration. The fuel consumption is reduced with
moderate acceleration due to higher
efficiency of the combustion engine and
driving in fully electric mode is possible.
– Careful use of the %
