2013 Lexus ES300h Instrument cluster / Owner's Manual (OM33A01U)

585
ES350 300h_OM_OM33A01U_(U)
5-4. Using the audio system
5
Interior features
Setting a cellular phone
To enter the menu for each function, follow the steps below using a voice
command or :
●Registering a cellular phone
1. “Setup”  2. “Phone Setup”  3. “Pair Phone”
●Selecting a cellular phone to be used
1. “Setup”  2. “Phone Setup”  3. “Connect Phone (Connect)”
●Changing the registered name of a cellular phone
1. “Setup”  2. “Phone Setup”  3. “Change Name”
●Listing the registered cellular phones
1. “Setup”  2. “Phone Setup”  3. “List Phones”
●Changing the passkey
1. “Setup”  2. “Phone Setup”  3. “Set Passkey”
●Deleting a registered cellular phone
1. “Setup”  2. “Phone Setup”  3. “Delete Phone”
Select “Pair Phone” using a voice command or , and perform the
procedure for registering a cellular phone. ( P. 5 76 )
Registering a cellular phon e in the hands-free phone system allows the
system to function. The following functions can be used for registered
cellular phones:
Functions and operation procedures
Registering a cellular phone

586
ES350 300h_OM_OM33A01U_(U)
5-4. Using the audio system
Select “Connect Phone (Connect)” using a voice command or
.
Pattern A
Select the cellular phone to be used by either of the following methods,
and select “Confirm” by using a voice command or :
a. Press the talk switch and say the name of the desired cellular phone.
b. Press the talk switch and say “L ist Phones”. When the name of the
desired cellular phone is read aloud, press the talk switch.
Pattern B
Select the cellular phone to be used using .
Select “Change Name” using a voice command or .
Pattern A
Select the name of the cellular phone to be changed by either of the fol-
lowing methods, and select “Co nfirm” using a voice command or
:
a. Press the talk switch and say the name of the desired cellular phone.
b. Press the talk switch and say “L ist Phones”. When the name of the
desired cellular phone is read aloud, press the talk switch.
Selecting a cellular phone to be used
Changing the registered name of a cellular phone
1
2
3
1
2

ES350 300h_OM_OM33A01U_(U)
5875-4. Using the audio system
5
Interior features
Pattern B
Select the desired cellular phone name to be changed using .
Press the talk switch or select “Record Name” using , and say
the new name.
Select “Confirm” using a voice command or .
Select “List Phones” using a voice command or . The list of regis-
tered cellular phones will be read aloud.
When listing is complete, the sys tem returns to “Phone Setup”.
Pressing the talk switch while the name of a cell ular phone is being read
aloud selects the cellula r phone, and the following functions will become
available:
●Selecting a cellular phone: “Connect Phone (Connect)”
●Changing a registered name: “Change Name”
●Deleting a cellular phone: “Delete Phone”
Listing the registered cellular phones
2
3
4

588
ES350 300h_OM_OM33A01U_(U)
5-4. Using the audio system
Select “Set Passkey” using a voice command or .
Pattern A
Press the talk switch, say a 4 to 8-digit number, and select “Confirm”
using a voice command or .
Pattern B
Select a 4 to 8-digit number using .
The number should be input 1 digit at a time.
When the entire number to be regis tered as a passkey has been input,
press again.
If the number to be registered has 8 digits, pressing of the knob is not necessary.
Select “Delete Phone” using a voice command or .
Pattern A
Select the cellular phone to be deleted by either of the following meth-
ods and select “Confirm” using a voice command or :
a. Press the talk switch and say the name of the desired cellular phone.
b. Press the talk switch and say “L ist Phones”. When the name of the
desired cellular phone is read aloud, press the talk switch.
Changing the passkey
Deleting a registered cellular phone
1
2
2
3
1
2

ES350 300h_OM_OM33A01U_(U)
5895-4. Using the audio system
5
Interior features
Pattern B
Select the desired cellular phone to be deleted using .
If the cellular phone to be del eted is paired as a Bluetooth
® audio player,
the registration of the audio player can be deleted at the same time. A
voice guidance instruction to delete a Bluetooth
® audio player is heard.
Select “Yes” or “No” using a voice command or .
(Bluetooth
® audio player P. 542)
■The number of cellular phones that can be registered
Up to 6 cellular phones can be registered in the system.
2
3

590
ES350 300h_OM_OM33A01U_(U)
5-4. Using the audio system
Security and system setup
To enter the menu for each function, follow the steps below using a voice
command or :
●Setting or changing the PIN (Personal Identification Number)
1. “Setup”  2. “Security”  3. “Set PIN”
●Locking the phone book
1. “Setup”  2. “Security”  3. “Phonebook Lock (Phbk Lock)”
●Unlocking the phone book
1. “Setup”  2. “Security”  3. “Phonebook Un lock (Phbk Unlock)”
To enter the menu for each function, follow the steps below using :
●Setting voice guidance volume
1. “Setup”  2. “System Setup”  3. “Guidance Vol”
●Displaying the Bluetooth® device address and name
1. “Setup”  2. “System Setup”  3. “Device Name”
●Initializing the system
1. “Setup”  2. “System Setup”  3. “Initialize”
Security setting items and operation procedures
System setup items and operation procedures

ES350 300h_OM_OM33A01U_(U)
5915-4. Using the audio system
5
Interior features
■Setting a PINSelect “Set PIN” using a voice command or .
Enter a PIN using a voice command or .
When using , input the code 1 digit at a time.
■Changing the PINSelect “Set PIN” using a voice command or .
Enter the registered PIN using a voice command or .
Enter a new PIN using a voice command or .
When using , input the code 1 digit at a time.
Setting or changing the PIN
1
2
1
2
3

592
ES350 300h_OM_OM33A01U_(U)
5-4. Using the audio system
Select “Phonebook Lock (Phbk Lock)” or “Phonebook Unlock (Phbk
Unlock)” using a voice command or .
Input the PIN by either of the following methods and select “Confirm”
using a voice command or :
a. Press the talk switch and say the registered PIN.
b. Input a new PIN using .
Select “Guidance Vol” using .
Change the voice guidance volume.
To decrease the volume: Turn counterclockwise.
To increase the volume: Turn clockwise.
Locking or unlocking the phone book
Setting voice guidance volume
1
2
1
2
