2013 TOYOTA COROLLA Owners Manual

297
3-4. Using the hand
s-free phone system (for cellular phone)
3
Interior features
Registering a portable player
Select “Pairing” using , and perform the procedure for regis-
tering a portable player. ( P. 285)
Listing the registered cellular phones
Select “List Phone” using . T he list of registered cellular
phones will be displayed.
● Connecting the registered cellular phone to the audio system
Select the name of the cellular phone to be connected
using .
Select “Select” using .
● Deleting a registered cellular phone
Select the name of the cellular phone to be deleted using
.
Select “Delete” using .
Press (YES).
STEP 1
STEP 2
STEP 1
STEP 2
STEP 3

298 3-4. Using the hands-free phone system (for cellular phone)
Listing the registered portable players
Select “List Audio” using . The list of registered portable play-
ers will be displayed.
● Connecting the registered portable player to the audio system
Select the name of the portab le player to be connected
using .
Select “Select” using .
● Deleting the registered portable player
Select the name of the portable player to be deleted using
.
Select “Delete” using .
Press (YES).
STEP 1
STEP 2
STEP 1
STEP 2
STEP 3

299
3-4. Using the hand
s-free phone system (for cellular phone)
3
Interior features
Changing the passkey
Select “Passkey” using .
Select a 4 to 8-digit passkey using .
Input the number 1 digit at a time.
When the entire number to be registered as a passkey has
been input, press again.
If the passkey to be registered has 8 digits, pressing again
is not necessary.
Setting automatic connection of the device on or offIf “BT Power” is set to on, the r egistered device will be connected
automatically when the engine switch is turned to the “ACC” position.
Select “BT Power” using .
Select “ON” or “OFF” using .
STEP 1
STEP 2
STEP 3
STEP 1
STEP 2

300 3-4. Using the hands-free phone system (for cellular phone)
Displaying the device status
Select “Bluetooth info” using .
● Displaying the device name
Select “Device Name” using .
● Displaying the device address
Select “Device Address” using .
Setting the automatic connection conf irmation display to on or off
If the “Display Setting” is set to on, the portable player connection sta-
tus will be displayed when the engine switch is turned to the “ACC” or
“ON” position.
Select “Display Setting” using .
Select “ON” or “OFF” using .
STEP 1
STEP 2

301
3-4. Using the hand
s-free phone system (for cellular phone)
3
Interior features
Initialization
Select “Initialize” using .
● Initializing the sound settings
Select “Sound setting” using and press (YES).
For details about sound settings ( P. 270)
●Initializing the device information
Select “Car Device Info” using and press (YES).
Automatic connection of a portable device, automatic connection confir-
mation display and the passkey will be initialized.
●Initializing a ll the settings
Select “All Initialize” using and press (YES).
■ The number of Bluetooth® devices that can be registered
Up to 5 Bluetooth
® devices can be registered in the system.

302
3-4. Using the hands-free phone system (for cellular phone)
Using the “SET UP” menu (“Phone” menu)
■Functions and operation procedures
To enter the menu of each function, press and follow
the steps below using :
●Adding a new phone number
1. “Phone”  2. “Phonebook”  3. “Add contacts”
● Setting speed dials
1. “Phone”  2. “Phonebook”  3. “Add SD”
● Deleting call histories
1. “Phone”  2. “Phonebook”  3. “Delete Call History”
● Deleting a registered phone number
1. “Phone”  2. “Phonebook”  3. “Delete contacts”
● Deleting another cellular phone’s phonebook
1. “Phone”  2. “Phonebook”  3. “Delete other PB”
● Setting call volume
1. “Phone”  2. “HF Sound Setting”  3. “Call Volume”
● Setting ringtone volume
1. “Phone”  2. “HF Sound Setting”  3. “Ringtone Volume”
● Setting ringtone
1. “Phone”  2. “HF Sound Setting”  3. “Ringtone”
● Transferring call histories
1. “Phone”  2. “Transfer Histories”

303
3-4. Using the hand
s-free phone system (for cellular phone)
3
Interior features
Adding a new phone number
Select “Add contacts” using .
● Transferring all contacts from the cellular phone
Select “Overwrite all contacts” using and press
(YES).
● Transferring one contact from the cellular phone
Select “Add one contact” using and press (YES).
Setting speed dials
Select “Add SD” using .
Select the desired data using .
Press and hold the desired preset button (from to).
For details about setting speed dials from the call history: P. 2 9 3
For details about deleting speed dials: P. 2 9 3
STEP 1
STEP 2
STEP 3

304 3-4. Using the hands-free phone system (for cellular phone)
Deleting call histories
Select “Delete Call History” using .
● Deleting outgoing call history
Select “Outgoing Calls” using .
Select the desired phone number using and press (YES).
To delete all outgoing call history data, press (ALL) and
then press (YES).
● Deleting incoming call history
Select “Incoming calls” using .
Select the desired phone number using and press (YES).
To delete all incoming call history data, press (ALL) and
then press (YES).
STEP 1
STEP 2
STEP 1
STEP 2
