2013 HONDA RIDGELINE Owners Manual

356
12/08/09 16:46:09 31SJC670_363

This section covers the more
common problems that motorists
experience with their vehicles. It
gives you inf ormation about how to
safely evaluate the problem and what
to do to correct it. If the problem has
stranded you on the side of the road,
you may be able to get going again.
If not, you will also f ind instructions
on getting your vehicle towed.......................
Compact Spare Tire .358
....................
Changing a Flat Tire .359
.............
If the Engine Won’t Start . 367
................................
Jump Starting .368
..............
If the Engine Overheats . 370
.........
Low Oil Pressure Indicator . 372
..........
Charging System Indicator . 372
.......
Malf unction Indicator Lamp . 373
...............
Brake System Indicator . 374
..............................................
Fuses .376
..............................
Fuse Locations .379
......................
Emergency Towing .381
..........
If Your Vehicle Gets Stuck . 381
Taking Care of the Unexpected
357
12/08/09 16:46:12 31SJC670_364

Use the compact spare tire as a
temporary replacement only. Get
your regular tire repaired or replaced,
and put it back on your vehicle as
soon as you can.
Check the air pressure of the
compact spare tire every time you
check the other tires. It should be
inf lated to:
Follow these precautions:Replace the tire when you can see
the tread wear indicator bars. The
replacement tire should be the same
sizeanddesign,mountedonthe
same wheel. The spare tire is not
designed to be mounted on a regular
wheel, and the spare wheel is not
designed f or mounting a regular tire.
Never exceed 50 mph (80 km/h).
This tire gives a harsher ride and
less traction on some road
surf aces. Use greater caution
while driving.
Do not mount snow chains on a
compact spare. Do not use your compact spare
tire on another vehicle unless it is
thesamemakeandmodel.
The low tire pressure indicator
comes on and stays on af ter you
replace the flat tire with the compact
spare tire. Af ter several miles
(kilometers) driving with the
compact spare tire, the TPMS
indicator comes on and the low tire
pressure indicator goes of f .
After the flat tire is replaced with the
spare tire, the low tire pressure/
TPMS indicator stays on. After
several miles (kilometers) driving
with the spare, this indicator begins
to f lash, then stays on again. You will
also see a ‘‘CHECK TPMS
SYSTEM’’ message on the multi-
inf ormation display (see page ). 282
On models without navigation system
On models with navigation system
Compact Spare Tire
358
INDICATOR LOCATION MARK
TREAD WEAR INDICATOR BAR
60 psi (420 kPa , 4.2 kgf/cm)
12/08/09 16:46:20 31SJC670_365
T aking Care of t he Unexpect ed

Turn on the hazard warning lights,
and turn the ignition switch to the
LOCK (0) position. Have all
passengers get out of the vehicle
while you change the tire.
Park the vehicle on f irm, level, and
non-slippery ground. Put the
transmission in Park. Apply the
parking brake.
If you are towing a trailer,
unhitch it.
If you have a f lat tire while driving,
stop in a saf e place to change it.
Drive slowly along the shoulder until
you get to an exit or an area to stop
that is far away from the traffic lanes.
If you tow a trailer f requently, we
recommend that you use a regular
tire as a spare. You can store the
regular size spare tire on the tire tray,
but store the tool kit at the side of
the In-Bed Trunk (see page ),
and secure it.
2.
1.
365
CONT INUED
Changing a Flat Tire
T aking Care of t he Unexpect ed
359
TOOL BOX SPARE TIRE
The vehicle can easily roll off
the jack, seriously injuring
anyone underneath.
Follow the directions for
changing a tire exactly, and
never get under the vehicle
when it is supported only by the
jack.
12/08/09 16:46:27 31SJC670_366

Open the In-Bed Trunk.
Remove the two tire trayPull out the tire tray with the
handle, and hook the rear of the
tire tray to the guides on the back
edge of the In-Bed Trunk.Unfasten the strap to remove
the tool box, and unscrew the
wing bolt.
Takeoutthecompactsparetire.
If you are using a cargo net or a
cargo cover in the In-Bed Trunk,
remove it before pulling out the
tire tray.
4. 3.
5.6.
7.
Changing a Flat Tire
360
WING BOLT
TOOL BOX STRAP
TIRE
TRAY
TIRE TRAY HOLDING BOLTS
12/08/09 16:46:36 31SJC670_367
T aking Care of t he Unexpect ed
holding bolts.

CONT INUED
Loosen each wheel nut 1/2 turn
with the wheel nut wrench.Place the jack under the jacking
point nearest the tire you need
to change.Turn the dial at the bottom of the
jack clockwise until the top of the
jack contacts the jacking point.
Make sure the jacking point tab is
restinginthejacknotch.
8.
9.10.
Changing a Flat Tire
361
JACKING POINT DIAL
12/08/09 16:46:42 31SJC670_368
T aking Care of t he Unexpect ed

Attach the stay to the extension,
then attach the wheel nut wrench
to the end of the extension.Turn the jack dial (wheel nut
wrench) clockwise as shown to
raise the vehicle until the f lat tire
is of f the ground.
Make sure the stay, the extension,
and the wheel nut wrench are
securely attached. Insert the hook at the end of the
stay into the opening on the dial at
the bottom of the jack.
11.
12.13.
Changing a Flat Tire
362
EXTENSION
DIAL
CONNECTOR BUTTON
HOOK
STAY WHEEL NUT WRENCH
CONNECTOR BUTTON
12/08/09 16:46:48 31SJC670_369
T aking Care of t he Unexpect ed

CONT INUED
Put on the spare tire. Put the
wheel nuts back on f inger-tight,
then tighten them in a crisscross
pattern with the wheel nut wrench
until the wheel is f irmly against
the hub. Do not try to tighten the
wheel nuts f ully.
Lower the vehicle to the ground,
and remove the jack.
Before mounting the spare tire,
wipe any dirt off the mounting
surface of the wheel and hub
with a clean cloth. Wipe the
hub carefully; it may be hot
from driving.
The wheel cap cannot be
removed without first removing
the wheel nuts. Remove the wheel nuts and the
wheel cap (on RT and DX models)
then remove the f lat tire. Handle
the wheel nuts caref ully; they may
be hot from driving. Place the flat
tire on the ground with the outside
surface facing up.
14.
15.16.
17.
On RT and DX models
Changing a Flat Tire
363
BRAKE HUB
WHEEL CAP
RT/DX model is shown.
12/08/09 16:46:56 31SJC670_370
T aking Care of t he Unexpect ed
