2013 Citroen DS5 HYBRID4 engine

243Checks





Before doing anything under the bonnet,switch off the ignition (Ready
lamp off) to avoid any risk of injury resulting fromautomatic operation of the engine. Th
e brake fluid level should be close
to the "MA X" mark. If it is not, check
the brake pad wear.
Brake fluid level

Changing the fl uid

Refer to the servicing and warranty booklet for
details of the interval for this operation.

Fluid specifi cation

The brake fluid must conform to themanufacturer's recommendations and meet the
DOT3 or DOT4 standard.
The power steerin
g fluid level should be close to the "MA X" mark. With
the engine cold, unscrew the cap to check the level.
Power steering fluid levelCoolant level

The coolant level should be closeto the "MAX" mark but should never exceed it.
When the en
gine is warm, the temperature of
the coolant is regulated by the fan. This can
operate with the ignition off.
On vehicles which are fitted with a particle
emission filter, the fan may operate after
the vehicle has been switched off, even if
the en
gine is cold.
In addition, as the cooling system ispressurised, wait at least one hour after
switching off the engine before carryingout any work. To avoid any risk of scalding, unscrewthe cap by two turns to allow the pressure to drop. When the pressure has dropped, remove the cap and top upthe level.

Changing the coolant
The coolant does not have to be changed.


Fluid specifi cation

The coolant must conform to the
manufacturer's recommendations.

Screenwash / headlamp
wash level
To check the level or top up the fluid on vehicle
fitted with headlamp washers, immobilise the
vehicle and switch of the en
gine. )Before opening the bonnet, ensure that the
engine has completely stopped. )Open the screenwash reser voir filler cap.

To p p i ng up

This additive must be topped up by a CITROËN
dealer or a qualified workshop without delay.

Diesel additive level
(Diesel engine with particle
emission filter)
A low additive level is
indicated by illumination of
the ser vice warning lamp,
accompanied by an audible warning and amessage in the instrument panel screen.

Specifi cation of the fl uid
To ensure optimum cleaning and to avoid freezing, the fluid should never be topped up or
replaced by plain water.

)
Take and pinch the level gauge to block itsbreather.)
Remove the gauge completely from
the reservoir to read the level in thetransparent section.) To p u p i f n e c e s s a ry. )
Refit the filler cap to the reser voir and close the bonnet.

Checks
Avoid prolonged contact of used oil or fluids with the skin. Most of these fluids are harmful to
health or indeed very corrosive.

Do not discard used oil or fluids into sewers or onto the ground.
Take used oil to a CITROËN dealer or a qualified workshop (France) or to anauthorised waste disposal site.
Used products







Checks
Unless otherwise indicated, check these
components in accordance with the servicingand warranty booklet and according to your
engine.
Other wise, have them checked by a CITROËN
dealer or a qualified workshop.
Before doing anything under the bonnet, switch off the ignition ( Readylamp off)to avoid any risk of injury resulting from automatic operation of the engine.The presence o
f this label, in particular with
the Stop & Start system, indicates the use of
a specific 12 V lead-acid battery with special
technology and specification. The involvement of a CITROËN dealer or a qualified workshop is essential when replacing or disconnecting the
battery.
12 V battery
The battery does not require any maintenance.
However, check that the terminals are clean
and correctly tightened, par ticularly in summer and winter.
When carrying out work on the battery, refer
to the "12 V battery" section for details of the precautions to be taken before disconnecting
the battery and following its reconnection.

Particle emission filter (Diesel)
The start of saturation of theparticle filter is indicated bythe temporary illumination of
this warning lamp accompanied by a message
in the multi-function screen.
As soon as the traffic conditions permit, regenerate the filter by driving at aspeed of at least 40 mph (60 km/h) until the warning lamp goes off.
If the warning lamp stays on, this indicates a low additive level.


On a new vehicle, the first par ticlefilter regeneration operations may be accompanied by a "burning" smell, which is perfectly normal.
Following prolonged operation of the vehicle at very low speed or at idle, you may, in exceptional circumstances,notice the emission of water vapour at the exhaust on acceleration. This does not affect the behaviour of the vehicle or the environment.
The 100% electric mode is not available during regeneration of the par ticle emissions filter.
Air filter and passenger compartment filter
Oil filter

Replace the oil filter each time the engine oil is changed.
Refer to the ser vicing and warrantybooklet for details of the replacement
interval for this component.
Re
fer to the ser vicing and warrantybooklet for details of the replacement
inter vals for these components.
Dependin
g on the environment (e.g. dustyatmosphere) and the use of the vehicle (e.g. city driving), replace them twice as often if necessary. y A clogged passenger compartment filter mayhave an adverse effect on the per formance
of the air conditioning system and generate undesirable odours.

Range varies according to the ambient climatic conditions, the driving style and conditions, the use of vehicle systems and ageing of the battery.











Electric motor and battery
Electric motor-

Te c h n o l ogy
Synchronous with permanent magnets.
Max. power: EU standard
(kW) *
27

Max. power speed (rpm)

2 500

Max. torque: EU standard (Nm)

200

Max. torque speed (rpm) 1 250

E
fficiency (%) 80 to 90
High voltage batteryNi-MH(Nickel Metal Hydride)

Volt a
ge (V~)

200

Energy capacity (kWh / Ah)

1.1 / 5.5
Ran
ge (miles (km)) 1. 2 (2) (approximately)

*

The maximum power corresponds to the value type approved on an engine test bed, under conditions defined by European legislation
(directive 1999/99/EC).

251Technical data













Engine and gearbox
Diesel engineHDi160 PEF
Gearbox

Electronic gearbox system(6-speed)

Model code

RHC

Cubic capacit
y (cc)

1 997
Bore x stroke
(mm) 85 x 88

Max power: EU standard (kW) *

120
Max power en
gine speed (rpm) 3 850

Max torque: EU standard
(Nm)
300

Max torque en
gine speed (rpm) 1 750

Fuel

Diesel

Catalytic converter
yes

P
article emission filter
yes

Oil capacities
(in litres)
Engine (with filter replacement) -

*

The maximum power corresponds to the type approved value on a test bed, under conditions defined by European legislation (directive 1999/99/EC).

Diesel engineHDi160PEF
Gearbox
Electronic gearbox system(6-speed)
Model code

RHC



- Unladen weight-


- Kerb weight
*



1 735


- Gross vehicle wei
ght (GV W)
2 265


- Gross train wei
ght (GT W)
on a 12% gradient
2 765



- Braked trailer (within GTW limit) on a 10% or 12% gradient 500



- Braked trailer
**
(with load transfer with the GTW limit)
800



- Unbraked trailer
500



- Recommended nose wei
ght 75

















Weights and towed loads (in kg)
*

The kerb weight is equal to the unladen weight + driver (75 kg).
**
The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
To make use of the 300 kg load transfer, the driver must be alone in the vehicle with no luggage in the vehicle.
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced b
y 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the per formance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

ANSWER SOLUTION
With the engine off, the system switches off after a few minutes of use.When the en
gine is switched off, the system's operating time depends on
the battery charge.
The switch-o
ff is normal: the system switches to economy mode and
switches off to prevent discharging of the vehicle's battery. Start the vehicle's en
gine to increase the batterycharge.
Pla
yback of my USB memory stick starts only
after a very long wait (around 2 to 3 minutes).Some fi les supplied with the memor
y stick may greatly slow down access
to reading the memory stick (multiplication by 10 of the catalogue time). Delete the fi les supplied with the memory stickand limit the number of sub-folders in the fi le structure on the memory stick.
When I connect m
yiPhone as telephone and
to the USB port at thesame time, I am unable
to play the music fi les. When the iPhone connects automaticall
y as a telephone, it forces the
streaming function. The streaming function takes the place of the USBfunction which is then not useable, there is a period without sound of the
track being played with AppleÆ players.Æ
Disconnect and reconnect to the USB port (the USB function takes priority over streaming).
When I connect m
yApple Æ
player or my Æ
BlackBerryÆ
to theÆ
USB port, I have alert messages on the currentconsumption by the USBport. When char
ging, the current consumption of these smartphones is greater
than the rating of the USB port, which is 500mA.
FREQUENTLY ASKED QUESTIONS
