2013 TOYOTA LAND CRUISER wiper fluid

206 2-3. Operating the lights and wipers
LC200_OM_OM60F57U_(U)
■The windshield wiper and washer can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
■Effects of vehicle speed on wiper operation (vehicles with rain-sensing
windshield wipers)
Vehicle speed affects the wiper operation when the washer is being used
(delay until drip prevention wiper sweep occurs) even when the wipers are
not in “AUTO” mode.
With “ ” selected, wiper operation will be switched from low speed to
intermittent wiper operation only when the vehicle is stationary.
(However, when the sensor sensitivity is adjusted to the highest level, the
mode cannot be switched.)
■Rain drop sensor (vehicles with rain-sensing windshield wipers)
●If the wiper switch is turned to “AUTO” position while the “ENGINE
START STOP” switch is in IGNITION ON mode, the wiper will operate
once to show that “AUTO” mode is activated.
●If the temperature of the rain drop sensor is 176F (80C) or higher, or
14F (-10C) or lower, automatic operation may not occur. In this case,
operate the wipers in any mode other than “AUTO”.
■If no windshield washer fluid sprays
Check that the washer nozzles are not blocked if there is washer fluid in the
windshield washer fluid reservoir.
●The sensor judges the amount of rain-
drops.

207 2-3. Operating the lights and wipers
2
When driving
LC200_OM_OM60F57U_(U)
CAUTION
■Caution regarding the use of windshield wipers in “AUTO” mode (vehi-
cles with rain-sensing windshield wipers)
The windshield wipers may operate unexpectedly if the sensor is touched or
the windshield is subject to vibration in “AUTO” mode. Take care that your
fingers or anything else do not become caught in the windshield wipers.
■Caution regarding the use of washer fluid
When it is cold, do not use the washer fluid until the windshield becomes
warm. The fluid may freeze on the windshield and cause low visibility. This
may lead to an accident, resulting in death or serious injury.
NOTICE
■When the windshield is dry
Do not use the wipers, as they may damage the windshield.
■When there is no washer fluid spray from the nozzle
Damage to the washer fluid pump may be caused if the lever is pulled
toward you and held continually.
■When a nozzle becomes blocked
Do not try to clear it with a pin or other object. The nozzle will be damaged.

209
2-3. Operating the lights and wipers
2
When driving
LC200_OM_OM60F57U_(U)
Headlight cleaner switch
: If equipped
■The headlight cleaner can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode and the head-
light switch is turned on.
NOTICE
■When the washer fluid tank is empty
Do not use this function when the washer fluid tank is empty. This may
cause the washer fluid pump to overheat.
Washer fluid can be sprayed on the headlights.
Press the switch to clean the
headlights.
ITY23C039

714 Alphabetical index
LC200_OM_OM60F57U_(U)
Parking brake ...........................177
Parking lights
Switch.................................... 196
PCS............................................ 290
Personal lights
Personal lights....................... 464
Switch.................................... 464
Wattage .................................675
Power outlet ............................. 485
Power steering
Fluid ......................................538
Power windows ..........................93
Pre-Collision System ............... 290
Radiator .................................... 535
Radio ......................................... 356
RDS ...........................................360
Rear seats
Adjustment .............................. 59
Tumbling second seats ...........60
Tumbling third seats ................63
Rear turn signal lights
Replacing light bulbs ............. 581
Wattage .................................675
Rear view monitor system
*
Rear window defogger ............351
Rear window wiper .................. 208
Replacing
Fuses .................................... 566
Key battery ............................ 563
Light bulbs ............................. 581
Tires ......................................633
Reporting safety defects for
U.S.A. owners ........................704
Roll sensing of curtain shield
airbags off switch .................. 128
Roof luggage carrier ................302Safety Connect......................... 504
Seat belts
Adjusting the seat belt............. 79
Automatic Locking
Retractor ............................... 80
Child restraint system
installation........................... 140
Cleaning and maintaining
the seat belts ...................... 516
Emergency Locking
Retractor ............................... 80
How to wear your seat belt ..... 76
How your child should wear
the seat belt .......................... 81
Pregnant women,
proper seat belt use .............. 82
Reminder light ....................... 609
Seat belt extenders ................. 81
Seat belt pretensioners ........... 79
Seat heaters ............................. 489
Seats
Adjustment precautions .......... 58
Child seats/child restraint
system installation .............. 140
Cleaning ................................ 515
Driver’s seat position
memory................................. 68
Front seat adjustment ............. 57
Head restraint ......................... 72
Properly sitting in the seat..... 111
Rear seat adjustment .............. 59
Seat heaters.......................... 489
Service reminder
indicators .............................. 184
Shift lever
Automatic transmission ......... 171
If the shift lever cannot be
shifted from “P” ................... 649
P
R
S

715 Alphabetical index
LC200_OM_OM60F57U_(U)
Side airbags ............................. 113
Side marker lights
Replacing light bulbs ............ 581
Switch ................................... 196
Wattage ................................ 675
Side mirror
Adjusting and folding .............. 90
Mirror position memory........... 68
Smart key system
Entry function ......................... 32
Starting the engine ............... 166
“SOS” button ........................... 504
Spare tire
Inflation pressure .................. 553
Storage location ................... 633
Spark plug................................ 671
Specifications .......................... 666
Speedometer ........................... 179
Steering
Column lock release ............. 168
Fluid...................................... 538
Steering wheel
Adjustment ............................. 86
Audio switches ..................... 398
Heated steering wheel.......... 487
Steering wheel position
memory ................................ 68
Stop lights ............................... 594
Storage feature ........................ 466
Storage precautions ............... 302
Stuck
If your vehicle becomes
stuck................................... 661
Sun visors ................................ 477
Sunshade
Roof ........................................ 98Switch
DISP switch ...........................190
ECT switch ............................172
Driving mode select switch....172
Emergency flasher switch .....598
Engine switch ........................166
Fog light switch .....................201
Hazard light switch ................598
Heated steering wheel
switch ..................................487
Ignition switch........................166
Light switches........................196
Power door lock switch ...........46
Power window switch ..............93
Rear window wiper and
washer switch .....................208
VIEW switch ..........................257
Window lock switch .................93
Wipers and washer
switch ..........................202, 208
Tachometer
Tachometer ...........................179
Tail lights
Switch....................................196
Talk switch
*.............................429
Telephone switch
*...................429
Theft deterrent system
Alarm .....................................107
Engine immobilizer system ...105
Tire inflation pressure .............553
Tie-down hooks........................495
Tire information
Glossary ................................685
Size .......................................682
Tire identification number ......681
Uniform tire quality grading ...683
T
*: For vehicles with a navigation system,
refer to the “Navigation System Owner’s Manual”.*: For vehicles with a navigation system,
refer to the “Navigation System Owner’s Manual”.
