4. Connect the chassis plug and bracket (provided in theglove box) to the chassis wiring harness and insert the
bracket back into the sill.
5. Connect the tailgate plug (provided in the glove box) to the tailgate wiring harness to ensure that the
terminals do not corrode.
6. Tape the tailgate harness and bracket against the forward-facing surface of the tailgate. This will pre-
vent damaging the connector and bracket when stor-
ing or reinstalling the tailgate.Removing The Tailgate
1. Disconnect the wiring harness for the rear camera andor power locks (if equipped), refer to “Disconnecting
the Rear Camera — If Equipped” in this section.
2. Unlatch the tailgate and remove the support cables by releasing the lock tang from the pivot.
NOTE: Make sure tailgate is supported when removing
support cables.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 247

3. Raise the tailgate to a 45 degree angle.
4. Raise the right side of the tailgate until the right sidepivot clears the hanger bracket.
5. Slide the entire tailgate to the right to free the left side pivot. 6. Remove the tailgate from the vehicle.
NOTE:
Do not carry the tailgate loose in the truck
pickup box.
WARNING!
To avoid inhaling carbon monoxide, which is deadly,
the exhaust system on vehicles equipped with “Cap
or Slide-In Campers” should extend beyond the
overhanging camper compartment and be free of
leaks.
Locking Tailgate
The lock is located next to the tailgate handle. The
tailgate can be locked using the vehicle key or by locking
the truck with the key-fob if equipped with remote
keyless entry.
Locking Tang
248 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

TRI-FOLD TONNEAU COVER-IF EQUIPPED
Tri-Fold Tonneau Cover — If Equipped
Your vehicle may be equipped with a Tri-Fold Tonneau
Cover which consists of different features:
•Easy Tri-Fold cover
• Tonneau fore aft locator
• Crosscar inside bed locator
• Front and rear clamps
• Stowage strap
• Locking Capability
NOTE: The Tonneau Cover can be folded up and secured
at the front of the box without removing completely.
Tri-Fold Tonneau Cover Removal
To remove the Tonneau Cover follow the following steps:
1. Lower the tailgate.
2. Pull down on the clamp on both driver and passenger sides.
3. Pick up on the cover and fold it back into the second panel.
4. Be sure both clamps are pushed completely down.
5. Pick up on the cover and fold it back into the third panel.
6. Once in the third panel position pull down on the clamp on both sides.
7. Be sure to clip both straps together to insure the cover stays together.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 249

8. With two people remove the cover.
Clamped Position
NOTE:If clamp wire is damaged replace immediately.
Semi Clamped Position
250 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NOTE:Be sure the Tonneau Cover has been folded
completely before removing.
Released PositionStowage Strap
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 251

Tri-Fold Tonneau Cover Installation And Cleaning
Position the folded Tonneau Cover on the truck bed and
push the Cover forward against the front of the truck
bed. The Tonneau Cover centers itself when placed on the
vehicle. Disengage the stowage straps and unfold the
Tonneau Cover then attach the rear clamps to the truck
bed flange to secure the Tonneau Cover to the vehicle.
The Tonneau Cover clamps can be locked when in the
clamped position by placing a lock through the locking
hole.NOTE:Be sure the Tonneau Cover is secured before
driving after installation.
For proper cleaning of the Tonneau Cover use MOPAR®
Whitewall &Vinyl Top Cleaner and MOPAR® Leather &
Vinyl Conditioner/Protectant.
Locking Hole
252 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
