2013 INFINITI G CONVERTIBLE Owner's Manual

9-10Technical and consumer information
DIMENSIONSGUID-704F2C89-EE05-4CD3-84B9-D4D5FC1C9816in (mm)
Overall length (with front license plate) 183.5 (4,661)*1
184.0 (4,672)*2
185.5 (4,712)*3
Overall length (without front license plate) 183.3 (4,657)*1
184.0 (4,672)*2
185.3 (4,706)*3
Overall width 72.9 (1,852)
Overall height 55.1 (1,399)*4
55.1 (1,400)*5
Front tread 60.8 (1,545)
Rear tread 62.8 (1,595)*4
62.6 (1,590)*5
Wheelbase 112.2 (2,850)
*1: Without Aero Bumper
*2: With Aero Bumper
*3: INFINITI Performance Line model
*4: 18-in tire models
*5: 19-in tire models

GUID-1DFF6920-97A0-4DA9-B651-6F777CC848D1If you plan to travel in another country,
you should first find out if the fuel
available is suitable for your vehicle’s
engine.
Using fuel with too low an octane rating
may cause engine damage. All gasoline
vehicles must be operated with unleaded
gasoline. Therefore, avoid taking your
vehicle to areas where appropriate fuel is
not available.
When transferring the registration of your
vehicle to another country, state, province
or district,it may be necessary to modify
the vehicle to meet local laws and regula-
tions.
The laws and regulations for motor vehicle
emission control and safety standards vary
according to the country, state, province or
district; therefore, vehicle specifications
may differ.
When any vehicle is to be taken into
another country, state, province or district
and registered, its modifications, trans-
portation, and registration are the respon-
sibility of the user. INFINITI is not
responsible for any inconvenience that
may result.GUID-F41F7467-7DF3-4B7D-ABAC-5C9EFE4F5D55
STI0431
VEHICLE IDENTIFICATION NUMBER
(VIN) PLATE
GUID-D4BA69C4-2062-40A9-B5C1-8906F7BF7537The vehicle identification number plate is
attached as shown. This number is the
identification for your vehicle and is used
in the vehicle registration.
STI0492
VEHICLE IDENTIFICATION NUMBER
(chassis number)
GUID-D52F97FB-EEC6-449E-94A8-68BE1813E836The number is stamped as shown in the
engine compartment.
Technical and consumer information9-11
WHEN TRAVELING OR REGISTERING YOUR
VEHICLE IN ANOTHER COUNTRY VEHICLE IDENTIFICATION

9-12Technical and consumer information
STI0509
ENGINE SERIAL NUMBERGUID-8DFD2952-052D-460D-B566-B62FBD5606A3The number is stamped on the engine as
shown.
STI0800
F.M.V.S.S./C.M.V.S.S. CERTIFICA-
TION LABEL
GUID-7777AE2C-849D-4907-9F2F-93D079D805DBThe Federal/Canadian Motor Vehicle Safety
Standards (F.M.V.S.S./C.M.V.S.S.) certifica-
tion label is affixed as shown. This label
contains valuable vehicle information, such
as: Gross Vehicle Weight Ratings (GVWR),
Gross Axle Weight Rating (GAWR), month
and year of manufacture, Vehicle Identifi-
cation Number (VIN), etc. Review it care-
fully.
STI0422
EMISSION CONTROL INFORMATION
LABEL
GUID-33299DCD-86BD-4813-92F3-A93C267D1663The emission control information label is
attached as shown.

STI0801
TIRE AND LOADING INFORMATION
LABEL
GUID-9D00F680-456E-4290-B749-35ABDC8427E9The cold tire pressure is shown on the Tire
and Loading Information label affixed to
the pillar as illustrated.
STI0495
AIR CONDITIONER SPECIFICATION
LABEL
GUID-87CEC58E-0226-411C-AE98-7586EC50F7BEThe air conditioner specification label is
attached as shown.
GUID-974FE228-79BE-4D41-B1D0-797A03FDF9D1Use the following steps to mount the
license plate:
Before mounting the license plate, confirm
that the following parts are enclosed in the
plastic bag.
.License plate bracket
. J-nut 62 (except for INFINITI Perfor-
mance Line model)
. Screw 62
. Screw grommet 62
Only use the recommended mounting
position or Intelligent Cruise Control (ICC)
sensor obstruction (if so equipped) may
result.
Technical and consumer information9-13
INSTALLING FRONT LICENSE PLATE

9-14Technical and consumer information
STI0799
Except for INFINITI Performance Line model
EXCEPT FOR INFINITI PERFORMANCE
LINE MODEL
GUID-3D1C304A-406E-415C-8D62-CDAE8F0DB8AE1. Park the vehicle on flat, level ground.
2. Locate the center position indicator
*Aon the lower part of the grille. Measure
straight down from the edge where the
bumper and grille meet to the aligning
holes
*B, keeping the tape measure
lined up with the center position
indicator.
3. Mark the holes
*Bwith a felt-tip pen.
4. For Sports models: Carefully drill the two aligning holes
*Busing a 0.39 in
(10 mm) drill bit at the marked loca-
tions. (Be sure that the drill only goes
through the bumper fascia.)
5. For Sports models: Line up the bosses
*Cor license plate bracket with the
holes and hold the license plate brack-
et in place.
6. Mark the center of the holes
*Dwith a
felt-tip pen.
7. Carefully drill the two pilot holes using a 0.39 in (10 mm) drill bit at the marked
locations. (Be sure that the drill only
goes through the bumper fascia.)
8. Insert grommets into the hole on the

9-16Technical and consumer information
STI0805
For INFINITI Performance Line model
FOR INFINITI PERFORMANCE LINE
MODEL
GUID-5684B0DB-28E1-48BD-903A-861C09C8D7EF1. Park the vehicle on flat, level ground.
2. Temporarily fit the license plate bracketon the center of the front bumper
fascia.
3. For horizontal position adjustment,
place and hold the underside tab of
the license plate bracket on the front
bumper fascia to align the tab’s V notch
with the edge of a bead on the upper
side of front bumper fascia.
4. Hold the license plate bracket and mark the points
*Aon the bumper facia
through the center of the holes
*Bwith
a felt-tip pen.
5. Remove the license plate bracket.
6. Detach the license plate bracket and cut the underside tab by using a cutter.
7. Carefully drill two shallow pilot holes
*Ausing a 0.39 in (10 mm) drill bit at
the marked locations. (Be sure that the
drill only goes through the fascia, or
damage to the nut may occur.)
8. Insert grommets into the hole on the front bumper fascia.

9. Insert a flat-blade screwdriver into thegrommet hole to add a 908 turn onto
the part
*C.
10. Install the license plate bracket with the bolts.
11. Install the license plate with bolts that are not longer than 0.55 in (14 mm).
GUID-FA938551-A2AF-4C28-8038-A1023026D8A8
WARNING
.It is extremely dangerous to ride
in a cargo area inside the vehicle.
In a collision, people riding in
these areas are more likely to be
seriously injured or killed.
.Do not allow people to ride in any
area of vehicle that is not
equipped with seats and seat
belts.
.Be sure everyone in your vehicle is
in a seat and using a seat belt
properly.
TERMSGUID-AFE6BEE1-94DB-40B4-B4CC-6439DC599E16It is important to familiarize yourself
with the following terms before
loading your vehicle:
.Curb Weight (actual weight of yourvehicle) - vehicle weight includ-
ing: standard and optional equip-
ment, fluids, emergency tools,
and spare tire assembly. This weight
does not include passen-
gers and cargo.
.GVW (Gross Vehicle Weight) - curb weight plus the combined weight
of passengers and cargo.
.GVWR (Gross Vehicle Weight Rat-ing) - maximum total combined
weight of the unloaded vehicle,
passengers, luggage, hitch, trailer
tongue load and any other op-
tional equipment. This informa-
tion is located on the F.M.V.S.S./
C.M.V.S.S. label.
.GAWR (Gross Axle Weight Rating) -maximum weight (load) limit spe-
cified for the front or rear axle.
This information is located on the
F.M.V.S.S./C.M.V.S.S. label.
.GCWR (Gross Combined WeightRating) - The maximum total
weight rating of the vehicle, pas-
sengers, cargo, and trailer.
.Vehicle Capacity Weight, Loadlimit, Total load capacity - max-
imum total weight limit specified
Technical and consumer information9-17
VEHICLE LOADING INFORMATION
