2013 PORSCHE PANAMERA Information Manual

Driving a sports car is fun. But do our
own principles have to fall by the
wayside? Those who are serious about
per formance potential don’t evade
questions of ef ficiency. They answer
them by showing the same will to
perform.
Pleasure and principle. Performance.
50

5
12
3
4
56
7
8
9
10
11
12
13
14
5253
Engines.
Increasing power output, reducing fuel
consumption. Brief fulfilled. With engines
characterised by sporty performance
and yet comparatively low energy
consumption and CO
2 emissions.

This has been achieved thanks to
technologies such as direct fuel injection
(DFI), VarioCam Plus or variable camshaft
control, turbocharging, recuperation,
the auto start/stop function, the coasting
function or the use of plug-in hybrid
technology. The engines are structurally
rigid and, thanks to aluminium cylinder
heads and magnesium valve covers (except the Panamera S E-Hybrid), they
are comparatively light weight. This helps
to ensure a decent weight-to -power

ratio and balanced weight distribution.

Let’s take the new engine generation of
the Panamera S and Panamera 4S as
an example. It may have been stripped
of t wo cylinders and its displacement
reduced by 1.8 litres compared with
that of its predecessor, but it has been
given a twin-turbocharger arrangement.
This is where the figures begin an
upward trend. Increased power output,
greater dynamics and enhanced
e f f ici e n cy.
Direct fuel injection (DFI).
With millisecond precision, DFI injects
fuel at up to 120 bar directly into the
combustion chamber by means of
electromagnetically actuated injection
valves. DFI also improves the internal
cooling of the combustion chamber by
having the mixture prepared directly in
the cylinder. The higher compression ratio
helps to deliver more output at the same
time as enhanced engine efficiency.
3.0-litre twin-turbo V6 engine
We can make things move in many ways.
With lightness, for example.

Drive.
Performance |
Drive
1. Throttle bodies/electronic throttle
2. Intake manifold
3. Intake camshaft
4. Exhaust camshaft
5. VarioCam Plus (valve adjuster)
6. VarioCam Plus (switching tappet)
7. V a l v e
8. Exhaust manifold
9. Turbocharger
10. Poly-V belts
11. PDCC/power steering pump
12. Air-conditioning compressor

13. Oil/water heat exchanger
14. Oil filter

5455
VarioCam Plus.
VarioCam Plus is a two-in-one engine
concept for adjusting the intake and
exhaust camshafts and switching the
lift of the intake valves. The system
differentiates between driver inputs that
typify normal, everyday driving and those
inputs that demand maximum power.
Valve operation is then adapted
automatically to prevailing conditions.
This results in instant acceleration and
extremely smooth running as well as
extraordinary acceleration power with
comparatively low fuel consumption.
Standard in the Panamera models with
petrol engine (except the Panamera S
E-Hybrid).

Variable camshaft control.
In the V6 combustion engine of the
new Panamera S E-Hybrid, fully variable
camshaft control is used to adjust the
intake camshaft timing. The result is
high specific output and high torque –
even at low engine speeds.

Auto/start stop function.
The auto start /stop function still works
in the familiar way. As soon as you come
to a halt and keep your foot on the brake
pedal, the system will automatically
stop the engine. This fuel-saving system
restarts the engine the moment you
release the brakes.

What’s new, however, is that the engine
now switches off as you approach traffic
lights. All audio and communication
systems remain switched on and the
climate control continues to maintain
your selected temperature, despite the
engine being switched off. The engine
restarts automatically if the energy
needs of the auxiliary equipment can
no longer be met by the energy saved
in the bat tery. In all models (except
the Panamera S E-Hybrid), the auto
start /stop function can be activated and
deactivated using a separate but ton.
Coasting.
The coasting function available with
Porsche Doppelkupplung (PDK) enables
you to save even more fuel where the
situation allows.* The engine is decoupled
from the transmission to prevent
deceleration caused by engine braking.
The Panamera S E-Hybrid goes one step
further and switches off the engine
completely. In this way, optimum use
is made of the vehicle’s momentum,
allowing it to coast for longer distances.
This achieves a noticeable reduction
in fuel consumption with no impact on
comfort or sporty performance.
VarioCam Plus
Performance |
Drive
* Not for Panamera GTS.

5657
Lightweight exhaust system.
The exhaust system of the Panamera
models is made from long-life stainless
steel. The primary and main catalytic
converters heat up rapidly and help

to deliver effective emissions control.
At high revs and under maximum
engine load, the exhaust system of
the Panamera Turbo opens flaps for
increased throughput and an even
more thunderous sound.
Sports exhaust system.
Available as an option for the Panamera S,
Panamera 4S and Panamera Turbo is a
sports exhaust system featuring unique -
design tailpipe trims. For an even more
authentic sports car sound – at the push
of a but ton.
The tailpipes of the Panamera GTS

sports exhaust system have a mat t
black painted finish as standard. At the
touch of a but ton or when SPORT or
SPORT PLUS mode is enabled, the
sports exhaust system provides that
characteristic motorsport sound –
another unmistakable expression of
the individualit y of the Panamera GTS.
Panamera Turbo tailpipes
Panamera and Panamera 4 tailpipes
Performance |
Drive
Panamera 4S with sports exhaust system

5859
Porsche Doppelkupplung (PDK).
Offering both a manual gearshift and an
automatic mode, 7-speed PDK promises
to deliver sports performance with
efficiency and comfort as well as
rapid gear changes with no discernible
interruption in the flow of power.
PDK is essentially t wo gearboxes in one.
The double clutch provides an alternating,

friction-locked connection between these
t wo half gearboxes and the engine. Gears
1 to 6 have a sports ratio and top speed
is reached in 6th gear. The 7th gear
has a long ratio, which helps to keep the
engine revs low, even at high speeds.
Depending on the gearshift programme (SPORT button activated or deactivated),
the gear change is optimised for comfort
or sporty driving.


For the Panamera GTS, we’ve made PDK
even sportier. The gearshift programmes
(Normal, SPORT or SPORT PLUS)
configure the gear changes to be sport y
to extremely sport y. During an upshift,
for example, selected engine cylinders
are deactivated temporarily, which
enables the speed of the engine to be
synchronised with the speed of the
transmission more quickly. This results
in even faster shift times accompanied
by a characteristic motorsport engine
sound.
After all, you also control your muscles with your head.

Transmission.
8-speed Tiptronic S.
8-speed Tiptronic S in the Panamera S
E-Hybrid reduces fuel consumption
and improves comfort. How? With a
particularly wide gear ratio spread. The
relatively low engine speeds in the upper
gears reduce noise levels in the interior,
especially on the motorway. The 8-speed
Tiptronic S shifts automatically and
adapts to your driving st yle. Of course,
you can still change gear manually at
the gear selector itself or using the t wo
ergonomic gearshift switches on the
steering wheel.Multifunction steering wheel, Sport Chrono Package
PDK gear selector
Performance |
Transmission

6061
Porsche Traction Management (PTM).
Porsche Traction Management (PTM)
comprises an active all-wheel drive with
electronic and map - controlled multi - plate
clutch, with automatic brake differential
(ABD) and anti-slip regulation (ASR).

The electronically controlled multi - plate
clutch regulates the distribution of drive
force bet ween the permanently driven
rear axle and the front axle. Through
continuous monitoring of the driving
conditions, the electronics are able to respond to a variet y of situations.
Sensors check, among other variables,
the rotation speeds of all four wheels,
longitudinal and lateral acceleration of
the vehicle, and the steering angle. If, for
example, the rear wheels spin under
acceleration, a greater proportion of
drive force is redirected to the front by a
more powerful engagement of the multi-
plate clutch. In addition, ASR reduces
wheel slip. In corners, the drive force
sent to the front wheels is regulated for
optimum lateral stability.
Exerting your authority. Letting go. Providing balance.

Typical powers of management.

Chassis.
In this way, PTM, in conjunction with
the upgraded version of Porsche Stabilit y
Management (PSM, p. 67) ensures
optimum force delivery in every driving
situation and excellent acceleration
power: whether on long straights, through
tight corners, or on road surfaces with
varying grip.
Standard in the Panamera 4,
Panamera 4S, Panamera GTS and
Panamera Turbo.
Active all-wheel drive
Performance |
Chassis

6263
Steering and Power steering Plus.
The steering system with its variable
steering ratio is precise and direct.
Around the straight ahead position, such
as when on the motorway, the ratio is less
direct with no loss of agilit y or feedback
from the road. When the steering wheel is
turned further, the steering ratio becomes
more direct, allowing easier cornering and
parking. For even greater driving comfort,
speed-sensitive Power steering Plus is
available as an option. At high speeds,
the firmer steering ratio enables precision
steering manoeuvres; at low speeds,
the ratio automatically adjusts to facilitate
parking. Power steering Plus is standard in the
Panamera S E-Hybrid and optional for

all other Panamera models.
Steering wheels.
The multifunction steering wheel is
standard in all models and available on
request for the Panamera GTS at no
extra cost. It features t wo ergonomic
gearshift switches for manual gear
selection and of fers convenient control
of audio, telephone and navigation
functions as well as the on-board
computer. In conjunction with PDK and
the Sport Chrono Package (p. 68), you
will find an additional display above the airbag module for the SPORT and

SPORT PLUS modes and the Launch
Control function.
The SportDesign steering wheel with
gearshift paddles is fit ted as standard
in the Panamera GTS and available
as an option for all other models. It is
distinguished by its striking dual-arm
design. Upon request, it is possible to
have the SportDesign steering wheel
finished in black Alcantara.
We haven’t reinvented the wheel.
Just about everything else that goes with it.
SportDesign steering wheel, Sport Chrono Package
Multifunction steering wheel
Performance |
Chassis

6465

Porsche Active Suspension
Management (PASM).
PASM is an electronic damping control
system and it actively and continuously
adjusts the damping force on each
wheel, based on road conditions and
driving st yle. This reduces body
movement and therefore increases
comfort in all four seats.

How does PASM work? By means of a
but ton on the centre console, you can
select one of the three modes: Comfort,
SPORT or SPORT PLUS. Sensors record
the body movements that accompany powerful acceleration, braking and

rapid cornering or uneven road surfaces.
The control unit evaluates the driving
conditions and modifies the damping
force on each of the wheels in
accordance with the selected mode. You
can feel the result: increased driving
stability, more comfort and improved
performance.
Optional for the Panamera and
Panamera 4, standard in all other models.
Do you love the road?
Keep your relationship intimate.
Adaptive air suspension.
Adaptive air suspension enhances both
driving dynamics and comfort at the
same time. It comprises a levelling
system, a manual lift function, ride-height
adjustment capability and the ability to
vary the spring rate.

The purpose of the levelling system is
to keep the vehicle level constant auto -
matically, regardless of load distribution.
For manoeuvring, the manual lift function
enables you to raise the vehicle body
by 20 mm to avoid the risk of grounding. When you select the SPORT PLUS
chassis programme, the ride height
drops to Low Level (–
25 mm, or – 15 mm
in the Panamera GTS). At the same time,
a harder spring rate is achieved through
a reduction in the amount of air stored in
the air suspension. In simple terms, it’s
a sports chassis at the push of a but ton.
Standard for the Panamera S E-Hybrid,
Panamera GTS and Panamera Turbo,
optional for the other models.
Wheels and Tyre Pressure Monitoring
(TPM).
The Panamera and Panamera 4 are
fit ted as standard with 18-inch Panamera
wheels, the Panamera S, 4S and
Panamera S E-Hybrid with 18-inch
Panamera S wheels. The wheels on all
models are light weight alloys featuring
a classic sport y design. Tyre sizes
245/50 ZR 18 and 275/45 ZR 18 are
fit ted to the front and rear, respectively.
The Panamera GTS and Panamera Turbo
are equipped with 19-inch Panamera
Turbo II wheels as standard. The t yre
sizes are 255/45 ZR 19 at the front, 285/40 ZR 19 at the rear. A range of
optional 19- and 20 -inch wheels is

also available (p. 128/129). In addition,
all-season tyres are optionally available
for all 19- and 20 -inch wheels.

Tyre Pressure Monitoring (TPM) sends
warnings to the on-board computer’s
display screen in the event of excessive
pressure loss.

TPM is standard in the Panamera models
(optional for Panamera and Panamera 4).19 - inch Panamera Turbo ll wheel
18 - inch Panamera S wheel
18-inch Panamera wheel
Performance |
Chassis
