2013 TOYOTA COROLLA Owners Manual

529
What to do if...
What to do if...
A tire puncturesP. 436If you have a flat tire
The engine does not start
P. 8 1Engine immobilizer system
P. 448If the engine will not start
P. 452If the electronic key does not oper-
ate properly
P. 455If the battery is discharged
The shift lever cannot be
moved outP. 450If the shift lever cannot be shifted
from P
The engine coolant temperature
gauge enters the red zone
Steam can be seen coming
from under the hood
P. 461If your vehicle overheats
The key is lostP. 451If you lose your keys
The battery runs outP. 455If the battery is discharged
The doors cannot be lockedP. 4 1Doors
The vehicle is stuck in
mud or sandP. 464If the vehicle becomes stuck
A warning light or indicator light
comes onP. 424If a warning light turns on or a
warning buzzer sounds...

530 What to do if...
Type A
Type B

531
What to do if...
■
Warning lights
P. 426
or
P. 4 2 4P. 426
P. 4 2 4P. 425
P. 4 2 4P. 425
P. 425
or
P. 4 2 5P. 426
P. 4 2 5P. 426
P. 426
or
P. 4 2 5P. 426
P. 4 2 6P. 434
*: The light flashes to indicate a malfunction.
Brake system warning
lightTire pressure warning
light
Low windshield washer fluid level
warning light
Charging system warn-
ing lightElectric power steering
warning light
Low engine oil pressure
warning lightSlip indicator
light
Malfunction indicator
lampCruise control indicator
light
*
Open door warning light
SRS warning lightLow fuel level warning
light
ABS warning lightDriver’s seat belt
reminder light
Front passenger’s seat belt
reminder light
Maintenance required
reminder lightSmart key system warn-
ing light

532
GAS STATION INFORMATION
Hood lock release lever
P. 3 5 1
Fuel filler door openerP. 7 7Tire inflation pressure
P. 480
Auxiliary catch leverP. 351Trunk openerP. 4 7Fuel filler door P. 7 7
Fuel tank capacity
(Reference) 13.2 gal. (50 L, 10.9 Imp. gal.)
Fuel type
Unleaded gasoline only P. 78, 474
Cold tire inflation pressure P. 480
Engine oil
capacity
(Drain and
refill

reference)
1.8 L 4-cylinder
(2ZR-FE)
engine With filter
Without filter qt. (L, Imp. qt.)
4.4 (4.2, 3.7)
4.1 (3.9, 3.4)
2.4 L 4-cylinder
(2AZ-FE)
engine
With filter
Without filter qt. (L, Imp. qt.)
4.0 (3.8, 3.3)
3.8 (3.6, 3.2)
Engine oil type
“Toyota Genuine Motor Oil” or equivalent
Oil grade: ILSAC multigrade engine oil
Recommended viscosity: P. 474
