2013 PEUGEOT 2008 reset

06





PRESET A STATION

From the permanent display, press "Memory".

Select a radio station or frequency
(refer to the corresponding section).
Select a number in the list to preset the
previously chosen radio station.
A long press on this number presets (momorises) the station.

Recall
pre-set stations

Press MENUto display the " MAIN MENU " then select " Media".
Select "Radio".
RADIO
Select "Memory".
238

01
270
FIRST STEPS


Select the source:
- FM1, FM2, AM, CD, USB, AUX,
Streaming.
- accept an
incoming call.
Long press:
- open the calls lo
g for the
telephone connected.
- or end a call i
f in progress.

Adjust audio settings:
sound ambience, treble,
bass, loudness, distribution,
left/right balance, front/rear balance, automatic volume. On / Off and volume
adjustment.
A
bandon the current
operation.
Go up one level (menu or folder).
Eject CD.

Select a
preset radio station.
Radio: long press: preset a
radio station.
Other than radio: see the corresponding sections.
Automatic search for a lower / higher radio
frequency.
Select previous / next CD, USB track.
Navigation in a list.
Pr
ess and hold: fast forwards or backwards.
Open the main menu.

Display the list of stations received, theCD/USB tracks or folders.
Lon
g press: update the list of stationsreceived.

02STEERING MOUNTED CONTROLS
271
RADIO: selection of the previous / nextpreset station.
CD / USB: selection of the previous
genre / artist / folder / playlist from the list
depending on classifi cation.

Change of sound source.

Confi rmation of a selection.
Start/End call with the tele
phone.
Pr
ess for more than 2 seconds:
access to the call log.

RADI
O: automatic search for a lower frequency.

CD / MP3 / USB: selection of the previous track.
CD / USB: continuous press: fast
reverse.
RADI
O: automatic search for a higher
frequency.

CD / MP3 / USB: selection of the next
track.
CD / USB: continuous press: fast
forwards play.

V
olume increase.

V
olume decrease.
Mute the sound by pressing the volume
increase and decrease
buttons simultaneously.
Restore the sound: b
y pressing one of the
two volume buttons.

03
272
RADIO
Press SRC/TEL
repeatedly and select
the FM1, FM2 or AM waveband.
Press a button to listen to the corresponding preset station.
Select the desired radio station and confi rm by pressing "OK".







RADIO

Press LIST
to display the list of stations
received in alphabetical order.
The exterior environment
(hills, buildings, tunnel, car park, below ground...) may prevent reception, even in RDS station tracking (alternative
frequencies) mode. This phenomenon is normal in the propagation of radio waves and is in no way indicative of a fault with the audio system.

A long press on LIST
builds or updates
the list of stations; audio reception is cut
momentarily.
Make a lon
g press on one of the buttons
to preset the station being listened to.
The name o
f the station is displayed andan audible signal confi rms the preset.

A press chan
ges to the next or previous
letter (e.g. A, B, D, F, G, J, K, ...). MANAGE THE LIST
PRESETTING AND SELECTING A STATION
When recalling a preset station, of the reception of the station is poor, the radio will try to fi nd a frequency transmitting the same programme and a message appears in the screen.

290
FREQUENTLY ASKED QUESTIONS
QUESTIONANSWER SOLUTION
There is a difference in sound quality between
the different audiosources (radio, CD...). For optimum sound qualit
y, the audio settings (volume, bass, treble, ambience, loudness) can be adapted to the different sound sources,
which may result in audible differences when changing source (radio,
CD...).
Check that the audio settings (volume, bass,
treble, ambience, loudness) are adapted to thesources listened to. It is advisable to adjust audio settings (bass, treble, Front-Rear balance, Left-Right balance) to the middle position, select the musical ambience and set the loudness correction
to the "Active" position in CD mode or to the "Inactive" position in radio mode.
When chan
ging the settings for treble and
bass, the ambience
setting is deselected.
When chan
ging the
ambience setting, treble and bass are reset to zero.
Choosing an ambience imposes settings for treble and bass. Modifyingone without the other is only possible with a personalised ambience. Modify the treble and bass settings or the
ambience setting to obtain the desired sound quality.
When chan
ging the
balance setting, distribution is deselected.
Choosing the "driver" distribution setting imposes a balance setting. Modify the balance setting or the distribution setting to obtain the desired sound quality. The
following tables contain answers to the most frequently asked questions.

01
FIRST STEPS
296
Selection of source:
FM1, FM2, AM,
CD, AUX.
Adjust audio settings:
sound ambience, treble, bass,loudness, left/right balance, automatic volume.
Abandon the current
operation.
Go up one level (menu or folder).
A
utomatic search for a lower/higher radio frequency.
Select the previous/next CD
track.
Navi
gation in a list.
Pr
ess and hold: fast forwardor backward.
Eject CD.

Manual search step by step for a lower/higher radio frequency.
Select the previous/nextMP3 track.
Navi
gation in a list.
Open the mainmenu. Select a preset radio station.Radio: long press: preset a radiostation. Displa
y the list of stations received,
the CD/MP3 tracks or MP3 folders.
Lon
g press: update the list of stations received.


On / Off and
volume adjustment.

02 STEERING MOUNTED CONTROLS
297


RADIO: select previous / next presetstation.

Select previous / next item in a menu.

Change audio source.
Confi rm a selection.

RADI
O: automatic search for previousfrequency.
CD / MP3: select the
previous track.
CD:
press and hold: fast backward.
RADI
O: automatic search for next
frequency.

CD / MP3: select the next track.

CD: press and hold: fast forward.

Volume up.

V
olume down.
Mute on; cuts the sound:
simultaneous press on
volume up and downbuttons.
Mute o
ff: press one of the
volume buttons.

03
Press the SRC/BANDbutton several
times in succession and select the FM1, FM2 or AM waveband.
Pr
ess a button to listen to the corresponding preset station.Press to chan
ge to the next or previousletter (e.g. A, B, D, F, G, J, K, ...).


RADIO

Select the desired radio station thenconfi rm by pressing OK.

SELECTING A STATION
Make a lon
g press on LIST
to construct
or update the list of stations; the sound
is interrupted temporarily.
The external environment
(hills, buildings, tunnels, basement car parks) may block reception, including in RDS mode. This is a normal effect of the way in which radio waves are transmitted and
does not indicate any failure of the audio equipment.
SELECTING A PRESET STATION
Make a lon
g press on a button to
preset the station being listened to. The
name of the station is displayed and anaudible signal confi rms that it has been
preset.
Pr
ess LIST
to display the list of stations
received, in alphabetical order.
AUDIO
298
