2013 SUBARU IMPREZA WRX Owners Manual

Page 145 of 414

SUBARU IMPREZA WRX 2013 4.G Owners Manual 3-30Instruments and controls
&High/low beam change (dim- mer)
To change from low beam to high beam,
push the turn signal lever forward. When
the headlights are on high beam, the high
beam indicator l

Page 146 of 414

SUBARU IMPREZA WRX 2013 4.G Owners Manual Turn signal lever
To activate the right turn signal, push the
turn signal lever up. To activate the left
turn signal, push the turn signal lever
down. When the turn is finished, the lever
will return

Page 147 of 414

SUBARU IMPREZA WRX 2013 4.G Owners Manual 3-32Instruments and controls
Headlight beam leveler (if equipped)
The vehicle has High-Intensity Discharge
(HID) headlights on the low beam setting.
The HID headlights generate more light
than conven

Page 148 of 414

SUBARU IMPREZA WRX 2013 4.G Owners Manual Dial positionNumber of front seat
occupants Number of rear seat
occupants Load in the luggage
compartment area
0 1 or 2 0 No load
1 2 3 No load 22 3 Full load*
1 0 Full load*
3 Not applicable Not app

Page 149 of 414

SUBARU IMPREZA WRX 2013 4.G Owners Manual 3-34Instruments and controls
Front fog light switch (if equipped)
The front fog lights operate only when the
light switch is in the “”position.
However, the front fog lights turn off when
the he

Page 150 of 414

SUBARU IMPREZA WRX 2013 4.G Owners Manual .In freezing weather, be sure that
the wiper blades are not frozen to
the windshield or rear window
before switching on the wipers.
Attempting to operate the wiper
with the blades frozen to the
windo

Page 151 of 414

SUBARU IMPREZA WRX 2013 4.G Owners Manual 3-36Instruments and controls
& Windshield wiper and washer switches
The wiper operates only when the ignition
switch is in the “ON ”or “Acc ”position.
! Windshield wipers
OFF: Off: Intermitte

Page 152 of 414

SUBARU IMPREZA WRX 2013 4.G Owners Manual !Washer
To wash the windshield, push the washer
button at the end of the wiper control lever.
The washer fluid sprays until you release
the washer button. The wipers operate
while you push the button
