2013 CITROEN DS3 CABRIO Handbook (in English)

Practical information





Towing a trailer, ...


Towbar suitable for the attachment of a trailer
with additional lighting and signalling.
Your vehicle is primarily designed for
transporting people and luggage, but it mayalso be used for towing a trailer.
We recommend the use of genuineCITROËN towbars and their harnesses that have been tested and approved from the design stage of your vehicle, and that the fitting of the towbar is entrusted to a CITROËN dealer or a qualified workshop.If the towbar is not fitted by a CITROËNdealer, it is imperative that it is fitted in accordance with the vehicle manufacturer's instructions.
Driving with a trailer places greater demands
on the towing vehicle and the driver must take
par ticular care.

Driving advice


Distribution of loads
)
Distribute the load in the trailer so that the heaviest items are as close as possible to
the axle and the nose weight approaches the maximum permitted without exceeding it.
Air density decreases with altitude, thus
reducing engine performance. Above
1 000 metres, the maximum towed load must
be reduced b
y 10 % for every 1 000 metres of altitude.
Refer to the "Technical Data" section for detailsof the weights and towed loads which apply to your vehicle.

Side wind
)
Take into account the increased sensitivity
to side wind.

The rear parking sensors will be deactivated automatically if a genuineCITROËN towbar is used.
Cooling
Towing a trailer on a slope increases the
temperature of the coolant.
As the fan is electrically controlled, its coolingcapacity is not dependent on the engine speed. )To lower the engine speed, reduce your
speed.
The maximum towed load on a long incline depends on the gradient and the ambient
temperature.
In all cases, keep a check on the coolant
temperature.
Braking
To w i ng a trailer increases the braking distance.
To avoid overheating of the brakes on a longmountain type of descent, the use of engine braking is recommended.

Tyres
)
Check the tyre pressures of the towing
vehicle and of the trailer, obser ving the
recommended pressures.

Lighting
)
Check the electrical lighting and signallingon the trailer.
)
If the warning lamp and the
STOPwarning lamp come on,
stop the vehicle and switch off
the engine as soon as possible.

RACING towbar

Your vehicle cannot be fitted with a towbar. The space occupied by thesport diffuser prevents this.

233Practical information
Matt paint

We recommend the use of a high pressurejet wash, or at least a water hose with a high output.

We recommend that the vehicle be rinsed using de-ionised water.
Use only a microfibre cloth to dry the vehicle.It must be clean and used without heavypressure.
Lightly wipe off any fuel stains present on the
lacquer using a soft cloth, then leave to dry.
From the range of cleaning and maintenance
products recommended and approved by CITROËN, use only products for removing
insects and car shampoo.
Always have paint repairs done by a CITROËN
dealer or a qualified workshop.

Recommendations on the care and maintenance your vehicle are given in the ser vicing booklet.
Never clean the vehicle without water. Never wash your vehicle in anautomatic roller brush car wash.Never polish the vehicle body, nor the alloy wheels. Doing this will make the paintwork shiny. Do not use paint cleaners, abrasive products or paint polishing or preserving products (such as wax, for example) on the paintwork. These products are only suitable for bright finishes. Application of these products on vehicles with a matt finish will seriously damage the paint surface of the vehicle, giving rise to irreversible
shiny or stained areas.Never use a high pressure jet washwith a lance fitted with a brush, this may scratch the paintwork. Never select a wash programme that finishes with a hot wax cycle.















Advice on care and maintenance

If you vehicle is finished with a clear matt
lacquer, please observe the followingrecommendations to avoid damaging the paintwork by the use of an inappropriate cleaning procedures.
These recommendations are also valid for alloy
road wheels finished with clear matt lacquer.
Leather
Leather is a natural product. Appropriate
regular care and cleaning is essential for its
durability.
Refer to your vehicle's ser vicingbooklet for information on the specialprecautions to observe.

A wide range of accessories and genuine par ts is available from the CITROËN dealer network.
These accessories and par ts have been tested and approved for reliability and safety.
The
y are all adapted to your vehicle and benefit from CITROËN's recommendation and warranty.





Accessories
"Comfort":
sun blinds, air deflectors, isotherm module,ashtray, fragrance car tridges, coat hanger fixed
to head restraint, front centre armrest, movable
mirror, reading lamp, front and rear parking sensors...
"Transport solutions":
boot liner, boot spacers, boot carpet, boot net,
transverse roof bars, bicycle carrier, ski carrier, roof boxes, towbars, towbar wiring harnesses...

"Styling":
full grain leather steering wheel, coloured and carbotech dashboards, coloured and leather gear lever knobs, aluminium footrest, spoiler,
alloy wheels, coloured wheel trims, coloured
wheel caps, exterior expressive stickers,
exterior chrome kit...

*

To avoid any risk of jamming of the pedals:
- ensure that the mat is positioned and
secured correctly,
- never fit one mat on top of another.


"Security and safety":

anti-intrusion alarm, wheel security devices,
vehicle tracking system, breathalyser, first aid kit, warning triangle, high visibility safety vest,child seats, snow chains, non-skid covers, fire extinguisher...


"Protection":

mats *
, mudflaps, seat covers, vehicle covers,
bumper protectors...

When fitting a towbar outside the CITROËN dealer network, the installation must be done using thevehicle's electrical pre-equipment and following the vehicle manufacturer'srecommendations.

235
Practical information
"Multimedia":

hands-free system, audio systems, semi-
integral satellite navigation system, por table
navigation systems, mapping update CD, speed camera warning, DVD player, reversing camera, USB Box, speakers, Hi-Fi module,
230 V socket, WiFi on Board...B
y visiting a CITROËN dealer, you can also
obtain cleaning and maintenance products
(interior and exterior) - including ecologicalproducts from the "TECHNATURE" range,products for topping up (screenwash fluid...),
touch-up pens and paint aerosols for the exact
colour of your vehicle, refills (cartridge for the
temporary puncture repair kit...), ...



Installation of radiocommunication transmitters

Before installing any after-market radio communication transmitter, you can contact a CITROËN dealer for the specification of transmitters which canbe fitted (frequency, maximum power, aerial position, specific installationrequirements), in line with the VehicleElectromagnetic Compatibility Directive(2004/104/EC).



The fitting of electrical equipment or accessories which are not recommended by CITROËN may resultin a failure of your vehicle's electronicsystem and excessive electrical consumption. Please note this precaution. Youare advised to contact a CITROËNrepresentative to be shown the rangeof recommended equipment and accessories.
Depending on the legislation in force in the country, it may be compulsoryto have a high visibility safety vest, warning triangle and spare bulbs and fuses available in the vehicle.

012
Technical data
This section contains the specifications of your vehicle depending on itsengine and gearbox, such as the maximum power and torque, unladenand maximum weights, trailer weights, exterior dimensions and all of its
identification markings.

MODELS:ENGINES AND GEARBOXES
Model codes:SA...8FP08FP0/P5FS05FS95FV85FN8 * 5FM8**
PETROL ENGINESVTi 95VTi 120THP 155THP 150
*
THP 160
**
Cubic capacity (cc)
1 397
1 598

1 598

Bore x stroke (mm)
77 x 75
77 x 85.8

77 x 85.8

Max power: EU standard
(kW)
70
88 115
11 0 *

120 **

Max power engine speed
(rpm)
6 000 6 000 6 000
Max torque: EU standard
(Nm) 13 6
160240

Max torque en
gine speed (rpm)
4 000
4 2501 400


Fuel Unleaded
UnleadedUnleaded
Catalytic conver ter yes
yes
yes
GEARBOX

Manual(5-speed)

Electronic
(5-speed)
Manual (5-speed)

Automatic
(4-speed)

Manual(6-speed)
OIL CAPACITIES (in litres)

En
gine (with filter replacement) 4.25
4.25

4.25

4.25
*
For Belgium and Russia.
**
For Brazil.
